Green Sample Preparation for HPTLC: Sustainable Strategies for Modern Labs

Abstract

This article provides a comprehensive guide for researchers and pharmaceutical professionals on implementing green sample preparation principles for High-Performance Thin-Layer Chromatography (HPTLC). Covering foundational concepts to advanced applications, it explores solvent selection, miniaturization, and automation to reduce environmental impact. The content details practical methodologies for complex matrices, troubleshooting common challenges, and rigorous validation using modern green assessment tools. By aligning with Green Analytical Chemistry (GAC) and White Analytical Chemistry (WAC) principles, this resource offers a framework for developing sustainable, efficient, and compliant HPTLC workflows in pharmaceutical and biomedical research.

Principles and Drivers of Green Sample Preparation in HPTLC

Defining Green Analytical Chemistry (GAC) in the HPTLC Context

Green Analytical Chemistry (GAC) represents a transformative approach to chemical analysis that seeks to minimize the environmental impact of analytical procedures while maintaining data quality. In the pharmaceutical industry, where analytical testing is ubiquitous, adopting GAC principles addresses significant sustainability challenges associated with traditional methods. High-Performance Thin-Layer Chromatography (HPTLC) has emerged as a powerful technique for implementing GAC principles, offering several inherent green advantages over solvent-intensive techniques like High-Performance Liquid Chromatography (HPLC). HPTLC is an advanced form of planar chromatography that provides superior resolution, sensitivity, and reproducibility compared to conventional Thin-Layer Chromatography (TLC), achieved through optimized stationary phases with smaller particle sizes (5-6 μm versus 10-12 μm in TLC) and automated instrumentation [1].

The alignment between HPTLC and GAC stems from fundamental methodological differences. Unlike HPLC's sequential analysis requiring fresh mobile phase for each sample, HPTLC analyzes multiple samples simultaneously on a single plate using a minimal volume of mobile phase [2]. This parallel processing capability dramatically reduces solvent consumption and waste generation—often by 80-90% compared to HPLC methods [3]. Furthermore, HPTLC eliminates the need for expensive analytical columns and reduces energy consumption through shorter analysis times (typically 3-20 minutes) [1]. These inherent advantages position HPTLC as a cornerstone technique for implementing sustainable analytical practices in pharmaceutical quality control and research environments.

Core Principles of GAC in HPTLC

The Twelve Principles of Green Analytical Chemistry

Green Analytical Chemistry extends the original Twelve Principles of Green Chemistry to specifically address the environmental impact of analytical methodologies. When applied to HPTLC, these principles guide the development of sustainable methods without compromising analytical performance:

• Direct Analysis and Miniaturization: HPTLC inherently minimizes sample preparation through direct application of samples onto plates, often requiring minimal pre-treatment [4]. The ability to analyze multiple samples on a single plate (up to 30 samples simultaneously) represents a form of methodological miniaturization [1].

• Solvent and Energy Reduction: HPTLC consumes significantly less mobile phase than column chromatography techniques. A typical HPTLC development uses approximately 10-20 mL of mobile phase for simultaneous analysis of multiple samples, whereas HPLC may consume 500-1000 mL for similar sample throughput [3]. The reduced energy requirements stem from shorter analysis times and elimination of high-pressure pumping systems [2].

• Waste Minimization and Derivatization: HPTLC generates minimal waste, primarily consisting of the used TLC plate and residual mobile phase [2]. When detection requires derivatization, HPTLC enables minimal reagent usage through targeted spraying or dipping protocols [5].

• Operator Safety: The closed-system design of modern HPTLC instrumentation reduces analyst exposure to hazardous chemicals [2]. Additionally, the ability to use less toxic solvents (like ethanol-water mixtures) in reversed-phase HPTLC enhances operator safety [6] [3].

White Analytical Chemistry: The Evolution of GAC

A recent advancement in sustainable method development is White Analytical Chemistry (WAC), which expands GAC principles into a holistic three-pillar framework assessing analytical methods based on their environmental impact (green), analytical performance (red), and practicality and economic feasibility (blue) [7]. This trichromatic approach ensures that green methods maintain the rigor required for pharmaceutical analysis while remaining practically implementable in quality control laboratories.

In the WAC framework, the green component incorporates traditional GAC metrics, the red component adds analytical performance criteria, and the blue component considers economic aspects and practicality [7]. HPTLC methods align exceptionally well with WAC principles, as they typically score highly across all three dimensions—offering environmental benefits without compromising the accuracy, precision, and sensitivity required for pharmaceutical analysis [2] [3].

Greenness Assessment Tools and Metrics for HPTLC

The greenness of HPTLC methods can be quantitatively evaluated using multiple standardized assessment tools. These metrics provide objective measures of environmental impact and enable comparison between different analytical methods.

Table 1: Greenness Assessment Tools for HPTLC Methods

Assessment Tool	Key Metrics Evaluated	Scoring System	Application in HPTLC
AGREE [8]	12 principles of GAC	0-1 scale (higher is greener)	Comprehensive software-based assessment
Analytical Eco-Scale [6]	Hazardous chemicals, energy, waste	Penalty points (higher score = greener)	Simplified quantitative assessment
NEMI [9]	Persistence, bioaccumulation, toxicity, corrosivity	Pass/Fail for 4 criteria	Quick visual assessment (pictogram)
GAPI [9]	Entire method lifecycle from sampling to disposal	5-level pictogram	Comprehensive lifecycle assessment
BAGI [3]	Practicality and applicability	0-100 scale (higher = more practical)	Evaluates blue component of WAC
ComplexGAPI [7]	Advanced lifecycle assessment with multiple parameters	Multi-colored pictogram	In-depth greenness profile

Recent applications of these metrics demonstrate the excellent greenness profile of HPTLC methods. For example, a green HPTLC method for simultaneous quantification of bisoprolol fumarate, amlodipine besylate, and 4-hydroxybenzaldehyde achieved an AGREE score of 0.81 and an Analytical Eco-Scale score of 86, indicating excellent environmental performance [2]. Similarly, an HPTLC method for carvedilol analysis demonstrated superior greenness compared to published HPLC methods when assessed using NEMI, AGREE, and Analytical Eco-Scale tools [9].

Table 2: Comparative Greenness Scores of Recent HPTLC Methods

Analytical Target	HPTLC Method Details	AGREE Score	Eco-Scale Score	BAGI Score	Reference
Trifluridine & Tipiracil	Normal-phase, QbD-optimized	0.81	86	80	[8]
Ertugliflozin	Reversed-phase (EtOH-H₂O)	>0.8	>80	N/R	[6]
Carvedilol	Stability-indicating method	>0.8	>80	N/R	[9]
Bisoprolol, Amlodipine, Impurity	Green HPTLC-densitometry	0.81	N/R	87.5	[2]
Remdesivir, Favipiravir, Molnupiravir	Reversed-phase (EtOH-H₂O)	>0.8	>80	>85	[3]

Experimental Design and Methodologies

Green Solvent Selection for HPTLC Mobile Phases

A fundamental strategy for greening HPTLC methods involves replacing hazardous solvents with environmentally benign alternatives while maintaining chromatographic performance. The ethanol-water mobile phase system has emerged as a particularly successful green alternative for reversed-phase HPTLC applications.

Experimental Protocol: Method Transfer from Normal-Phase to Reversed-Phase HPTLC with Green Solvents

• Initial Method Development:

  • For normal-phase HPTLC, begin with traditional solvent systems (e.g., chloroform-methanol) to establish baseline separation parameters [6].
  • For reversed-phase HPTLC, test ethanol-water mixtures in varying proportions (typically 40:60 to 90:10 v/v) [6].

• Systematic Optimization:

  • Employ systematic optimization approaches such as Response Surface Methodology (RSM) with Central Composite Design (CCD) to identify critical method parameters [8].
  • For the analysis of ertugliflozin, a method using ethanol-water (80:20 v/v) on RP-18 plates demonstrated superior greenness and comparable performance to normal-phase methods using chloroform-methanol (85:15 v/v) [6].

• Greenness Verification:

  • Compare the greenness profiles using multiple assessment tools (AGREE, Eco-Scale, NEMI).
  • The ethanol-water system typically achieves perfect NEMI pictograms (all four quadrants green) and high AGREE scores (>0.8) due to reduced toxicity and hazardous waste generation [6] [3].

Analytical Quality by Design (AQbD) for Green HPTLC

The Analytical Quality by Design (AQbD) framework, aligned with White Analytical Chemistry principles, provides a systematic approach for developing robust green HPTLC methods [8] [7].

Experimental Protocol: AQbD-based Method Development

• Define Analytical Target Profile (ATP):

  • Identify critical quality attributes: resolution, retardation factor (Rf), peak symmetry, and detection limits [8].

• Identify Critical Method Parameters:

  • Determine factors that significantly impact separation: solvent ratio, chamber saturation time, development distance [8].
  • For trifluridine and tipiracil analysis, solvent volume and chamber saturation time were identified as critical factors through screening designs [8].

• Establish Method Operable Design Region (MODR):

  • Use experimental designs (e.g., Central Composite Design) to model the relationship between critical parameters and method responses [8].
  • Apply Response Surface Methodology to identify the optimal operational region where all method criteria are satisfied [8].

• Control Strategy and Validation:

  • Implement control measures for critical parameters.
  • Validate the method according to ICH Q2(R1) guidelines, confirming linearity, accuracy, precision, and robustness [8] [6].

Diagram: AQbD Workflow for Green HPTLC Method Development

Sample Preparation Green Principles

Sample preparation represents a significant opportunity for implementing GAC principles in HPTLC workflows. Green Sample Preparation (GSP) strategies focus on reducing solvent consumption, minimizing waste, and enhancing operator safety [4].

Experimental Protocol: Green Sample Preparation for HPTLC

• Minimalist Sample Treatment:

  • For pharmaceutical formulations, employ simple dissolution in the least toxic, least volatile solvent that provides adequate solubility [5].
  • Standard dilution: 1 drop sample to approximately 1 mL solvent (50-100x dilution) to prevent overloading while maintaining adequate sensitivity [5].

• Solvent Selection Hierarchy:

  • Preferred: Water, ethanol, ethyl acetate, acetone
  • Acceptable: Methanol, isopropanol
  • Avoid: Chloroform, hexane, dichloromethane, acetonitrile [6] [3]

• Miniaturization and Integration:

  • Use automated application systems that enable precise sample positioning with minimal volume (typically 0.5-2.0 μL for identity testing) [5].
  • Implement band application rather than spot application to improve resolution and quantitative accuracy [5].

Essential Research Reagent Solutions for Green HPTLC

Table 3: Essential Materials for Green HPTLC Method Development

Material/Reagent	Green Alternative	Function	Sustainability Advantage
Silica Gel 60 F₂₅₄ plates	Standard HPTLC plates	Stationary phase	Reusable for method development, minimal material consumption
Chloroform	Ethanol-water mixtures	Mobile phase component	Reduced toxicity, biodegradability
n-Hexane	Ethyl acetate-hexane mixtures	Mobile phase component	Lower bioaccumulation potential
Methanol	Ethanol or isopropanol	Mobile phase & sample solvent	Reduced toxicity, renewable sourcing
Derivatization reagents	Minimal volume spraying	Compound visualization	Reduced reagent consumption
Ammonia solution	Dilute solutions in sealed chambers	Modifier for basic compounds	Reduced volatilization exposure

Comparative Case Studies and Applications

Pharmaceutical Analysis Applications

Recent applications demonstrate the successful implementation of GAC principles in HPTLC methods for pharmaceutical analysis:

Case Study 1: Antiviral Drug Analysis A comparative study of normal-phase versus reversed-phase HPTLC for concurrent quantification of remdesivir, favipiravir, and molnupiravir demonstrated the superior greenness of the reversed-phase approach [3]. The RP-HPTLC method employing ethanol-water (6:4 v/v) mobile phase achieved excellent greenness scores (AGREE >0.8) while maintaining linearity (R² >0.99988), precision (RSD <2%), and accuracy (95-105% recovery) [3].

Case Study 2: Cardiovascular Drug Analysis A green HPTLC-densitometry method for simultaneous determination of bisoprolol fumarate, amlodipine besylate, and mutagenic impurity 4-hydroxybenzaldehyde used an eco-friendly mobile phase of ethyl acetate-ethanol (7:3 v/v) [2]. The method achieved baseline separation with Rf values of 0.29 ± 0.02 (impurity), 0.72 ± 0.01 (amlodipine), and 0.83 ± 0.01 (bisoprolol) while demonstrating minimal environmental impact through comprehensive sustainability assessment [2].

Green HPTLC versus Conventional HPLC

The environmental advantages of HPTLC become particularly evident when compared with conventional HPLC methods:

• Solvent Consumption: HPTLC typically uses 10-20 mL of mobile phase per analysis (multiple samples), while HPLC consumes 500-2000 mL per run [3].
• Energy Requirements: HPTLC operates at ambient pressure without high-pressure pumps, reducing energy consumption by approximately 70% compared to HPLC [2].
• Waste Generation: HPTLC generates primarily solid waste (TLC plates), while HPLC produces significant volumes of liquid waste requiring specialized disposal [3].
• Carbon Footprint: A recent study calculated the carbon footprint of green HPTLC methods at 0.021-0.037 kg CO₂ per sample, significantly lower than HPLC methodologies [2].

The integration of Green Analytical Chemistry principles into HPTLC method development represents a critical step toward sustainable pharmaceutical analysis. The emerging paradigm of White Analytical Chemistry, with its balanced consideration of environmental impact, analytical performance, and practical applicability, provides a comprehensive framework for evaluating and improving HPTLC methods [7]. Future developments will likely focus on several key areas:

First, the continued development and validation of green solvent systems for both normal-phase and reversed-phase HPTLC will further reduce the environmental footprint of analytical methods. Ethanol-water mixtures have demonstrated excellent potential as sustainable alternatives to traditional toxic solvents [6] [3].

Second, the implementation of Advanced Quality-by-Design approaches combined with multivariate optimization techniques will enable more efficient method development with reduced experimental runs and solvent consumption [8] [2]. The integration of computational modeling and in silico solvent selection tools will further enhance this trend.

Finally, the adoption of circular economy principles in analytical chemistry, including solvent recovery systems and biodegradable stationary phases, will push HPTLC toward even greater sustainability [10]. The proposed Green Financing for Analytical Chemistry (GFAC) model may provide dedicated funding to accelerate these innovations [7].

In conclusion, HPTLC represents a inherently green analytical technique that aligns strongly with GAC principles through minimal solvent consumption, reduced energy requirements, and minimal waste generation. Through the systematic application of greenness assessment tools, solvent replacement strategies, and quality-by-design approaches, HPTLC methods can achieve excellent environmental performance without compromising analytical rigor—fulfilling the promise of sustainable pharmaceutical analysis.

High-Performance Thin-Layer Chromatography (HPTLC) has evolved from a simple chromatographic tool into a versatile, sustainable analytical platform ideal for modern laboratories. The technique aligns intrinsically with the principles of Green Analytical Chemistry (GAC), offering a framework for reducing the environmental impact of analytical practices. A paradigm shift is occurring to align analytical chemistry with sustainability science, moving away from the traditional linear "take-make-dispose" model [10]. This transition is particularly crucial in pharmaceutical and natural product analysis, where conventional methods often rely heavily on toxic organic solvents and energy-intensive procedures, creating ecological and health risks [11]. The core green advantages of HPTLC include significantly reduced solvent consumption, minimal waste generation, lower energy demands, and enhanced operator safety compared to many column chromatographic techniques. Furthermore, the simplicity of HPTLC equipment often eliminates the need for extensive, energy-intensive instrumentation, contributing to a lower overall carbon footprint for analytical workflows [12].

Core Green Principles

Solvent Reduction

Solvent reduction stands as a primary pillar of green HPTLC. The technique is inherently minimalistic in its mobile phase requirements, typically consuming less than 10 mL of solvent per analysis, a fraction of the volume used in conventional High-Performance Liquid Chromatography (HPLC) [12]. This reduction is achieved through several mechanisms. Firstly, the miniaturized nature of HPTLC separations means that only a small volume of mobile phase is needed for development. Secondly, the choice of mobile phase itself can be optimized for greenness. Researchers are increasingly employing solvents with better environmental profiles, such as ethanol or ethyl acetate, in place of more hazardous options. The development of ecofriendly methods using mobile phases like isopropanol:water:glacial acetic acid for reversed-phase (RP) HPTLC and n-butanol:ethyl acetate for normal-phase (NP) HPTLC demonstrates this principle in practice [13]. Another significant advancement is the use of Micellar Liquid Chromatography (MLC), which utilizes surfactants in the mobile phase to further minimize or eliminate the need for organic solvents [11].

Waste Minimization

Waste minimization in HPTLC is achieved through both procedural design and technological innovation. Unlike HPLC, where the entire eluent becomes waste, HPTLC uses a fixed, small volume of mobile phase for development, resulting in minimal liquid waste [12]. The advent of microextraction techniques for sample preparation, such as Solid-Phase Microextraction (SPME) and Liquid-Phase Microextraction (LPME), dramatically reduces both solvent and sample volume requirements before the analysis even begins [11]. Furthermore, the HPTLC process itself generates no post-separation waste from column flushing or regeneration. A key strategy for transitioning from a linear "take-make-dispose" model to a Circular Analytical Chemistry (CAC) framework involves coordination and collaboration among all stakeholders, including manufacturers, researchers, and routine labs, to embrace circular principles like recycling and resource recovery [10]. This approach ensures that materials are kept in use for as long as possible, minimizing the overall waste footprint.

Safety Enhancement

Safety in green HPTLC encompasses both operator well-being and environmental protection. The principle of safety is directly addressed by substituting hazardous solvents with safer alternatives. The emergence of Natural Deep Eutectic Solvents (NADES) as green alternatives for extraction and sample preparation is a key development, offering biodegradability and low toxicity [11]. The reduced solvent volumes inherently lower the risk of operator exposure and the potential for environmental release. Methods are also designed to avoid, where possible, highly toxic or corrosive reagents. The validation of methods using tools like the AGREEprep metric quantitatively assesses and confirms the safety and greenness of sample preparation procedures, with scores of 0.77 and 0.73 reported for developed RP-HPTLC and NP-HPTLC methods, indicating green sample preparation [13]. Automation of sample preparation and application further enhances safety by minimizing direct human interaction with chemicals, thereby reducing exposure risks and handling errors [10].

Quantitative Assessment of Greenness

The greenness of analytical methods can be quantitatively evaluated using standardized metric tools, providing an objective measure of their environmental performance. The AGREEprep metric is used for assessing sample preparation steps, while the AGREE tool evaluates the overall analytical method. These tools consider multiple factors including waste generation, energy consumption, and hazardous chemical use.

Table 1: Greenness Assessment Scores of HPTLC Methods

Method Description	Application	AGREEprep Score (Sample Prep)	AGREE Score (Overall Method)	Key Green Features
RP-HPTLC Method [13]	Sorafenib analysis in formulations	0.77	0.83	Mobile phase: isopropanol:water:glacial acetic acid; Reduced solvent usage
NP-HPTLC Method [13]	Sorafenib analysis in formulations	0.73	0.82	Mobile phase: n-butanol:ethyl acetate; Reduced solvent usage
HPTLC-Densitometry [14]	Florfenicol & Meloxicam in tissue	Not Specified	Evaluated by 5 greenness tools	Mobile phase: glacial acetic acid:methanol:triethylamine:ethyl acetate

A study evaluating 174 standard methods from CEN, ISO, and Pharmacopoeias revealed that 67% scored below 0.2 on the AGREEprep scale, highlighting the urgent need to update standard methods with greener techniques like HPTLC [10]. The high greenness scores of the HPTLC methods in Table 1 demonstrate their superiority and alignment with the principles of green chemistry.

Experimental Protocols for Green HPTLC

Ecofriendly Method Development and Validation for Sorafenib

This protocol outlines the development of green RP-HPTLC and NP-HPTLC methods for quantifying Sorafenib in bulk and pharmaceutical formulations [13].

• Materials and Reagents: Sorafenib bulk drug, pharmaceutical formulations, isopropanol, n-butanol, ethyl acetate, glacial acetic acid (all analytical grade), water (HPLC grade).
• Instrumentation: HPTLC system (e.g., CAMAG) including Linomat IV/V applicator, twin-trough development chamber, TLC scanner, and WinCATS software. Pre-coated silica gel 60 F254 HPTLC plates.
• Sample Preparation: Standard stock solutions of Sorafenib are prepared in an appropriate solvent such as methanol. For formulation analysis, a representative sample is extracted with the same solvent.
• Chromatographic Conditions:
  • RP-HPTLC: Mobile phase: isopropanol:water:glacial acetic acid. Saturation time: 20 minutes. Development distance: 80 mm.
  • NP-HPTLC: Mobile phase: n-butanol:ethyl acetate. Saturation time: 20 minutes. Development distance: 80 mm.
• Detection & Analysis: Densitometric scanning is performed in absorbance mode at 265 nm. The Rf values are 0.54 ± 0.2 for RP-HPTLC and 0.7 ± 0.2 for NP-HPTLC.
• Method Validation: The method is validated as per ICH Q2(R2) guidelines for linearity (200-1000 ng/spot for RP-HPTLC, 200-1200 ng/spot for NP-HPTLC), precision, accuracy, specificity, and robustness. The greenness of the method is assessed using the AGREE and AGREEprep tools.

Green HPTLC Method for Veterinary Drug Residues in Tissue

This protocol describes an FDA-validated HPTLC method for the simultaneous quantification of Florfenicol and Meloxicam in spiked bovine muscle tissue, prioritizing sustainability [14].

• Materials and Reagents: Florfenicol (FLR) and Meloxicam (MEL) reference standards, Esomeprazole (ESO) internal standard, methanol (HPLC grade), triethylamine, glacial acetic acid, ethyl acetate, sodium hydroxide (NaOH), EDTA.
• Instrumentation: HPTLC system (e.g., CAMAG) with Linomat V applicator, twin-trough chamber, and TLC scanner 3 operated with WinCATS software. Aluminum-backed silica gel 60 F254 plates.
• Sample Preparation (Spiked Bovine Tissue):
  • Homogenize 2 grams of bovine muscle tissue.
  • Spike tissue with known concentrations of FLR and MEL.
  • Add 300 µL of 0.10 N EDTA and 0.50 mL of ESO internal standard solution.
  • Extract analytes using a suitable method (e.g., vortex mixing with solvent).
  • Centrifuge and filter the supernatant through a 0.45 µm nylon membrane.
• Chromatographic Conditions: Mobile phase: glacial acetic acid:methanol:triethylamine:ethyl acetate (0.05:1.00:0.10:9.00, v/v/v/v). Chamber saturation: 15 minutes at room temperature. Development distance: 80 mm.
• Detection & Analysis: Densitometric scanning is performed at 230 nm. Calibration curves are linear from 0.50–9.00 µg/band for FLR and 0.03–3.00 µg/band for MEL.
• Method Validation: Validation according to ICH guidelines. The method's greenness is confirmed using five different assessment tools (greenness, whiteness, and blueness metrics).

Workflow and Signaling Pathways

The following diagram illustrates the logical workflow for implementing green principles in HPTLC method development, from core concepts to final validation.

Green HPTLC Method Development Workflow

The Scientist's Toolkit: Research Reagent Solutions

This table details key reagents and materials used in green HPTLC experiments, highlighting their function and sustainable attributes.

Table 2: Essential Materials for Green HPTLC Analysis

Item Name	Function / Purpose	Green & Safety Attributes
Silica Gel 60 F254 HPTLC Plates [14]	Stationary phase for chromatographic separation.	Enables parallel analysis of multiple samples, reducing solvent use and analysis time per sample.
Ethyl Acetate [13] [14]	Component of the mobile phase.	Less hazardous and more biodegradable compared to chlorinated solvents.
Isopropanol [13]	Component of the mobile phase.	Preferred over more toxic alcohols like methanol in some methods.
Natural Deep Eutectic Solvents (NADES) [11]	Green alternative for sample extraction and preparation.	Offer biodegradability, low toxicity, and are often derived from renewable sources.
Water (HPLC Grade) [13]	Component of the mobile phase in RP-HPTLC.	Non-toxic, safe, and the most green solvent available.
Triethylamine [14]	Modifier in the mobile phase to improve peak shape.	Used in very low concentrations (e.g., 0.10% v/v) to minimize environmental impact.

The integration of solvent reduction, waste minimization, and safety enhancement as core principles is fundamental to advancing sustainable HPTLC research. The demonstrated protocols and quantitative greenness assessments prove that it is feasible to develop analytical methods that are both environmentally responsible and scientifically rigorous, complying with stringent regulatory standards. The adoption of these principles, supported by tools like AGREE and a circular economy mindset, paves the way for more responsible and sustainable practices in pharmaceutical and natural product research. As the field evolves, continued innovation in green solvents, miniaturized techniques, and collaborative efforts across industry and academia will further solidify the role of HPTLC as a cornerstone of green analytical chemistry.

The Environmental and Economic Imperative for Greener Labs

The field of analytical chemistry stands at a critical juncture. Its success in determining the composition and quantity of matter plays a crucial role in addressing environmental challenges, yet its traditional reliance on energy-intensive processes, non-renewable resources, and waste generation raises significant sustainability concerns [10]. A paradigm shift is occurring to align analytical chemistry with sustainability science, particularly in pharmaceutical and natural product research where routine testing generates substantial solvent waste and consumes considerable energy [10]. High-Performance Thin-Layer Chromatography (HPTLC) has emerged as a powerful platform that bridges the gap between analytical performance and environmental responsibility. This technical guide explores how HPTLC, especially when integrated with green sample preparation principles, offers researchers and drug development professionals a pathway to maintain analytical excellence while reducing their ecological footprint and operational costs.

The transition from traditional linear "take-make-dispose" models to a Circular Analytical Chemistry (CAC) framework represents the future of responsible laboratory practice [10]. This transition faces two primary challenges: the lack of clear direction toward greener practices, and coordination failures among stakeholders including manufacturers, researchers, routine labs, and policymakers [10]. HPTLC addresses these challenges by offering a versatile analytical platform that aligns with the core principles of Green Analytical Chemistry (GAC), providing inherent sustainability benefits through minimal solvent consumption, reduced energy requirements, and capacity for parallel sample processing [12].

HPTLC as a Foundation for Sustainable Analysis

The Evolution from TLC to Advanced HPTLC Platforms

Thin-layer chromatography (TLC) has long been appreciated for its affordability, simplicity, and rapid qualitative screening capabilities [12]. However, traditional TLC suffered from several inherent limitations, including low resolution, poor reproducibility, and limited quantification accuracy, making it increasingly inadequate for modern regulatory or high-throughput workflows [12]. The evolution to High-Performance Thin-Layer Chromatography (HPTLC) has transformed this technique from a simple chromatographic tool to a powerful and versatile analytical platform through improved stationary phases with finer particle sizes, automated sample application, standardized development conditions, and advanced detection capabilities [12].

Recent advances have further elevated HPTLC into a modular, high-resolution analytical platform through integration with complementary detection systems. These include Mass Spectrometry (HPTLC-MS) for structural identification and trace quantification, Surface-Enhanced Raman Spectroscopy (HPTLC-SERS) for molecular fingerprinting, and Near-Infrared Spectroscopy (HPTLC-NIR) for non-destructive compositional profiling [12]. Additional enhancements, such as bioautography enable function-directed screening of biological activity, while Metal-Organic Framework (MOF)-modified plates facilitate selective analyte enrichment [12]. Together, these innovations constitute a new generation of ''HPTLC+'' platforms that substantially improve sensitivity, selectivity, and throughput in complex matrices while maintaining environmental benefits.

Quantitative Environmental and Economic Advantages

The sustainability advantages of HPTLC become particularly evident when comparing its resource consumption with conventional chromatographic methods. The following table summarizes key comparative metrics based on experimental data from recent studies:

Table 1: Environmental and Economic Comparison of HPTLC versus UHPLC for Herbal Drug Analysis [15]

Parameter	Combined USP Method (HPTLC + UHPLC)	New HPTLC Method	Improvement Ratio
Solvent Consumption	Baseline	13x less	13:1
Cost per Sample	Baseline	37% of original cost	~2.7:1 cost saving
Analysis Time per Sample	Baseline	2.9x faster	~3:1 time saving
Cost for 13 Samples	Baseline	<10% of original cost	>10:1 cost saving
Time for 13 Samples	Baseline	11x faster	>11:1 time saving

The dramatic scalability of advantages for multiple samples arises from HPTLC's parallel processing capability. While UHPLC analysis time and cost increase linearly with each additional sample, HPTLC can process numerous samples on a single plate with minimal incremental resource requirements [15]. This makes HPTLC particularly advantageous for quality control laboratories handling large sample volumes.

The green credentials of HPTLC methods have been quantitatively validated using modern assessment tools. For instance, an eco-friendly HPTLC method for determining Tenoxicam in commercial formulations demonstrated an excellent Analytical GREEnness (AGREE) score of 0.75 out of 1.0, confirming its outstanding environmental profile [16]. Similarly, methods for sorafenib analysis achieved AGREE scores of 0.83 (RP-HPTLC) and 0.82 (NP-HPTLC), reflecting their high environmental sustainability [17].

Green Sample Preparation Fundamentals for HPTLC

Core Principles and Strategies

Green sample preparation for HPTLC aligns with the twelve principles of Green Analytical Chemistry, emphasizing waste prevention, safer solvents, energy efficiency, and real-time analysis for pollution prevention [12] [10]. The fundamental strategies include:

• Solvent Reduction and Substitution: Replacing hazardous solvents with eco-friendly alternatives like ethanol, water, ethyl acetate, or acetone in mobile phases [16]. For example, a green HPTLC method for Tenoxicam utilizes ethanol/water/ammonia solution (50:45:5 v/v/v) instead of traditional toxic solvents [16].
• Miniaturization and Micro-Scale Extraction: Using minimal sample sizes and solvent volumes through techniques like vortex-assisted extraction or ultrasound-assisted extraction that enhance mass transfer while consuming less energy [10].
• Parallel Processing: Handling multiple samples simultaneously to increase throughput and reduce energy consumption per sample [15] [10].
• Automation: Implementing automated systems to save time, lower consumption of reagents and solvents, reduce waste generation, and minimize operator exposure to hazardous chemicals [10].
• Integration: Streamlining multi-step preparation processes into single, continuous workflows to cut down on resource use and waste production [10].

Practical Methodologies and Protocols

Eco-Friendly HPTLC Method for Pharmaceutical Analysis

A validated green HPTLC method for simultaneous quantification of bisoprolol fumarate, amlodipine besylate, and 4-hydroxybenzaldehyde demonstrates practical implementation of these principles [2]:

• Stationary Phase: Silica gel 60 F₂₅₄ plates (10 × 10 cm)
• Mobile Phase: Ethyl acetate–ethanol (7:3, v/v)
• Sample Application: 8 mm bands at 10 mm intervals using automated applicator
• Development Conditions: Automated development chamber with 25 min pre-saturation at 25 ± 0.5°C and 40 ± 2% relative humidity
• Detection: Densitometric scanning at appropriate wavelengths with deuterium/tungsten lamps
• Linear Range: Demonstrated for all analytes with correlation coefficients ≥ 0.9995
• Sustainability Metrics: AGREE score > 0.80, minimal carbon footprint (0.037 kg CO₂/sample)

Green HPTLC Method for Veterinary Drug Residues

An FDA-validated eco-friendly HPTLC method for quantification of Florfenicol and Meloxicam in bovine tissues illustrates green principles applied to complex matrices [14]:

• Sample Preparation: Homogenized tissue spiked with analytes and extracted using minimal solvent volumes
• Mobile Phase: Glacial acetic acid/methanol/triethylamine/ethyl acetate (0.05:1.00:0.10:9.00, by volume)
• Detection: Densitometry at 230 nm with esomeprazole as internal standard
• Validation: Linear ranges of 0.03–3.00 µg/band for meloxicam and 0.50–9.00 µg/band for Florfenicol
• Greenness Assessment: Evaluated with five greenness assessment tools confirming eco-friendly nature

The following workflow diagram illustrates the integration of green principles into HPTLC method development:

Essential Research Reagent Solutions for Green HPTLC

Implementing green HPTLC methodologies requires careful selection of reagents and materials that maintain analytical performance while reducing environmental impact. The following table details key research reagent solutions and their functions in sustainable HPTLC workflows:

Table 2: Essential Materials for Green HPTLC Methods [12] [14] [16]

Material/Reagent	Function in HPTLC	Green Alternatives & Considerations
Silica gel 60 F₂₅₄ plates	Stationary phase for separation	Standard HPTLC plates; MOF-modified plates available for enhanced selectivity [12]
Ethanol	Mobile phase component	Preferred green solvent; replace acetonitrile or methanol where possible [16]
Ethyl Acetate	Mobile phase component	Low toxicity alternative to chlorinated solvents [2]
Water	Mobile phase component	Solvent with zero environmental impact; ideal for reversed-phase HPTLC [16]
Ammonia Solution	Modifier for peak symmetry	Minimal volumes (e.g., 5%) to improve chromatography without significant environmental impact [16]
Metal-Organic Frameworks (MOFs)	Stationary phase modification	Enhance selectivity and enrichment for trace analytes; reduce need for extensive sample cleanup [12]

Advanced Sustainable HPTLC Platforms and Applications

Multimodal HPTLC Integration

The true potential of HPTLC in green analytical chemistry emerges through its integration with complementary detection techniques. The "HPTLC+" concept represents a multimodal approach that leverages the separation power of HPTLC while adding specificity and sensitivity through coupled techniques [12]:

• HPTLC-MS: Combines rapid separation with high-resolution mass spectrometry for structural identification, leveraging pre-separation to reduce ion suppression effects [12].
• HPTLC-SERS: Integrates separation with Surface-Enhanced Raman Spectroscopy for molecular fingerprinting directly on the plate without need for elution [12].
• HPTLC-NIR: Enables non-destructive monitoring of food freshness and quality through near-infrared spectroscopy [12].
• HPTLC-Bioautography: Provides function-directed screening of biological activity, linking chemical profiles with biological effects [12].

These integrated approaches align with green chemistry principles by maximizing information obtained from a single analysis, thereby reducing the need for multiple separate tests and associated resource consumption.

Computational Enhancements and Sustainability Metrics

The integration of computational methods with HPTLC represents another advancement toward sustainability. Recent research demonstrates the successful application of Firefly Algorithm-optimized partial least squares (FA-PLS) spectrophotometry alongside HPTLC, achieving exceptional environmental profiles with minimal carbon footprints (0.021-0.037 kg CO₂/sample) and outstanding sustainability scores across multiple metrics [2].

Furthermore, the adoption of convolutional neural networks (CNNs) for automated spot recognition in HPTLC analysis improves data processing efficiency, reduces human errors, and enhances reproducibility [12]. This integration of artificial intelligence supports sustainability by optimizing method development and reducing solvent consumption through predictive modeling.

Modern greenness assessment tools provide quantitative metrics for evaluating analytical methods. The AGREE (Analytical GREEnness) metric system applies all 12 principles of GAC, offering a comprehensive scoring system from 0 (not green) to 1 (excellent greenness) [16]. Additional tools include the Analytical Eco-Scale, GAPI (Green Analytical Procedure Index), and ComplexGAPI, which provide multi-dimensional assessment of method environmental impact [16] [2]. These metrics enable researchers to objectively compare and optimize their methods for sustainability.

The transition to greener laboratories is both an environmental imperative and an economic opportunity. HPTLC technology, particularly when integrated with green sample preparation principles and advanced detection platforms, offers a practical pathway toward sustainable analytical practices without compromising analytical performance. The documented reductions in solvent consumption (up to 32-fold), analysis time (up to 11-fold faster), and operational costs (over 90% reduction for batch analysis) provide compelling evidence for adopting HPTLC in research and quality control settings [15].

Successful implementation requires coordinated effort across multiple stakeholders. Researchers should prioritize method development using green solvents like ethanol, water, and ethyl acetate [16]. Laboratory managers should invest in automated HPTLC systems that enable parallel processing and reduce solvent consumption [10]. Regulatory agencies play a critical role by updating standard methods to incorporate green metrics and providing incentives for adopting sustainable practices [10].

As the field advances, the integration of HPTLC with computational methods, artificial intelligence, and circular economy principles will further enhance sustainability. By embracing these innovations, researchers, scientists, and drug development professionals can lead the transformation toward laboratories that not only generate crucial scientific data but also protect environmental resources for future generations.

High-Performance Thin-Layer Chromatography (HPTLC) represents a modern, instrumentalized advancement of traditional thin-layer chromatography, offering superior separation efficiency, detection sensitivity, and reproducibility. Beyond its analytical capabilities, HPTLC has emerged as an inherently sustainable platform that aligns with the principles of Green Analytical Chemistry (GAC). This technical guide examines the core sustainable attributes of HPTLC, focusing on its minimal solvent consumption and reduced energy demands compared to conventional chromatographic techniques. The environmental advantages of HPTLC are particularly relevant within the broader context of greener sample preparation for analytical research, offering scientists a viable path toward reducing the ecological footprint of pharmaceutical and natural product analysis without compromising analytical performance [11].

The fundamental architecture of HPTLC contributes significantly to its sustainable profile. Unlike column-based chromatographic systems where mobile phase flows continuously throughout analysis, HPTLC employs a passive development process where solvent migration occurs capillary action. This core mechanistic difference translates into substantially reduced solvent consumption per sample analyzed [2]. Additionally, the elimination of high-pressure pumping systems and temperature-controlled columns dramatically decreases energy requirements, positioning HPTLC as an environmentally conscious choice for routine analytical applications [11].

Core Sustainable Attributes of HPTLC

Minimal Solvent Consumption

The solvent requirements of HPTLC are substantially lower than those of liquid chromatography techniques, representing one of its most significant environmental advantages. A typical HPTLC development consumes approximately 10-15 mL of mobile phase, which remains in a closed chamber during the separation process [2]. This fixed volume requirement remains constant regardless of whether 10 or 100 samples are applied to a single plate, creating exceptional efficiency for batch analysis.

The environmental impact of this minimal solvent usage is quantifiable through green chemistry assessment tools. In the development of an HPTLC method for carvedilol analysis, researchers employed a mobile phase of toluene, isopropanol, and ammonia (7.5:2.5:0.1, v/v/v), specifically designed to avoid carcinogenic solvents while maintaining sharp, symmetric peaks with minimal tailing [9]. The greenness assessment using multiple metrics confirmed the method's reduced environmental impact compared to published chromatographic methods for the same analyte.

Table 1: Solvent Consumption Comparison Between HPTLC and HPLC

Parameter	HPTLC	Conventional HPLC
Mobile phase volume per analysis	10-15 mL (per plate)	500-1000 mL (per run)
Sample capacity per run	Up to 100 samples/plate	1 sample/injection
Solvent waste generation	Minimal	Significant
Sample preparation volume	0.5-10 µL/spot	10-100 µL/injection

Reduced Energy Requirements

HPTLC systems operate without energy-intensive components common to other chromatographic platforms. The absence of high-pressure pumping systems, heated column compartments, and complex mixing chambers translates to dramatically lower power consumption. A typical HPTLC analysis requires energy only for the sample applicator, plate development (in some automated systems), and densitometric scanning—collectively consuming a fraction of the power needed to operate HPLC or UHPLC systems [2].

This energy efficiency extends throughout the analytical workflow. While HPLC systems often require continuous operation for multiple analyses, HPTLC allows for parallel processing of samples on a single plate, further reducing energy demands per sample. The cumulative effect is an analytical technique with a significantly reduced carbon footprint, quantified in one study as 0.037 kg CO₂ per sample for HPTLC compared to substantially higher values for HPLC methodologies [2].

Inherent Waste Minimization

The HPTLC workflow generates minimal analytical waste through several mechanism. The small mobile phase volumes required naturally reduce solvent waste, while the disposable plate nature eliminates column cleaning and regeneration steps that typically consume significant solvent volumes in column chromatography [11]. Furthermore, the ability to analyze multiple samples on a single plate consolidates waste streams, simplifying disposal and reducing handling costs.

Recent applications demonstrate this waste reduction in practice. A dual-platform HPTLC method for quantifying bisoprolol fumarate, amlodipine besylate, and 4-hydroxybenzaldehyde employed an eco-friendly mobile phase of ethyl acetate-ethanol (7:3, v/v), achieving baseline separation while minimizing hazardous waste generation [2]. The method's sustainability was confirmed through comprehensive assessment tools including NEMI, AGREE, and ComplexGAPI, which awarded perfect scores for environmental performance.

Quantitative Sustainability Assessment

Modern green chemistry assessment tools provide quantitative metrics for evaluating the environmental footprint of analytical methods. These tools consistently demonstrate the superior sustainability profile of HPTLC methodologies across multiple dimensions.

Table 2: Greenness Assessment Scores of Recent HPTLC Methods

Application Domain	Assessment Tool	Score/Result	Reference
Sorafenib analysis	AGREE (RP-HPTLC)	0.83/1.0	[13]
Sorafenib analysis	AGREE (NP-HPTLC)	0.82/1.0	[13]
Cardiovascular drugs & impurity	Carbon footprint	0.037 kg CO₂/sample	[2]
Cardiovascular drugs & impurity	NEMI	Perfect score	[2]
Carvedilol quantification	AGREE, NEMI, GAPI	Superior to reference methods	[9]
Remdesivir with co-administered drugs	Analytical Eco-scale, GAPI, AGREE	Confirmed eco-friendly	[18]

The AGREE assessment tool evaluates methods across twelve principles of green analytical chemistry, generating a score between 0-1, with higher scores indicating superior environmental performance [9] [13]. The consistently high scores achieved by HPTLC methods reflect their alignment with sustainable practice, particularly in terms of waste minimization, energy efficiency, and reagent toxicity reduction.

Experimental Protocols for Sustainable HPTLC Analysis

Eco-Friendly Method Development Protocol

The development of sustainable HPTLC methods follows a systematic approach that prioritizes environmental considerations alongside analytical performance:

• Mobile Phase Selection: Begin with ethanol, ethyl acetate, or isopropanol as the primary solvents, which offer favorable environmental and safety profiles compared to traditional acetonitrile or chlorinated solvents [2] [13]. For example, a method for bisoprolol fumarate and amlodipine employed ethyl acetate-ethanol (7:3, v/v) as the mobile phase [2].

• Solvent Ratio Optimization: Systematically adjust solvent ratios to achieve resolution (Rs > 1.5) while minimizing overall solvent consumption. Employ software-assisted optimization when available to reduce experimental iterations.

• Greenness Assessment: Evaluate the optimized method using at least two greenness assessment tools (e.g., AGREE, NEMI, GAPI) to quantify environmental performance [9] [2].

• Method Validation: Validate according to ICH Q2(R1) guidelines to ensure analytical performance is maintained despite greener solvent choices [13].

Sustainable Sample Preparation Workflow

Sample preparation for HPTLC can be optimized for minimal environmental impact:

• Micro-Scale Extraction: Utilize minimal solvent volumes for extraction. A recent method for florfenicol and meloxicam in bovine tissue employed 300 µL of 0.10 N EDTA for extraction, followed by direct application to HPTLC plates [14].

• Eco-Friendly Solvents: Replace traditional solvents with greener alternatives. Natural Deep Eutectic Solvents (NADES) have emerged as biodegradable, low-toxicity options for extraction [11].

• Minimal Sample Manipulation: Leverage HPTLC's tolerance for partially purified samples to reduce clean-up steps. The analysis of remdesivir with co-administered drugs in spiked human plasma demonstrated successful quantification with minimal sample preparation [18].

HPTLC Green Analysis Workflow

Greenness Evaluation Protocol

Comprehensive sustainability assessment should be integrated into method validation:

• Multi-Tool Assessment: Employ complementary assessment tools to evaluate different environmental aspects. The NEMI scale provides a quick visual profile, while AGREE offers comprehensive scoring across twelve GAC principles [9].

• Carbon Footprint Calculation: Quantify energy consumption and convert to CO₂ equivalents using standard conversion factors. The documented value of 0.037 kg CO₂ per sample for HPTLC provides a benchmark for comparison [2].

• Solvent Waste Accounting: Precisely measure and document all solvent wastes generated during analysis, including sample preparation and development.

• Comparative Assessment: Benchmark against previously published methods for the same analytes to demonstrate environmental improvement.

The Researcher's Toolkit: Essential Materials for Sustainable HPTLC

Table 3: Essential Research Reagents and Materials for Sustainable HPTLC

Item	Function	Green Considerations
Silica gel 60 F₂₅₄ plates	Stationary phase for separation	Mercury-free fluorescence indicator, minimal material usage per sample
Ethanol or ethyl acetate	Mobile phase components	Renewable sources, low toxicity, biodegradable
CAMAG Linomat autosampler	Precise sample application	Reduced sample volume requirements (50-100 nL/band)
HPTLC denistometer	Quantification of separated bands	Eliminates derivatization reagents in many cases
Microsyringe (100 µL)	Sample application	Enables precise low-volume application
Twin-trough development chamber	Mobile phase containment	Enables chamber saturation with minimal solvent

Hyphenation and Advanced Sustainable Applications

The sustainability profile of HPTLC extends to its hyphenation capabilities with other analytical techniques. HPTLC-MS coupling represents a powerful combination where the minimal solvent consumption of HPTLC is preserved while adding mass spectrometric identification capabilities [19]. This approach avoids the continuous solvent flow into the MS interface characteristic of LC-MS, further reducing waste generation and solvent consumption.

Recent applications demonstrate HPTLC's effectiveness in complex analytical scenarios with maintained sustainability. The simultaneous quantification of florfenicol and meloxicam in bovine tissue achieved detection limits of 0.06 µg/spot for meloxicam and 0.18 µg/spot for florfenicol while utilizing a mobile phase of glacial acetic acid, methanol, triethylamine, and ethyl acetate (0.05:1.00:0.10:9.00, by volume) [14]. The method's greenness was confirmed using five different assessment tools, highlighting its minimal environmental impact despite the complex matrix.

Similarly, the analysis of remdesivir in combination with linezolid and rivaroxaban in spiked human plasma employed a mobile phase of dichloromethane-acetone (8.5:1.5, v/v), achieving detection limits of 128.8, 50.5, and 55.8 ng/band for the respective analytes [18]. The method demonstrated that even for challenging pharmaceutical applications, HPTLC methods can maintain high sensitivity while adhering to green chemistry principles.

HPTLC stands as an inherently sustainable analytical platform that directly addresses the growing need for environmentally responsible chromatography techniques. Its fundamental operational principles—characterized by minimal solvent consumption, low energy requirements, and minimal waste generation—provide a solid foundation for green analytical methodologies. The technique's compatibility with eco-friendly solvents, minimal sample preparation requirements, and capacity for high-throughput analysis further enhance its environmental profile.

As pharmaceutical and natural product research increasingly prioritizes sustainability alongside analytical performance, HPTLC offers a viable path forward. The quantitative greenness assessments consistently demonstrate HPTLC's superiority to conventional chromatographic techniques across multiple environmental metrics. By adopting HPTLC methodologies and the protocols outlined in this guide, researchers can significantly reduce the ecological footprint of their analytical operations while maintaining the high-quality data required for drug development and quality control.

Regulatory Trends and Standards Influencing Green Method Development

The field of analytical chemistry is undergoing a significant paradigm shift, moving beyond a sole focus on performance to integrate environmental sustainability as a core principle. This transition is increasingly driven by global regulatory trends and the development of standardized frameworks that encourage the adoption of Green Analytical Chemistry (GAC) principles. High-Performance Thin-Layer Chromatography (HPTLC) is at the forefront of this movement due to its inherent advantages in minimal solvent consumption, energy efficiency, and capacity for high-throughput analysis [12]. Ensuring the authenticity and safety of food and herbal products amid globalized supply chains has created an urgent need for advanced screening technologies that are not only rapid and reliable but also environmentally sustainable [12]. This technical guide examines the current regulatory landscape and standards shaping green method development, providing researchers and drug development professionals with the frameworks and practical protocols needed to align HPTLC research with sustainability goals.

Current Regulatory Landscape and Standardization Initiatives

International Pharmacopoeia Advancements

A significant regulatory development is the World Health Organization's (WHO) recent draft proposal for a new general chapter "1.18 High-Performance Thin-Layer Chromatography" to be included in The International Pharmacopoeia [20]. This chapter, currently open for public consultation until September 2025, defines HPTLC as a chromatographic technique "in which variables are controlled within narrow ranges, using a standardized methodology and appropriate equipment, in order to achieve more reproducible results compared to traditional thin-layer chromatography (TLC)" [20]. The proposed chapter includes:

• An introduction to HPTLC principles
• Required equipment and materials specifications
• A step-by-step analytical procedure
• System suitability criteria and documentation standards
• New reagent specifications (e.g., saturated MgCl₂ solution) [20]

This standardization represents a crucial step toward formal recognition of HPTLC as a robust analytical technique suitable for regulatory compliance, providing a validated foundation for implementing greener methodologies.

Compendial HPTLC Methods and Regulatory Compliance

Compendial HPTLC methods published in authoritative sources such as the United States Pharmacopeia (USP), Food Chemicals Codex (FCC), and European Pharmacopoeia (EP or PhEur) provide standardized methods validated for specific botanicals or extracts [21]. These methods include detailed acceptance criteria to guide evaluation, ensuring regulatory compliance, reproducibility, and transparency in testing. For example, the method for Melissa leaf (lemon balm) dry extract specifies solvent types and concentrations that must be adhered to for proper testing [21].

The selection of fit-for-purpose compendial methods requires specific information including genus species, plant part, extraction process, solvents, standardization steps, and product specifications [21]. Results are analyzed based on Retention Factor (Rf) values, color, and band intensity, documented as "conforms" or "does not conform" on the Certificate of Analysis (CoA) [21]. While these standardized methods provide a reliable regulatory foundation, their predefined scope may not account for all material variabilities, sometimes necessitating additional method development for complex analytical challenges [21].

The Shift from Linear to Circular Analytical Chemistry

A broader paradigm shift is occurring in analytical chemistry, transitioning from a linear "take-make-dispose" model toward a Circular Analytical Chemistry (CAC) framework [10]. This transition faces two primary challenges: the lack of clear direction toward greener practices, and coordination failures among stakeholders including manufacturers, researchers, routine labs, and policymakers [10].

Regulatory agencies are increasingly recognizing the need to phase out outdated methods in favor of greener alternatives. A recent evaluation of 174 standard methods and their 332 sub-method variations from CEN, ISO, and Pharmacopoeias revealed poor greenness performance, with 67% of methods scoring below 0.2 on the AGREEprep scale (where 1 represents the highest possible score) [10]. This demonstrates that many official methods still rely on resource-intensive and outdated techniques, highlighting the urgent need to update standard methods by including contemporary and mature analytical approaches [10].

Greenness Assessment Metrics and Method Validation

Standardized Greenness Evaluation Tools

The development of standardized metrics has been crucial for objectively evaluating the environmental impact of analytical methods. Several tools have emerged, with the Analytical GREEnness (AGREE) metric representing the most comprehensive approach as it incorporates all 12 principles of green analytical chemistry [16] [22].

Table 1: Comparison of Greenness Assessment Tools

Assessment Tool	Key Features	Scoring System	Applicability
Analytical GREEnness (AGREE)	Evaluates all 12 GAC principles	0-1 scale (1 = excellent greenness)	Comprehensive method evaluation
Green Analytical Procedure Index (GAPI)	Pictorial representation of environmental impact	5-color pictogram	Visual method comparison
Modified Green Analytical Procedure Index (MoGAPI)	Enhanced version of GAPI	Quantitative scoring	Detailed lifecycle assessment
National Environmental Methods Index (NEMI)	Traditional environmental assessment	Pass/Fail criteria	Basic greenness screening

These metrics have become essential for validating claims of environmental sustainability in analytical method development. For instance, a reverse-phase HPTLC method for caffeine estimation in energy drinks and pharmaceutical formulations achieved an AGREE score of 0.80, confirming its excellent greener profile [22]. Similarly, a green HPTLC method for tenoxicam determination demonstrated an AGREE score of 0.75, indicating outstanding environmental performance [16].

Quantitative Greenness Assessment in Practice

The application of these metrics provides quantitative validation of green method improvements. Recent studies demonstrate how HPTLC consistently demonstrates high greenness ratings due to:

• Minimal solvent consumption (<10 mL per analysis) [12]
• Low energy requirements (often operating at ambient pressure/temperature) [12]
• Elimination of derivatization in many cases [12]
• Capacity for parallel sample processing [12]

When compared with traditional techniques like HPLC and GC-MS, HPTLC offers distinct advantages in speed (5-15 min analysis time versus >30 min for HPLC/GC-MS) and significantly reduced solvent consumption [12]. The application of greenness assessment metrics provides objective validation of these environmental benefits, facilitating regulatory acceptance and implementation.

Practical Implementation: Green HPTLC Methodologies

Experimental Protocols for Green HPTLC

The development of green HPTLC methods requires careful optimization of both stationary and mobile phases to minimize environmental impact while maintaining analytical performance. The following experimental protocols illustrate successfully implemented green HPTLC methodologies:

Table 2: Experimental Parameters for Green HPTLC Methods

Analyte	Mobile Phase Composition	Stationary Phase	Detection	AGREE Score	Reference
Tenoxicam	Ethanol/water/ammonia solution (50:45:5 v/v/v)	HPTLC silica gel plates	375 nm	0.75	[16]
Caffeine	Ethanol-water (55:45 v/v)	Reverse-phase silica gel 60 F254S plates	275 nm	0.80	[22]
Phenylephrine & Doxylamine	Ethanol/methylene chloride/ammonia 30% (7:2.5:0.5 v/v/v)	Silica gel 60 F254 plates	260 nm	Reported as green	[23]
Lidocaine & Miconazole	Eth acetate:methanol:formic acid (9:1:0.1, by volume)	TLC silica gel fluorescent indicator F254	220 nm	Green profile confirmed	[24]

Detailed Methodological Protocol for Tenoxicam Analysis

The following step-by-step protocol for tenoxicam analysis illustrates the practical implementation of green HPTLC principles:

Materials and Reagents:

• Tenoxicam standard and pharmaceutical formulations
• Ethanol, water, ammonia solution (green solvents)
• HPTLC silica gel plates
• CAMAG HPTLC system including automatic sampler, developing chamber, and TLC scanner

Methodology:

• Standard Solution Preparation: Dissolve tenoxicam standard in ethanol/water/ammonia solution (50:45:5 v/v/v) to obtain concentration range of 25–1400 ng/band
• Sample Preparation: Extract tenoxicam from commercial tablets and capsules using green solvents
• Application: Spot samples as 6 mm bands on HPTLC plates using automatic sampler
• Chromatographic Development: Develop plates in automatic developing chamber saturated with mobile phase vapor for 30 minutes at 22°C
• Detection: Quantify at wavelength of 375 nm using TLC scanner
• Validation: Validate method for linearity, accuracy, precision, robustness, and sensitivity per ICH Q2(R1) guidelines [16]

System Suitability Parameters:

• Retention factor (Rf): 0.85 ± 0.01
• Asymmetry factor (As): 1.07 ± 0.02
• Theoretical plates per meter (N/m): 4971 ± 3.13 [16]

This method demonstrates excellent performance while utilizing environmentally preferable solvents, achieving an AGREE score of 0.75, confirming its outstanding greenness profile [16].

The Scientist's Toolkit: Essential Research Reagent Solutions

Table 3: Essential Materials and Reagents for Green HPTLC Research

Item	Function/Application	Green Considerations
Silica gel 60 F254 plates	Standard stationary phase for HPTLC	Reusable with proper cleaning protocols
Reverse-phase silica gel plates	For hydrophobic compound separation	Extended lifespan with appropriate mobile phases
Ethanol-water mobile phases	Green solvent system	Replaces more hazardous solvents like methanol or acetonitrile
Automatic Developing Chamber	Controlled chromatographic development	Minimizes solvent vapor exposure; ensures reproducibility
TLC Scanner with winCATS software	Densitometric quantification	Enables precise measurement without additional derivatization
Ethyl acetate-methanol mixtures	Alternative green mobile phase	Lower toxicity compared to chlorinated solvents
CAMAG Automatic Sampler (ATS4)	Precise sample application	Reduces human error and exposure to hazardous materials

Advanced "HPTLC+" Platforms and Future Directions

Multimodal HPTLC Integration

The evolution of HPTLC into versatile "HPTLC+" platforms represents the cutting edge of green analytical technology. These advanced systems integrate HPTLC with complementary detection techniques, creating multimodal analytical tools with enhanced capabilities:

• HPTLC-MS (Mass Spectrometry): Provides structural identification and trace quantification capabilities [12]
• HPTLC-SERS (Surface-Enhanced Raman Spectroscopy): Enables molecular fingerprinting for enhanced selectivity [12]
• HPTLC-NIR (Near-Infrared Spectroscopy): Facilitates non-destructive compositional profiling [12]
• HPTLC-bioautography: Allows function-directed screening of biological activity [12]

These integrated approaches maintain the green advantages of HPTLC while significantly expanding analytical capabilities. For instance, HPTLC-MS combined with convolutional neural networks (CNNs) is evolving into intelligent analysis systems capable of automated spot recognition, improving data processing efficiency while reducing human errors [12].

Material-Enabled Enhancements

The incorporation of functional nanomaterials represents another advancement in HPTLC technology. Metal-organic frameworks (MOFs) have shown particular promise when used to modify HPTLC plates, facilitating selective analyte enrichment and enhancing detection sensitivity for trace-level contaminants in complex matrices [12]. These material innovations align with green chemistry principles by improving method sensitivity without significantly increasing environmental impact.

Regulatory Compliance and Strategic Implementation

Framework for Method Transition

Laboratories transitioning to greener HPTLC methods should implement a systematic approach:

• Evaluate current methods using AGREE or GAPI metrics to establish baseline environmental impact
• Identify replacement green solvents using established solvent selection guides
• Validate new methods according to ICH Q2(R1) guidelines while incorporating greenness assessment
• Document environmental benefits using standardized metrics for regulatory submissions
• Implement monitoring systems to track sustainability improvements over time

Addressing the "Rebound Effect"

A critical consideration in implementing green analytical methods is the "rebound effect" - where efficiency gains lead to increased consumption, potentially offsetting environmental benefits [10]. For example, a novel, low-cost microextraction method might lead laboratories to perform significantly more extractions than before, increasing the total volume of chemicals used and waste generated [10]. Mitigation strategies include:

• Optimizing testing protocols to avoid redundant analyses
• Using predictive analytics to identify when tests are truly necessary
• Implementing smart data management systems
• Incorporating sustainability checkpoints into standard operating procedures
• Training personnel on the implications of the rebound effect [10]

Regulatory trends and standards are increasingly influencing green method development in HPTLC, driven by international initiatives such as the WHO's proposed HPTLC chapter, the widespread adoption of compendial methods, and the development of standardized greenness assessment metrics. The fundamental advantages of HPTLC - including minimal solvent consumption, low energy requirements, and parallel processing capabilities - position it as a cornerstone technique for sustainable analytical chemistry. By adopting the methodologies, assessment tools, and implementation strategies outlined in this guide, researchers and drug development professionals can successfully navigate the evolving regulatory landscape while advancing the principles of green chemistry in their HPTLC research. The continued development of "HPTLC+" platforms and nanomaterial-enhanced methodologies promises to further expand the capabilities of this versatile technique while maintaining its alignment with sustainability goals.

Green HPTLC Development Workflow

Practical Green Techniques and Workflow Integration

The adoption of greener solvents in High-Performance Thin-Layer Chromatography (HPTLC) is a critical advancement aligned with the principles of Green Analytical Chemistry (GAC). This transition responds to the significant environmental, health, and safety concerns associated with traditional organic solvents, which have historically dominated chromatographic methods. The pharmaceutical industry, in particular, faces substantial challenges as solvents can account for 80-90% of the total mass used in active pharmaceutical ingredient (API) production, most of which ends up as waste [25]. This solvent consumption contributes significantly to the life cycle impacts of pharmaceutical analysis and manufacturing.

The hazards of conventional solvents are well-documented. Solvents like dichloromethane (DCM) are classified as high-hazard substances, with the Environmental Protection Agency (EPA) associating them with serious health problems including cancer and damage to the central nervous system [25]. Furthermore, these solvents persist in the environment, with DCM having a half-life in water of more than 18 months [25]. The occupational risks are equally concerning, as exposure to these solvents can lead to neurological toxicity, reproductive system damage, organ damage, respiratory impairment, and dermatitis [26].

Within the context of greener sample preparation for HPTLC research, solvent selection represents a fundamental opportunity to reduce the environmental footprint of analytical methods while maintaining, and in some cases enhancing, analytical performance. This guide provides a comprehensive technical framework for identifying, evaluating, and implementing safer solvent alternatives in HPTLC methodologies, supporting the pharmaceutical industry's transition toward more sustainable practices.

Hazard Assessment of Common Chromatographic Solvents

A critical first step in solvent replacement is understanding the specific hazards associated with traditional solvents used in HPTLC. These solvents are typically categorized based on their toxicity profiles, with Class I solvents being the most hazardous and Class III representing lower risk options.

Table 1: Hazard Classification of Common Organic Solvents

Class I (High Hazard)	Class II (Moderate Hazard)	Class III (Lower Hazard)
Benzene [26]	Acetonitrile [26]	Acetic acid [26]
Carbon tetrachloride [26]	Chloroform [26]	Acetone [26]
1,2-Dichloroethane [26]	Pyridine [26]	Butanol [26]
1,1,1-Trichloroethane [26]	Hexane [26]	Ethanol [26]
Dichloromethane (DCM) [25]	Methanol [26]	Ethyl Acetate [25]

Dichloromethane (DCM) deserves special attention due to its widespread use in chromatography and significant associated risks. The GreenScreen assessment assigns DCM a Benchmark score of 1 (BM-1), designating it as a "chemical of high concern that should be avoided" [25]. Similarly, the GlaxoSmithKline (GSK) solvent selection guide rates DCM a 4 on a scale of 1-10, where 1 is of highest concern [25]. Replacing DCM and other high-hazard solvents is therefore a priority for developing greener HPTLC methods.

Safer Alternative Solvents and Blends for HPTLC

Extensive research has identified several safer solvent alternatives that provide effective chromatographic performance while significantly reducing environmental and health impacts. These solvents can be used as direct replacements or in optimized blends to achieve desired separation properties.

Promising Green Solvent Blends

Table 2: Safer Solvent Blends for HPTLC Applications

Safer Solvent Blend	Traditional Blend Being Replaced	Reported Applications	Key Advantages
Heptane/Ethyl Acetate [25]	DCM/Methanol [25]	API purification, separation of ibuprofen, acetaminophen, caffeine [25]	Better EHS profile, high API recovery and purity [25]
Heptane/Methyl Acetate [25]	DCM/Methanol [25]	API purification [25]	Safer profile, good separation efficiency [25]
Ethyl Acetate-Ethanol (7:3, v/v) [27]	Traditional toxic solvent systems	Simultaneous quantification of bisoprolol, amlodipine, and mutagenic impurity [27]	Eco-friendly, baseline separation of complex mixtures [27]
n-Butanol:Ethyl Acetate [17]	Traditional normal-phase solvents	Analysis of sorafenib in bulk and formulations [17]	Green profile, compact spots (Rf 0.7 ± 0.2) [17]
Water-Ethanol (70:30, v/v) [28]	Reversed-phase toxic solvents	Estimation of ascorbic acid in plant extracts [28]	Excellent greenness index (0.88), safe and sustainable [28]
Dichloromethane-Acetone (8.5:1.5, v/v) [18]	-	Quantification of remdesivir, linezolid, rivaroxaban [18]	Effective for spiked human plasma analysis [18]

The greenness of these alternative solvents is confirmed through comprehensive assessment tools. For instance, the HPTLC method using ethyl acetate-ethanol achieved perfect scores on multiple green metrics: NEMI, AGREE, and ComplexGAPI, with high GEMAM indices (7.015) and minimal carbon footprints (0.037 kg CO₂/sample) [27].

Emerging Green Solvent Technologies

Beyond conventional replacements, several innovative solvent technologies are emerging:

Micellar Liquid Chromatography (MLC): This approach uses surfactants like sodium dodecyl sulfate (SDS) above their critical micelle concentration to create micellar mobile phases. These systems offer reduced organic solvent consumption and improved safety profiles while maintaining separation efficiency [29]. The biodegradable nature of many biosurfactants aligns well with green chemistry principles [29].

Natural Deep Eutectic Solvents (NADES): These solvents, typically composed of natural compounds like choline chloride and urea, offer biodegradability and low toxicity while providing excellent extraction and separation capabilities for natural products [11].

Supercritical Fluid Chromatography (SFC): Utilizing carbon dioxide as the primary mobile phase component, SFC dramatically reduces organic solvent consumption. Though more common in column chromatography, the principles are adaptable to planar chromatography development [11].

Experimental Protocols for Solvent Evaluation and Implementation

Transitioning to greener solvents requires systematic evaluation to ensure analytical performance is maintained or enhanced. The following protocols provide detailed methodologies for assessing and implementing alternative solvent systems.

Protocol 1: Thin-Layer Chromatography Screening for Solvent Replacement

Purpose: To rapidly screen potential green solvent blends as replacements for hazardous solvent systems in HPTLC method development.

Materials and Equipment:

• TLC silica gel 60 F₂₅₄ plates (e.g., Merck, 20 × 20 cm) [25]
• Ultraviolet lamp (254 nm) for visualization [25]
• Capillary tubes for sample application [25]
• Developing chamber with saturation pad [25]
• Model analytes (e.g., APIs, impurities relevant to your application) [25]

Procedure:

• Cut TLC plates to appropriate size (e.g., 4 × 10 cm) and mark origin and solvent front lines [25].
• Prepare solutions of model compounds (typically 3 mg/mL in a volatile solvent like acetone) [25].
• Spot samples approximately 1 cm apart on the origin line [25].
• Prepare candidate green solvent blends (e.g., heptane/ethyl acetate, heptane/methyl acetate) in varying ratios [25].
• Develop chromatograms in chambers pre-saturated with mobile phase vapor for 15-30 minutes [27] [28].
• Document migration distances and calculate retention factors (Rf) for each compound.
• Compare separation efficiency, spot compactness, and resolution to traditional solvent systems.
• Select the most promising green solvent blend that provides comparable or superior separation to the hazardous system being replaced.

Protocol 2: Comprehensive Greenness Assessment of HPTLC Methods

Purpose: To quantitatively evaluate the environmental sustainability of new HPTLC methods using multiple assessment tools.

Materials and Equipment:

• Developed HPTLC method with complete operational details
• AGREE (Analytical GREEnness) assessment software [17] [28]
• GAPI (Green Analytical Procedure Index) tool [18]
• NEMI (National Environmental Methods Index) tool [27]

Procedure:

• Document all method parameters including solvent types and volumes, energy consumption, waste generation, and operator safety considerations [27].
• AGREE Assessment: Input all twelve principles of green analytical chemistry into the AGREE calculator, which generates a score from 0-1 (with 1 being ideal) [17] [28]. For example, the water-ethanol HPTLC method for ascorbic acid estimation achieved an excellent AGREE score of 0.88 [28].
• GAPI Evaluation: Complete the GAPI pictogram which assesses environmental impact across the entire method lifecycle [18].
• NEMI Assessment: Apply the NEMI criteria to determine if the method meets basic green chemistry principles [27].
• Calculate Carbon Footprint: Estimate the kg CO₂ generated per sample based on solvent production and waste treatment [27]. The ethyl acetate-ethanol HPTLC method demonstrated a minimal carbon footprint of 0.037 kg CO₂/sample [27].
• Compare sustainability metrics against traditional methods to quantify environmental improvements.

The Scientist's Toolkit: Essential Research Reagent Solutions

Table 3: Key Reagents and Materials for Green HPTLC Method Development

Reagent/Material	Function in Green HPTLC	Examples & Alternatives
Ethyl Acetate [27] [25]	Polar organic solvent in normal-phase separations	Safer alternative to DCM or chloroform in blending with heptane [25]
Ethanol [28]	Polar solvent for reversed-phase systems	Replaces acetonitrile or methanol in water-ethanol blends [28]
Heptane [25]	Non-polar solvent for normal-phase chromatography	GreenScreen rating of BM-2, significantly better than DCM's BM-1 [25]
Water [28]	Primary solvent in reversed-phase systems	Minimal toxicity and environmental impact [28]
Sodium Dodecyl Sulfate (SDS) [29]	Surfactant for micellar liquid chromatography	Enables reduced organic solvent consumption [29]
Silica Gel 60 F₂₅₄ Plates [27] [18]	Stationary phase for HPTLC	Standard adsorbent compatible with greener solvent systems [27]

Method Development Workflow and Sustainability Assessment

The transition to greener HPTLC methods follows a logical pathway from hazard assessment to implementation and validation. The diagram below illustrates this workflow, integrating both analytical performance and sustainability considerations.

Green HPTLC Solvent Selection Workflow

This systematic approach ensures that both chromatographic performance and sustainability objectives are met throughout method development.

The transition to greener solvents in HPTLC represents a significant opportunity to align pharmaceutical analysis with the principles of sustainable development. The solvent alternatives and methodologies presented in this guide demonstrate that effective chromatographic separation need not come at the expense of environmental and human health. By adopting ethyl acetate, ethanol, water-based systems, and other safer solvent blends, researchers can develop HPTLC methods that maintain analytical performance while reducing hazardous waste, minimizing carbon footprint, and enhancing laboratory safety.

The comprehensive sustainability assessments now available provide quantitative metrics to validate these improvements, with tools like AGREE, GAPI, and ComplexGAPI offering standardized evaluation criteria. As the field continues to evolve, emerging technologies including micellar liquid chromatography and natural deep eutectic solvents promise even greener alternatives for the future. Through the systematic application of these principles and methodologies, researchers can contribute to a more sustainable paradigm in pharmaceutical analysis that aligns with global initiatives for responsible consumption and production.

The growing emphasis on sustainability has made miniaturization a cornerstone of Green Analytical Chemistry (GAC), particularly in High-Performance Thin Layer Chromatography (HPTLC) research. Miniaturization strategies systematically reduce the consumption of samples, solvents, and reagents while maintaining or enhancing analytical performance [30] [31]. These approaches align with the core principles of green chemistry by minimizing waste generation, reducing energy demands, and decreasing operator exposure to hazardous chemicals [10].

Within HPTLC methodologies, miniaturization delivers specific technical advantages that extend beyond environmental benefits. The reduction in solvent volumes and sample sizes leads to improved separation efficiency through the formation of narrower application bands and more compact diffusion zones [32] [33]. This guide examines current miniaturized techniques, their implementation in HPTLC workflows, and their role in advancing sustainable pharmaceutical and environmental analysis.

Core Miniaturization Concepts and Technical Advantages

Fundamental Principles and Environmental Impact

Miniaturization in HPTLC and related sample preparation techniques operates on several interconnected principles that drive both environmental and analytical benefits:

• Reduced Capillary Action Requirements: Miniaturized HPTLC plates with shorter development distances (3-6 cm versus 10-15 cm in conventional TLC) require significantly less mobile phase volume while achieving comparable separation efficiency due to finer stationary phase particles (4-8 μm) [33].
• Enhanced Mass Transfer: Miniaturized sample preparation techniques utilize assisted strategies such as vortex mixing, ultrasound, and microwave energy to accelerate mass transfer during extraction, dramatically reducing both extraction time and energy consumption compared to traditional methods like Soxhlet extraction [10].
• Parallel Processing Capability: HPTLC's inherent ability to process multiple samples simultaneously on a single plate significantly increases throughput while maintaining minimal solvent consumption per sample [32] [33].

Quantitative Environmental Benefits

The implementation of miniaturization strategies generates measurable reductions in environmental impact and operational costs, as demonstrated in the table below.

Table 1: Environmental and Economic Benefits of Miniaturized HPTLC Versus Conventional Methods

Parameter	Conventional TLC/HPLC	Miniaturized HPTLC	Reduction Percentage
Sample Volume	1-10 μL	0.1-1 μL	70-90% [33]
Mobile Phase Consumption	50-100 mL per run	5-15 mL per run	70-90% [32]
Development Distance	10-15 cm	3-6 cm	60-80% [33]
Analysis Time	30-60 minutes	10-30 minutes	50-70% [32]
Waste Generation	50-100 mL per run	5-15 mL per run	70-90% [30]
Number of Samples per Run	1 (HPLC) / 5-10 (TLC)	10-20 (HPTLC)	100-300% increase [33]

The data demonstrates that miniaturization in HPTLC and related techniques achieves dramatic reductions in resource consumption while simultaneously enhancing analytical throughput. These improvements directly support the principles of Green Analytical Chemistry and contribute to more sustainable laboratory practices.

Miniaturized Sample Preparation Techniques for HPTLC

Effective sample preparation is crucial for successful HPTLC analysis, and miniaturized techniques in this area provide significant environmental advantages while improving analytical performance.

Liquid-Phase Microextraction (LPME)

Liquid-Phase Microextraction encompasses several miniaturized approaches that use minimal solvent volumes for efficient analyte extraction and preconcentration:

• Single-Drop Microextraction (SDME): Utilizes a single suspended microdrop of organic solvent (typically 1-3 μL) exposed to the sample solution for analyte extraction, achieving high enrichment factors through the large sample-to-acceptor phase volume ratio [30].
• Hollow Fiber-Liquid Phase Microextraction (HF-LPME): Employs a porous hollow fiber membrane filled with organic solvent that protects the acceptor phase and enables efficient extraction from complex samples with exceptional clean-up capabilities [30].
• Dispersive Liquid-Liquid Microextraction (DLLME): Based on a cloudy solution formed when a water-immiscible extraction solvent is dispersed in an aqueous sample solution using a disperser solvent, enabling rapid extraction due to the large surface area between the extraction solvent and aqueous phase [31].

These LPME techniques typically consume less than 100 μL of organic solvent per extraction, compared to hundreds of milliliters in traditional liquid-liquid extraction, while providing excellent analyte enrichment and sample clean-up for subsequent HPTLC analysis [30].

Solid-Phase Microextraction (SPME)

Solid-Phase Microextraction utilizes a fused silica fiber coated with a stationary phase for extracting analytes from sample headspace or direct immersion:

• Fiber SPME: A reusable fiber with various coating chemistries (PDMS, PA, CAR/PDMS) is exposed to the sample, then thermally desorbed or eluted with minimal solvent for HPTLC application [31].
• Thin-Film Microextraction (TF-SPME): Utilizes a larger surface area thin film instead of a fiber, providing higher extraction capacity and faster extraction kinetics while maintaining the solventless principle [30].

SPME techniques are particularly valuable for HPTLC analysis as they can be directly coupled with application devices by solvent-assisted desorption, enabling complete elimination of solvent consumption during sample preparation when thermal desorption is not feasible [31].

Miniaturized Homogenization and Extraction

For solid samples, miniaturized homogenization and extraction techniques provide efficient analyte recovery with minimal solvent consumption:

• Microscale Ultrasound-Assisted Extraction (μ-UAE): Utilizes ultrasonic energy with solvent volumes under 1 mL to enhance mass transfer and extraction efficiency from solid samples, achieving comparable or better recovery than conventional macroscale UAE [30].
• Vortex-Assisted Extraction: Employs vigorous vortex mixing with small solvent volumes (500 μL - 2 mL) and reduced extraction times for efficient analyte recovery from various sample matrices [10].

Table 2: Comparison of Miniaturized Sample Preparation Techniques for HPTLC Analysis

Technique	Typical Solvent Volume	Extraction Time	Enrichment Factor	Compatibility with HPTLC
SDME	1-3 μL	10-30 minutes	50-200	Excellent (minimal solvent)
HF-LPME	10-25 μL	20-40 minutes	100-500	Excellent (good clean-up)
DLLME	50-100 μL	<5 minutes	100-300	Good (requires optimization)
SPME	0-50 μL (for desorption)	15-60 minutes	50-1000	Excellent (solventless option)
μ-UAE	0.5-2 mL	5-15 minutes	N/A	Good (may need concentration)

Implementation in HPTLC Methodology

Miniaturized HPTLC Plate Design and Development

The fundamental design of HPTLC plates incorporates miniaturization at multiple levels, contributing to reduced solvent consumption and improved performance:

• Stationary Phase Optimization: HPTLC plates utilize finer stationary phase particles (4-8 μm) with more uniform size distribution compared to conventional TLC (5-20 μm), enabling shorter development distances with maintained resolution [33].
• Miniaturized Development Chambers: Specialized chambers such as the Automatic Developing Chamber (ADC) enable standardized miniaturized development with controlled saturation, developing distance, and drying parameters, ensuring reproducible results with minimal solvent consumption [33].
• Horizontal Development Configuration: Development from both opposing sides toward the middle on 10×10 cm or 20×10 cm plates effectively doubles the number of samples processed per unit volume of mobile phase [33].

Experimental Protocol: Miniaturized HPTLC Analysis of Pharmaceutical Compounds

The following detailed protocol for simultaneous determination of ivabradine and metoprolol demonstrates the practical implementation of miniaturization strategies in HPTLC [32]:

Materials and Instrumentation:

• HPTLC silica gel 60 F254 plates (10×10 cm, 0.20 mm thickness)
• CAMAG Linomat 5 autosampler with 100 μL syringe
• CAMAG twin trough glass chamber (10×10 cm)
• CAMAG TLC Scanner 3 with winCATS software
• Chloroform, methanol, formic acid, ammonia (all HPLC grade)
• Standard solutions of ivabradine and metoprolol (100 μg/mL in methanol)

Sample Application:

• Pre-wash plates with methanol using ascending development to remove impurities
• Activate plates at 110-120°C for 30 minutes prior to application
• Apply samples as 4 mm bands using Linomat 5 autosampler:
  • Distance from bottom: 10 mm
  • Distance from edge: 10 mm
  • Application volume: 0.18-9.0 μL (18-900 ng/band for ivabradine, 50-900 ng/band for metoprolol)
  • Nitrogen aspirator pressure: 10 sec delivery time per μL

Chromatographic Development:

• Mobile phase: chloroform:methanol:formic acid:ammonia (8.5:1.5:0.2:0.1, v/v)
• Chamber saturation: 30 minutes at ambient temperature
• Development distance: 80 mm
• Development time: approximately 10 minutes
• Drying: ambient temperature for 5 minutes

Detection and Quantification:

• UV absorbance detection at λ = 275 nm for both compounds
• Fluorescence detection with excitation at 260 nm using optical filter K320
• Densitometric scanning with slit dimensions 3.0×0.45 mm
• Scanning speed: 20 mm/s
• Quantification via peak area against calibration curves

This protocol exemplifies miniaturization through reduced mobile phase volume (typically 5-10 mL per development), miniaturized sample application (nanogram quantities), and short analysis time (approximately 45 minutes total including preparation, development, and scanning) [32].

Green Solvent Alternatives in Miniaturized HPTLC

The integration of green solvents with miniaturized HPTLC methods further enhances environmental sustainability:

• Natural Deep Eutectic Solvents (NADES): Emerging as biodegradable, low-toxicity alternatives for extraction and sample preparation, with potential application as mobile phase modifiers in HPTLC [11].
• Ethanol-Water Mixtures: Replacement of more toxic acetonitrile with ethanol-water mixtures in reversed-phase HPTLC applications, maintaining separation efficiency while reducing environmental impact [34].
• Solvent-Free Sample Application: Implementation of thermal desorption techniques for direct transfer of SPME-extracted analytes to HPTLC plates, eliminating solvent consumption in the application step [30].

Automation and Integration Strategies

Automation plays a crucial role in maximizing the benefits of miniaturized HPTLC systems by improving reproducibility, throughput, and operational safety:

• Automated Sample Application: Computer-controlled autosamplers like the CAMAG Linomat series enable precise application of nanoliter volumes as narrow bands, critical for achieving high resolution in miniaturized separations [33].
• Standardized Development: Automated developing chambers control chamber saturation, development distance, and drying parameters, reducing variability and operator intervention while optimizing mobile phase consumption [33].
• Integrated Analysis Systems: Modern HPTLC scanners with densitometry capabilities provide automated quantification at multiple wavelengths with minimal sample requirement, enabling detection in the nanogram range [32] [33].

The synergy between automation and miniaturization creates analytical systems that not only reduce environmental impact but also enhance analytical performance and operational efficiency, addressing all three pillars of sustainability: environmental, economic, and social [10].

The Scientist's Toolkit: Essential Research Reagents and Materials

Successful implementation of miniaturized HPTLC requires specific materials and reagents optimized for reduced consumption and enhanced performance.

Table 3: Essential Research Reagent Solutions for Miniaturized HPTLC

Item	Specification	Function in Miniaturized HPTLC
HPTLC Plates	Silica gel 60 F254, 10×10 cm or 5×7.5 cm, particle size 4-8 μm	Miniaturized separation platform with uniform layer thickness for reproducible migration
Stationary Phases	C8, C18, silica gel, cyano, amino, diol phases	Selective separation mechanisms for different analyte classes in miniaturized formats
Green Solvents	Methanol, ethanol, acetone, ethyl acetate, NADES	Reduced toxicity mobile phase components with maintained separation efficiency
Sample Application Syringe	100 μL precision syringe with automated control	Accurate delivery of nanoliter volumes as narrow bands for high-resolution separation
Microextraction Devices	SPME fibers, hollow fibers, microextraction capsules	Solvent-free or minimal solvent sample preparation and analyte enrichment
Derivatization Reagents	Primuline, anisaldehyde, ninhydrin in miniature sprayers	Targeted compound visualization with minimal reagent consumption
Densitometry Standards	Certified reference materials in miniature ampules	Quantitative calibration with minimal standard consumption and waste generation

Workflow Visualization and Strategic Implementation

The integration of miniaturization strategies throughout the HPTLC analytical process creates a comprehensive green analytical workflow, as visualized in the following diagram:

Figure 1: Integrated workflow for miniaturized HPTLC analysis highlighting key green benefits.

Miniaturization strategies represent a fundamental shift toward sustainable HPTLC research that aligns with the principles of Green Analytical Chemistry. The systematic reduction of sample and solvent volumes through microextraction techniques, miniaturized HPTLC platforms, and automated workflows achieves dramatic reductions in environmental impact while maintaining or enhancing analytical performance.

Future developments in miniaturized HPTLC will likely focus on increased integration with complementary techniques, further automation, and the adoption of novel green solvents. The successful implementation of these strategies requires continued collaboration between researchers, instrument manufacturers, and regulatory bodies to establish standardized methodologies that prioritize sustainability without compromising analytical quality [10]. As miniaturization technologies mature and become more widely adopted, they will play an increasingly vital role in advancing sustainable analytical practices across pharmaceutical, environmental, and biomedical research fields.

The growing emphasis on Green Analytical Chemistry (GAC) has fundamentally transformed pharmaceutical analysis, driving the adoption of techniques that align environmental sustainability with analytical excellence. High-Performance Thin-Layer Chromatography (HPTLC) has emerged as a frontrunner in this movement, offering inherent green advantages through minimal solvent consumption, reduced energy requirements, and low waste generation [35] [12]. The core principles of GAC emphasize waste prevention, the use of safer solvents, and energy efficiency throughout the analytical workflow. Automated and semi-automated sample preparation represents a critical advancement in optimizing both the environmental profile and analytical performance of HPTLC methods [12]. Modern HPTLC systems embody these principles by integrating sophisticated instrumentation that enhances reproducibility while significantly reducing the consumption of solvents and samples [36] [37]. This technical guide examines how automated sample preparation technologies enhance precision and green metrics within HPTLC workflows, providing researchers with practical methodologies to implement these advances in pharmaceutical and biomedical research.

Green Metrics and Assessment Tools for HPTLC Methods

Established Greenness Assessment Frameworks

Objective evaluation of method environmental impact requires standardized metrics. Several validated tools have been developed to quantify the greenness of analytical procedures, including HPTLC methods [35] [6]:

• AGREE (Analytical GREEnness Metric): Provides a comprehensive 0-1 scoring system based on all 12 GAC principles, offering a holistic environmental assessment [13] [6].
• NEMI (National Environmental Methods Index): Uses a simple pictogram to indicate whether a method meets criteria for persistent, bioaccumulative, and toxic chemicals, and corrosivity [6].
• Analytical Eco-Scale: Assigns penalty points to problematic methodological aspects, with higher scores indicating greener methods [6] [18].
• GAPI (Green Analytical Procedure Index): Employs a colored pictogram to evaluate environmental impact across the method's entire lifecycle [35].

Quantitative Greenness Assessments of HPTLC Methods

Recent pharmaceutical applications demonstrate the superior green profile of HPTLC methods when assessed with these metrics:

Table 1: Green Metric Scores of Recent HPTLC Pharmaceutical Applications

Analytical Target	Method Type	Green Metric Tool	Score	Reference
Sorafenib	RP-HPTLC	AGREE	0.83	[13]
Sorafenib	NP-HPTLC	AGREE	0.82	[13]
Sorafenib	RP-HPTLC	AGREEprep	0.77	[13]
Sorafenib	NP-HPTLC	AGREEprep	0.73	[13]
Ertugliflozin	RP-HPTLC	AGREE	>0.80*	[6]
Ertugliflozin	NP-HPTLC	AGREE	<0.80*	[6]
Remdesivir with co-drugs	HPTLC	Analytical Eco-Scale	High Score	[18]
Florfenicol & Meloxicam	HPTLC	Multiple Tools	Confirmed Green	[14]

*Scores approximated from comparative data in source publication.

These quantitative assessments confirm that HPTLC methods consistently achieve high greenness ratings, particularly when incorporating automated technologies and greener solvent systems [13] [6]. The AGREE scores specifically reflect adherence to GAC principles, with methods scoring above 0.80 considered exceptionally green.

Automated HPTLC Instrumentation for Green Sample Preparation

Sample Application Systems

Automated sample application represents the first critical step in minimizing environmental impact while enhancing precision:

• CAMAG Automatic TLC Sampler 4 (ATS 4): Enables fully automatic sample application for both qualitative and quantitative analyses. This system precisely controls application parameters, reducing solvent consumption by ensuring optimal band lengths and positions without manual error [37].
• CAMAG Linomat 5: Provides semi-automatic application with spray-on capability using nitrogen or compressed air. This technology allows reproducible sample application as bands or spots, significantly reducing sample volume requirements compared to manual techniques [37].

The transition from manual capillary application to automated spray-on systems has demonstrated remarkable improvements in data quality while reducing solvent consumption by up to 50% through precise volumetric control [37] [38].

Automated Development and Derivatization

• CAMAG Automatic Developing Chamber 3 (ADC 3): Provides fully automated chromatogram development with integrated humidity control, ensuring maximum reproducibility while minimizing solvent vapor exposure to laboratory personnel [37].
• CAMAG Derivatizer: Enables automated reagent transfer using patented "micro droplet" spraying technology. This closed system reduces reagent consumption to 2-4 mL per plate while providing unsurpassed homogeneous reagent distribution, enhancing both safety and data quality [37].

Detection and Quantification Systems

• CAMAG TLC Scanner 4: Permits advanced densitometric evaluation with measurement of reflection in absorbance and/or fluorescence modes. This non-destructive detection approach aligns with green principles by enabling multiple detections on a single plate [37].
• CAMAG TLC Visualizer 3: Provides high-end imaging and documentation with maximum illumination homogeneity, facilitating image-based evaluation without additional chemical modification [37].

Experimental Protocols for Green HPTLC Analysis

Method for Anticancer Drug Analysis (Sorafenib)

Experimental Protocol from Bhatt et al. (2025) [13]:

• Sample Preparation: Bulk drug substance or formulation homogenized in appropriate solvent followed by filtration (0.45 μm membrane). For RP-HPTLC, samples were prepared in ethanol-water mixtures; for NP-HPTLC, chloroform-methanol mixtures were employed.
• Chromatographic Conditions:
  • Stationary Phase: Silica gel 60 F254S plates (RP-18 for reversed-phase, unmodified for normal-phase)
  • Mobile Phase: RP-HPTLC: isopropanol:water:glacial acetic acid; NP-HPTLC: n-butanol:ethyl acetate
  • Application: Automated application of 200-1200 ng/spot using Linomat 5
  • Detection: Densitometric scanning at 265 nm
• Green Metrics: AGREE scores of 0.83 (RP-HPTLC) and 0.82 (NP-HPTLC) demonstrated excellent environmental performance.

Method for COVID-19 Therapeutic Panel

Experimental Protocol for Remdesivir, Linezolid, and Rivaroxaban [18]:

• Sample Preparation: Plasma samples underwent protein precipitation with methanol followed by centrifugation and filtration. Minimal sample volumes (100-200 μL) were utilized.
• Chromatographic Conditions:
  • Stationary Phase: TLC silica gel 60 F254 aluminum plates
  • Mobile Phase: Dichloromethane:acetone (8.5:1.5, v/v)
  • Application: Automated application of bands 1.0 cm from bottom edge using Linomat 5
  • Detection: Densitometric detection at 254 nm
• Green Metrics: Assessed using Analytical Eco-Scale, GAPI, and AGREE metrics, confirming outstanding greenness profile.

Method for Veterinary Drug Residue Analysis

Experimental Protocol for Florfenicol and Meloxicam [14]:

• Sample Preparation: Bovine muscle tissue homogenized with EDTA solution, followed by extraction with methanol and filtration (0.45 μm nylon membrane).
• Chromatographic Conditions:
  • Stationary Phase: Aluminum HPTLC plates coated with silica gel 60 F254
  • Mobile Phase: Glacial acetic acid:methanol:triethylamine:ethyl acetate (0.05:1.00:0.10:9.00, by volume)
  • Internal Standard: Esomeprazole to compensate for potential fluctuations
  • Detection: Densitometric detection at 230 nm
• Green Metrics: Evaluated using five different greenness assessment tools, confirming eco-friendly nature.

The Scientist's Toolkit: Essential Research Reagent Solutions

Table 2: Key Research Reagent Solutions for Green HPTLC Analysis

Item	Function	Green Consideration
Silica gel 60 F254 plates	Stationary phase for separation	Reusable for multiple detections, minimal waste generation
Ethanol-water mobile phases	Environmentally benign solvent system	Replaces toxic acetonitrile, biodegradable [6]
Automated developing chamber	Reproducible mobile phase migration	Minimizes solvent vapor exposure, ensures optimal solvent volumes [37]
Micro-droplet derivatization	Automated reagent application	Reduces reagent consumption to 2-4 mL [37]
Hyperspectral imaging	Multiple detection without additional chemicals	Non-destructive analysis enables further testing [36]
HPTLC-MS interface	Direct mass spectrometric analysis	Enables structural confirmation without additional separation [37]

Integrated Workflow for Automated Green HPTLC Analysis

The following workflow diagram illustrates the integrated process of automated green HPTLC analysis, highlighting the reduction of environmental impact at each stage:

Automated and semi-automated sample preparation technologies have fundamentally enhanced both the precision and green metrics of HPTLC analysis. Through standardized instrumentation, reduced solvent consumption, minimized waste generation, and improved reproducibility, these approaches align analytical excellence with environmental responsibility. The quantitative greenness assessments using AGREE, Analytical Eco-Scale, and other metrics provide validated evidence of HPTLC's superior sustainability profile compared to conventional chromatographic techniques. As green chemistry principles continue to influence analytical science, the integration of automated HPTLC systems with multimodal detection platforms represents a powerful strategy for pharmaceutical and clinical researchers seeking to minimize their environmental footprint while maintaining rigorous analytical standards.

The integration of Green Analytical Chemistry (GAC) principles into sample preparation is revolutionizing how researchers handle complex matrices in High-Performance Thin-Layer Chromatography (HPTLC). Traditional sample preparation methods often consume significant amounts of hazardous organic solvents, generate substantial waste, and compromise environmental safety [39]. Within the pharmaceutical and natural products industries, the analysis of botanicals, formulations, and biological samples presents particular challenges due to their complex compositions, varying concentrations of target analytes, and numerous interfering components [40]. Greener sample preparation aims to address these challenges while minimizing environmental impact through the use of alternative solvents, reduced solvent consumption, and streamlined procedures.

The drive toward greener methodologies is particularly relevant for HPTLC, a technique prized for its efficiency, reproducibility, and capacity for high-throughput analysis [41]. As a cornerstone of quality assurance in botanical testing, HPTLC enables the simultaneous observation of numerous chemical constituents, providing characteristic fingerprints for identification and quantification [42]. However, the effectiveness of this technique hinges on appropriate sample preparation tailored to the specific matrix. This guide provides an in-depth examination of current greener sample preparation strategies for complex matrices within the framework of HPTLC analysis, featuring detailed protocols, quantitative comparisons, and practical implementation guidelines.

The Challenge of Complex Matrices

Complex matrices in pharmaceutical and natural product research present unique analytical challenges that necessitate specialized sample preparation approaches. Biological samples, including body fluids (blood, saliva, sweat) and solid tissues (hair, organs), contain numerous interfering components, have wide molecular weight distributions, and often contain target analytes at low concentrations amidst a background of highly abundant proteins and lipids [40]. Similarly, botanical materials contain intricate mixtures of secondary metabolites with varying polarities, concentrations, and chemical properties, further complicated by variations based on plant species, plant part used, extraction methods, and geographical sources [42] [41].

Pharmaceutical formulations represent another category of complex matrices where excipients, fillers, stabilizers, and other active ingredients can interfere with the analysis of target compounds. The primary challenges in handling these diverse matrices include the need for selective extraction of target analytes from interfering components, enrichment of low-abundance compounds, preservation of analyte integrity, and maintenance of environmental sustainability throughout the process [39] [40]. Without proper sample preparation, these matrix complexities can lead to inaccurate quantification, reduced method sensitivity, and compromised analytical results in HPTLC analysis.

Matrix-Specific Interferences and Considerations

Table 1: Characteristics and Challenges of Different Complex Matrices in HPTLC Analysis

Matrix Type	Key Characteristics	Major Challenges	Common Interferences
Botanical Materials	Complex phytochemical composition; variable marker compound levels [41]	Inconsistent composition; unknown constituents; varying extractability [42]	Pigments (chlorophylls, carotenoids); tannins; essential oils
Biological Fluids	High protein content; enzymatic activity; low analyte concentrations [40]	Protein binding; complex composition; analyte stability [40]	Proteins; lipids; salts; endogenous metabolites
Pharmaceutical Formulations	Excipients; fillers; multiple active ingredients [43]	Excipient interference; drug-excipient interactions	Binders; disintegrants; lubricants; preservatives

Greener Sample Preparation Strategies

The transition to greener sample preparation methodologies is guided by the Twelve Principles of Green Analytical Chemistry, which emphasize waste reduction, safety, and efficiency [39]. Several effective strategies have emerged that significantly reduce environmental impact while maintaining or even improving analytical performance for HPTLC applications.

Green Solvent Replacement

A fundamental approach to greener sample preparation involves replacing hazardous organic solvents with environmentally benign alternatives. Traditional chromatographic methods often employ substantial quantities of solvents like acetonitrile, methanol, and chlorinated hydrocarbons, generating 1-1.5 liters of waste per day [39]. Green alternatives include ethanol and water, which offer significantly reduced environmental and health impacts. For instance, recent stability-indicating HPTLC methods for flufenamic acid and cordycepin utilized ethanol-water mixtures as the eluent system, demonstrating excellent analytical performance while aligning with green chemistry principles [43] [44].

Alternative Extraction Techniques

Several extraction techniques have been developed or adapted to align with green chemistry principles while effectively handling complex matrices:

Solid Phase Microextraction (SPME) This technique combines extraction and enrichment into a single step while eliminating solvent use entirely. Developed by Arthur and Pawliszyn in 1990, SPME utilizes a silica fiber coated with an appropriate adsorbent phase to directly extract analytes from solution [39]. The efficiency of SPME depends on several factors, including fiber type, sample stirring, and extraction duration. SPME can be coupled with HPTLC, HPLC, GC, and various mass spectrometric detection methods for the isolation of compounds from complex samples, offering advantages of minimal cost, simplicity, eliminated solvent disposal expenses, rapid preparation time, reliability, and sensitivity [39].

QuEChERS (Quick, Easy, Cheap, Effective, Rugged, and Safe) Originally developed for pesticide residue analysis, this approach has found application across various matrix types. The method involves two main stages: solvent extraction with acetonitrile followed by a dispersive solid-phase extraction clean-up using primary secondary amine (PSA) and magnesium sulfate [39]. QuEChERS is considered a green extraction method due to its reduced solvent consumption compared to traditional approaches. Applications include extracting analytes from blood specimens, removing various pollutants from human blood, extracting amphetamine, opiate, and cocaine from blood using LC-MS/MS, and extracting tetrahydrocannabinol (THC) [39].

Solid Phase Extraction (SPE) While a more traditional technique, SPE can be implemented with greener principles by using smaller cartridges, reduced solvent volumes, and more environmentally friendly sorbents. In SPE, solutes are adsorbed onto a short column of compatible solid sorbent, then eluted with minimal amounts of solvent, resulting in analyte enrichment [39]. Modern advancements include the development of improved sorbent materials such as porous organic frameworks, imprinted polymers, and bioactive media, which significantly enhance extraction performance, selectivity, and sensitivity when integrated with techniques like µSPE, MSPE, and on-line analysis [40].

Direct Analytical Approaches

From the perspective of Green Analytical Chemistry, direct analytical techniques that require minimal or no sample preparation are particularly desirable [39]. For liquid samples, direct injection into chromatographic systems may be possible with proper column selection and pre-column protection. Significant improvements in column stationary phase quality and advanced cross-linking strategies have increased resistance to deterioration caused by water, making direct aqueous injection more feasible [39]. The main limitation of these approaches is their restriction to relatively pure matrices free of suspended debris. Direct chromatographic procedures align with green chemistry principles by eliminating the sample preparation stage, thereby reducing solvent usage, energy consumption, and waste generation [39].

Table 2: Comparison of Greener Sample Preparation Techniques for HPTLC Analysis

Technique	Principles	Green Advantages	Limitations	Typical Applications
SPME	Solvent-free extraction using coated fiber [39]	Eliminates solvent use; minimal waste; reusable fibers	Limited fiber types; possible carryover; requires optimization	Volatile and semi-volatile compounds in biological fluids; food analysis
QuEChERS	Salting-out extraction with dispersive SPE clean-up [39]	Reduced solvent volume; faster processing; minimal equipment	May require method adaptation for different matrices	Pesticides in foods; pharmaceuticals in biological matrices; metabolomics
Green SPE	Selective sorption with green elution solvents [39] [40]	Reduced solvent consumption; minimal waste; improved sorbents	Sorbent selection critical; potential channeling	Pre-concentration of analytes from biological fluids; environmental samples

Detailed Methodologies for Different Matrices

Botanical Materials

The analysis of botanical materials requires careful consideration of plant species, plant part, extraction methods, and standardization. The complete chemical composition of botanical products is often largely unknown and may vary widely, making targeted analysis challenging [41]. Effective HPTLC analysis of botanicals depends on providing four key pieces of information: Latin name (genus and species), plant part, extraction solvents and processing methods, and vendor Certificate of Analysis (CoA) or specification document [42].

Ultrasound-Assisted Extraction (UAE) Protocol for Botanical Materials A recent study on Dodonaea angustifolia demonstrates an effective greener extraction approach [45]:

• Sample Preparation: Reduce plant material (leaf or flower) to fine powder.
• Extraction: Weigh appropriate amount of powder and extract with methanol using ultrasound-assisted extraction.
• Filtration: Remove particulate matter through filtration.
• Concentration: If necessary, concentrate under reduced pressure using green solvents.
• HPTLC Analysis: Apply samples to HPTLC plates using automated sample applicator.

The resulting extracts were successfully analyzed using HPTLC for flavonoid and phenolic acid profiles, demonstrating significant antimicrobial activity with MIC values of 20 µg/mL against Enterococcus faecalis and Listeria monocytogenes, and 40 µg/mL against Aspergillus flavus [45].

Critical Considerations for Botanical Analysis

• Species Verification: The Latin name ensures correct species identification, aligning the sample with appropriate pharmacopeial standards and facilitating database searches [42].
• Plant Part Specificity: The chemical makeup varies significantly between different plant parts (leaf, root, seed, bark, flower), directly influencing the type and concentration of compounds present [42].
• Extraction Conditions: The choice of solvent and extraction process determines which compounds are effectively isolated from the matrix, impacting the HPTLC fingerprint [42].

Pharmaceutical Formulations

Pharmaceutical formulations often contain excipients that can interfere with HPTLC analysis, requiring efficient extraction and clean-up procedures. Greener approaches focus on minimizing organic solvent consumption while maintaining extraction efficiency.

Stability-Indicating Greener HPTLC Method for Flufenamic Acid [43] This protocol demonstrates an eco-friendly approach for pharmaceutical analysis:

• Sample Preparation: Weigh and powder tablets. For assay determination, transfer powder equivalent to average tablet weight to volumetric flask.
• Extraction: Add methanol and sonicate to dissolve active ingredient.
• Dilution: Dilute with greener eluent system (ethanol-water, 70:30 v/v).
• Filtration: Filter through Whatman filter paper (No. 41) to remove undissolved excipients.
• HPTLC Analysis: Apply samples to RP-60F254S HPTLC plates using automated applicator.

The method was validated over the range of 25-1400 ng/band with a determination coefficient of 0.9974. The AGREE greenness score was 0.77, indicating outstanding greenness characteristics. The method successfully detected degradation products under forced degradation conditions, demonstrating its stability-indicating capability [43].

Biological Samples

Biological sample preparation has distinct characteristics: it is time-consuming with multiple steps, low-content target substances require effective enrichment, and biomolecules can lose activity outside their physiological environment [40]. There is no universal sample preparation method for biological analysis, with selection depending on required separation and purity levels.

Advanced Media for Biological Sample Preparation Recent advances focus on media that improve extraction performance [40]:

• Porous Organic Frameworks: Highly porous materials with large surface areas and tunable functionality.
• Imprinted Polymers: Synthetic polymers with specific recognition sites for target molecules.
• Bioactive Media: Materials incorporating biological recognition elements.

These media can be integrated with extraction technologies such as solid-phase extraction (SPE), micro-SPE (µSPE), solid-phase microextraction (SPME), and magnetic SPE (MSPE) to significantly improve performance of biological sample preparation [40].

Sample Preparation Workflow for Biological Fluids

• Collection: Collect biological fluid (blood, saliva, urine) in appropriate container.
• Stabilization: Add stabilizers if required for analyte integrity.
• Deproteinization: For blood-based samples, remove proteins using green approaches (e.g., ethanol precipitation).
• Extraction: Apply appropriate extraction technique (SPME, SPE, QuEChERS) based on analyte properties.
• Concentration: If necessary, concentrate using gentle evaporation or lyophilization.
• HPTLC Analysis: Apply prepared samples to HPTLC plates.

HPTLC Analysis Parameters and Method Validation

Essential HPTLC Instrumentation and Conditions

Proper HPTLC analysis requires specific instrumentation and optimized conditions to ensure accurate, reproducible results [43] [46] [44]:

• HPTLC Plates: Use specific HPTLC plates with thinner layers and smaller silica particles (≈10 µm) for greater resolving power, faster development, and reduced solvent consumption compared to conventional TLC plates [46].
• Sample Application: Use automated sample applicators (e.g., CAMAG ATS4) for precise band application of 6 mm width at constant application rate (e.g., 150 nL/s) [43] [44].
• Plate Activation: Activate silica plates by heating before use to remove absorbed water that can affect Rf values [46].
• Development Chamber: Use automated developing chambers (e.g., CAMAG ADC2) to control conditions such as humidity, chamber saturation with mobile-phase vapor, and mobile-phase migration distance [43] [41].
• Detection: Use TLC scanner at appropriate wavelength (e.g., 262 nm for cordycepin, 290 nm for flufenamic acid) with slit size of 4 × 0.45 mm² and scan speed of 20 mm/s [43] [44].

Method Validation in Greener HPTLC

Greener HPTLC methods require rigorous validation to ensure performance comparable to conventional methods. Key validation parameters include [43] [44]:

• Linearity: Determine over appropriate concentration range (e.g., 50-1000 ng/band for cordycepin, 25-1400 ng/band for flufenamic acid) with coefficient of determination (R²) ≥0.997.
• Specificity: Demonstrate separation of analyte from degradation products and matrix components.
• Precision and Accuracy: Evaluate through replicate analyses at different concentration levels.
• Robustness: Assess method resilience to small, deliberate variations in parameters.
• Greenness Assessment: Calculate AGREE score considering all twelve principles of green analytical chemistry [43] [44].

Table 3: Validation Parameters for Greener HPTLC Methods from Recent Applications

Validation Parameter	Flufenamic Acid Method [43]	Cordycepin Method [44]	Dodonaea angustifolia [45]
Linearity Range	25-1400 ng/band	50-1000 ng/band	Not specified
Determination Coefficient (R²)	0.9974	0.9978	0.9862-0.9977
LOD/LOQ	Not specified	Not specified	LOD: 0.0264-0.1317 µg/100 mL
AGREE Score	0.77	0.79	Not specified
Application Results	101.28% and 99.17% recovery from tablets	98.84% recovery from nanoemulsion	Antimicrobial activity with MIC 20 µg/mL

The Scientist's Toolkit: Essential Materials and Reagents

Successful implementation of greener sample preparation for HPTLC requires specific materials and reagents optimized for both performance and environmental considerations:

Table 4: Essential Research Reagent Solutions for Greener HPTLC Analysis

Item	Function	Greener Alternatives	Application Notes
HPTLC Plates (RP-60F254S)	Stationary phase for separation [43]	Plates with thinner layers and smaller particles for reduced solvent consumption [46]	Use reverse-phase plates for polar compounds; activate before use [46]
Ethanol-Water Mixtures	Green eluent system [43] [44]	Replace traditional acetonitrile or methanol with ethanol-water combinations	Binary combinations (70:30 or 75:25 v/v) provide effective greener elution [43] [44]
Primary Secondary Amine (PSA)	Dispersive SPE sorbent for clean-up [39]	Reduces need for large solvent volumes in clean-up	Effective for removing fatty acids and other polar interferences [39]
SPME Fibers	Solvent-free extraction [39]	Reusable fibers eliminate solvent consumption	Select appropriate fiber coating based on analyte properties [39]
Porous Organic Frameworks	Advanced sorbents for selective extraction [40]	Enhanced selectivity reduces need for multiple clean-up steps	Particularly effective for trace analysis in complex matrices [40]

Workflow Visualization: Greener Sample Preparation for HPTLC

The following diagram illustrates the comprehensive workflow for greener sample preparation of complex matrices prior to HPTLC analysis:

The integration of greener sample preparation methodologies for complex matrices in HPTLC analysis represents a significant advancement in sustainable analytical science. By adopting techniques such as SPME, QuEChERS, and ultrasound-assisted extraction with green solvents, researchers can maintain analytical performance while substantially reducing environmental impact. The successful application of these approaches to diverse matrices—botanicals, pharmaceutical formulations, and biological samples—demonstrates their versatility and effectiveness.

As the field continues to evolve, future developments will likely focus on further miniaturization, increased automation, and the development of even more selective extraction media. The integration of artificial intelligence in method development and optimization promises to accelerate the adoption of these greener approaches. By implementing the protocols and principles outlined in this guide, researchers can contribute to more sustainable analytical practices while generating high-quality HPTLC data for complex matrices.

Direct Sample Application and Solvent-Free Extraction Techniques

The adoption of greener analytical chemistry principles has become a critical objective in modern laboratories, driven by the need to reduce hazardous waste, minimize energy consumption, and enhance operator safety [39]. Within High-Performance Thin-Layer Chromatography (HPTLC), sample preparation represents the most significant source of environmental pollution and chemical waste [39]. Traditional preparation methods often involve extensive sample manipulation, large volumes of organic solvents, and complex extraction procedures that generate substantial waste. This technical guide examines advanced approaches that align with the twelve principles of Green Analytical Chemistry (GAC), specifically focusing on techniques that either eliminate or significantly reduce solvent consumption during the sample preparation stage for HPTLC analysis [39]. By implementing these methodologies, researchers can maintain analytical precision while substantially reducing the ecological footprint of their analytical procedures, contributing to more sustainable pharmaceutical and natural product research.

Theoretical Foundation: Principles of Green Sample Preparation

Green Analytical Chemistry principles provide a framework for evaluating and improving the environmental friendliness of analytical methods [39]. The core tenets most relevant to HPTLC sample preparation include: minimizing or eliminating sample preparation steps, reducing solvent consumption and waste generation, using safer alternative solvents, and lowering energy requirements [39]. The concept of "significance" serves as a useful mnemonic for remembering these principles in practice.

Direct sample application and solvent-free extraction techniques align perfectly with these principles by addressing the most polluting aspects of chromatographic analysis. Conventional HPTLC methods often require solvent-intensive extraction and purification steps before application to the plate. By contrast, the techniques discussed in this guide either eliminate these preliminary steps entirely or replace hazardous organic solvents with safer alternatives, thereby significantly reducing the method's overall environmental impact [39]. The resulting methods are not only more ecologically sustainable but also frequently offer practical advantages including reduced analysis time, lower costs, and simplified procedures.

Direct Sample Application Techniques in HPTLC

Automated Sample Spray Application

Modern HPTLC instrumentation has revolutionized sample application through automated spray-on techniques that significantly improve precision while potentially reducing preliminary sample handling. Unlike manual capillary application in traditional TLC, HPTLC auto-samplers employ precision instruments that apply specified sample volumes by spraying them using nitrogen gas [38]. This automated approach is controlled by computer systems that allow precise specification of application parameters including sample volume, band width, and positioning on the plate [38].

Critical Implementation Considerations:

• Sample Filtration: Unlike manual spotting, samples must be filtered using syringe filters before application to prevent clogging of the precision HPTLC syringes [38].
• Volume Control: Automated systems can handle volumes from 0.1 to 500 μL with exceptional precision, a significant improvement over the 1-10 μL range of manual capillaries [47].
• Band Geometry: Automated application produces rectangular bands (typically 6mm length × 1mm width) versus the circular spots (2-4mm diameter) characteristic of manual application, leading to improved separation efficiency [47].

Table 1: Comparison of Sample Application Techniques

Parameter	Traditional TLC	Modern HPTLC
Application Method	Manual capillary/pipette	Automated spray-on syringe [47]
Sample Volume	1-10 μL (uncontrolled)	0.1-500 μL (precisely controlled) [47]
Sample Geometry	Circular (2-4 mm diameter)	Rectangular (6×1 mm bands) [47]
Solvent Dependency	High (spot size varies with solvent)	Minimal (solvent-independent band size) [47]
Samples per Plate	≤10	≤36 (up to 72 with some systems) [47]

Direct Injection Methodologies

For liquid samples with relatively clean matrices, direct injection represents the ultimate green approach by completely eliminating sample preparation. This methodology involves applying samples directly to HPTLC plates without any preliminary extraction, purification, or dilution steps [39]. While particularly suited for pharmaceutical formulations and relatively pure solutions, this approach can also be adapted for biological samples with minimal pretreatment.

Applications in Pharmaceutical Analysis:

• Formulation Analysis: Tablet and capsule extracts can often be applied directly after simple dissolution and centrifugation [18] [48].
• Clean Matrix Samples: Spirits, petroleum fractions, and simple solutions represent ideal candidates for direct application [39].
• Biological Fluids: With appropriate validation, plasma and serum samples can be applied directly following protein precipitation and centrifugation [18].

Technical Considerations for Success:

• Matrix Complexity: Samples with high particulate or non-volatile content may require filtration or centrifugation to prevent column degradation and interference [39].
• Application Volume Optimization: Careful method development is essential to apply sufficient analyte while minimizing matrix interference.
• Plate Selection: Appropriate stationary phase selection can help manage matrix effects in direct application scenarios.

Solvent-Free and Green Extraction Methods

Solid Phase Microextraction (SPME)

Solid Phase Microextraction represents a completely solvent-free approach that combines extraction and enrichment in a single step. Originally developed in 1990 by Arthur and Pawliszyn, SPME utilizes silica fibers coated with appropriate adsorbent phases to directly extract analytes from solution and concentrate them on the fiber layer [39]. This technique can be directly coupled with HPTLC analysis by eluting captured analytes onto the application zone.

Implementation Protocol:

• Fiber Selection: Choose appropriate fiber coating based on analyte polarity and molecular characteristics.
• Extraction Conditions Optimization: Determine optimal extraction time, sample agitation, and temperature parameters.
• Analyte Desorption: Transfer extracted analytes to HPTLC plate using minimal solvent volume or direct thermal desorption.
• Chromatographic Development: Proceed with standard HPTLC development procedures.

Advantages for HPTLC:

• Complete elimination of solvent use in extraction phase
• Significant sample enrichment and cleanup
• Compatibility with various sample matrices including biological fluids
• Minimal sample volume requirements

QuEChERS Methodology

The QuEChERS (Quick, Easy, Cheap, Effective, Rugged, and Safe) approach, while utilizing minimal solvents, represents a significantly greener alternative to traditional extraction techniques. Originally developed for pesticide analysis, this method has been successfully adapted for pharmaceutical and natural product analysis in HPTLC applications [39].

Standardized Protocol:

• Solvent Extraction: Vigorously shake sample with buffer and acetonitrile containing magnesium sulfate and sodium chloride to induce phase separation.
• Dispersive SPE Cleanup: Utilize primary secondary amine (PSA) adsorbent with magnesium sulfate to remove interfering matrix components including carbohydrates and fatty acids.
• Application to HPTLC: Direct application of cleaned extract to HPTLC plates.

Green Attributes:

• Substantially reduced solvent consumption compared to traditional liquid-liquid extraction
• Minimal waste generation
• Reduced processing time and energy requirements
• Effectiveness for complex matrices including biological samples [39]

Table 2: Comparison of Green Extraction Techniques for HPTLC

Technique	Principle	Solvent Consumption	Best Suited Applications	Limitations
SPME	Adsorption on coated fibers	Solvent-free [39]	Volatile and semi-volatile compounds; biological samples	Limited fiber varieties; possible carryover
QuEChERS	Partitioning and dispersive SPE	Minimal solvents [39]	Complex matrices; multi-residue analysis	Requires optimization for different matrices
Direct Application	No extraction	None	Pharmaceutical formulations; simple matrices	Limited to clean or minimally processed samples
Micellar Extraction	Use of surfactant solutions	Aqueous-based [49]	Hydrophobic compounds; biological samples	May require optimization for different analytes

Experimental Protocols for Greener HPTLC Analysis

Protocol 1: Direct Analysis of Pharmaceutical Formulations

This protocol demonstrates the direct application of pharmaceutical formulations to HPTLC plates, eliminating extraction solvents entirely, as successfully applied in the analysis of remdesivir, linezolid, and rivaroxaban in spiked human plasma [18].

Materials and Equipment:

• HPTLC plates (silica gel 60 F254)
• Automated HPTLC applicator (e.g., CAMAG Linomat series)
• Pharmaceutical formulation (tablet, capsule, or injection solution)
• Appropriate mobile phase for target analytes
• HPTLC densitometer

Procedure:

• Sample Preparation:
  • For tablets/capsules: Accurately weigh and crush, then dissolve in minimal solvent (water, methanol, or ethanol).
  • For injections: Dilute directly with appropriate solvent.
  • Centrifuge at 10,000 rpm for 5 minutes to remove particulates.

• Filtration: Pass supernatant through 0.45 μm syringe filter to prevent applicator clogging [38].

• Application: Program auto-sampler to apply 1-10 μL bands in rectangular configuration (6mm × 1mm typical).

• Chromatographic Development: Develop in pre-saturated chamber with optimized mobile phase.

• Detection and Quantification: Scan plates at appropriate wavelength and quantify via densitometry.

Validation Parameters:

• Linearity across working concentration range
• Recovery studies (98-102% typically acceptable)
• Precision (intra-day and inter-day %RSD <2%)
• Specificity regarding formulation excipients

Protocol 2: Solvent-Free SPME-HPTLC for Biological Samples

This integrated protocol combines solvent-free SPME with HPTLC analysis for sensitive determination of analytes in complex biological matrices.

Materials and Equipment:

• SPME assembly with appropriate fiber coating
• HPTLC system with automated applicator
• Biological sample (plasma, serum, or tissue homogenate)
• Appropriate buffers and reagents
• HPTLC densitometer

Procedure:

• Sample Preparation:
  • For plasma/serum: Dilute 1:1 with appropriate buffer.
  • For tissues: Homogenize in minimal aqueous buffer.
  • Transfer 1-2 mL to SPME vial.

• SPME Extraction:

  • Condition SPME fiber according to manufacturer specifications.
  • Immerse fiber in sample with continuous agitation for optimized time.
  • Withdraw fiber and rinse briefly with distilled water.

• Analyte Transfer to HPTLC:

  • Option A: Thermal desorption directly onto HPTLC plate pre-application zone.
  • Option B: Solvent desorption using minimal solvent (10-50 μL) followed by application.

• Chromatographic Development and Analysis:

  • Develop in optimized mobile phase system.
  • Detect and quantify using densitometric scanning.

Method Optimization Considerations:

• Fiber coating selection based on analyte log P values
• Extraction time profiling (30-120 minutes typically)
• Desorption efficiency evaluation
• Matrix effect assessment

The Scientist's Toolkit: Essential Research Reagents and Materials

Successful implementation of direct sample application and solvent-free extraction techniques requires careful selection of reagents and materials. The following table details essential components for establishing these green HPTLC methodologies.

Table 3: Research Reagent Solutions for Green HPTLC Sample Preparation

Material/Reagent	Specifications	Function	Green Attributes
HPTLC Plates	Silica gel 60 F254, 5-6 μm particle size, 0.1-0.2 mm layer thickness [47]	Stationary phase for separation	High efficiency allows shorter development distances, reducing mobile phase consumption
Automated Applicator	CAMAG Linomat series with 100 μL syringe [18]	Precise sample application in bands	Minimizes sample volume required; improves reproducibility
SPME Fibers	Various coatings (PDMS, PA, CAR/PDMS)	Solvent-free extraction and concentration	Eliminates solvent use in sample preparation
QuEChERS Kits	Pre-mixed salts (MgSO4, NaCl) and dispersive SPE sorbents (PSA, C18) [39]	Matrix cleanup and extraction	Reduces solvent consumption compared to traditional extraction
Green Solvents	Ethanol, water, ethyl acetate [39]	Sample dissolution and mobile phase components	Lower toxicity and better biodegradability than traditional solvents
Micellar Solutions	SDS, Brij-35 surfactants [49]	Mobile phase components for micellar LC	Replace toxic organic modifiers with aqueous-based solutions
NADES	Natural Deep Eutectic Solvents [11]	Green extraction media	Biodegradable, low toxicity, from renewable resources

Assessment of Method Greenness and Sustainability

The environmental impact of analytical methods can be systematically evaluated using established greenness assessment tools. For HPTLC methods incorporating direct sample application and solvent-free extraction, several metrics demonstrate significant improvements over conventional approaches.

Greenness Assessment Tools:

• Analytical Eco-Scale: Semi-quantitative approach evaluating penalty points for hazardous chemicals, energy consumption, and waste [49].
• GAPI (Green Analytical Procedure Index): Pictographic representation assessing environmental impact across multiple method stages [48].
• AGREE Metric: Comprehensive assessment based on all 12 principles of Green Analytical Chemistry [48].
• White Analytical Chemistry (WAC): Evaluates the balance between analytical quality, practicality, and ecological impact [48].

Advantages of Direct and Solvent-Free Approaches:

• Reduced Organic Waste: Elimination or minimization of extraction solvents dramatically reduces hazardous waste generation [39].
• Lower Energy Consumption: Simplified sample preparation requires less energy-intensive equipment and procedures.
• Enhanced Safety: Reduced operator exposure to toxic organic solvents.
• Improved Efficiency: Streamlined workflows decrease analysis time while maintaining data quality.

Comparative studies consistently demonstrate that methods incorporating direct application and solvent-free extraction principles achieve superior greenness scores while maintaining analytical performance comparable to conventional methodologies [18] [48].

Direct sample application and solvent-free extraction techniques represent transformative approaches that align HPTLC methodology with the fundamental principles of Green Analytical Chemistry. By minimizing or eliminating solvent consumption in the sample preparation stage, these methods significantly reduce the environmental impact of chromatographic analysis while maintaining, and in some cases enhancing, analytical performance. The implementation of automated application systems, coupled with innovative extraction methodologies including SPME and QuEChERS, provides researchers with practical tools to advance sustainability in pharmaceutical and natural product analysis. As green chemistry principles continue to gain prominence in regulatory and industrial contexts, these techniques will play an increasingly vital role in the development of environmentally responsible analytical methods that do not compromise data quality or practical efficiency.

Overcoming Challenges in Sustainable Method Development

Addressing Matrix Effects and Interferences in Complex Samples

In analytical chemistry, the sample matrix is conventionally defined as the portion of the sample that is not the target analyte—essentially, most of the sample [50]. Matrix effects occur when components of this matrix interfere with the detection, quantification, or separation of analytes, potentially compromising analytical accuracy, precision, and sensitivity. These effects are particularly pronounced when analyzing complex samples such as botanical extracts, biological fluids, food products, and environmental samples, where the target analytes coexist with much higher concentrations of exogenous and endogenous compounds [51] [52].

Within the context of High-Performance Thin-Layer Chromatography (HPTLC) and other chromatographic techniques, matrix effects can manifest as co-elution with isobaric interferents, leading to potential false negatives, or as signal suppression/enhancement during detection, which causes inaccurate quantification [53]. Addressing these challenges is fundamental to developing reliable analytical methods, especially as regulatory scrutiny increases in industries like dietary supplements and herbal medicine where confirming mixture identity is paramount [54].

The push for greener analytical chemistry further compounds this challenge. The ideal of minimalistic sample preparation, while reducing solvent consumption and waste, can intensify matrix effects by introducing more co-extracted compounds into the analytical system [55] [56]. This tutorial provides a structured framework for understanding, evaluating, and mitigating matrix effects, aligning effective interference management with the principles of sustainable science.

Characterizing and Evaluating Matrix Effects

A systematic approach to evaluating matrix effects is crucial for developing robust methods. The first step is recognizing that matrix components can affect various parts of an analytical method, including extraction efficiency, apparent retention time, peak shape, and, most critically, the apparent quantity of an analyte [50].

Quantitative Evaluation Methods

Two established experimental protocols are predominantly used for assessing matrix effects, particularly in mass spectrometric detection:

• The Qualitative Post-Column Infusion Method: This method involves adding a dilute solution of the analyte of interest via continuous infusion between the chromatographic column outlet and the mass spectrometer inlet. As the blank matrix extract is chromatographed, the constant analyte signal will display regions of suppression or enhancement corresponding to the elution of matrix compounds. An ideal result shows a constant signal across the entire chromatogram, while deviations indicate matrix effects [50] [52].
• The Quantitative Post-Extraction Spike Method: This approach involves comparing the detector response for an analyte spiked into a blank matrix extract after extraction with the response for the same analyte in a pure solution. The magnitude of the matrix effect (ME) is often calculated as: ME (%) = (B / A) × 100%, where A is the peak area of the analyte in neat solution and B is the peak area of the analyte spiked into the blank matrix extract. A value of 100% indicates no matrix effect, <100% indicates suppression, and >100% indicates enhancement [52].

Matrix Effect Profiles Across Sample Types

The severity of matrix effects is highly dependent on both the sample origin and the extraction methodology. A comprehensive study evaluating 25 different matrices extracted with four common multiresidue methods revealed significant variations in interference levels [53].

Table 1: Matrix Interference Evaluation by Chromatography and Extraction Method

Extraction Method	Average % of Interferents (GC-MS/MS)	Average % of Interferents (LC-MS/MS)	Common Matrix Challenges
Citrate QuEChERS (with/without PSA)	2.8%	0.23%	Phospholipids, sugars, organic acids
Ethyl Acetate	2.8%	0.23%	Lipids, pigments
Dutch Mini-Luke (NL)	12.1%	1.4%	Broad spectrum of polar and apolar compounds

Key findings from this study include:

• Interference Prevalence: The presence of matrix compounds with isobaric transitions to target pesticides was higher in GC-than in LC-based analyses under the tested conditions [53].
• Quantification Errors: For over 90% of cases, quantification errors were minimized when using matrix-matched calibration, provided the interferent concentration remained constant along the calibration curve. The error was also found to be concentration-dependent [53].
• Signal Effects: Signal suppression/enhancement was observed in 44% of cases with LC and a striking 93% of cases with GC, primarily manifesting as signal enhancement [53].

The following workflow diagram illustrates the logical process for characterizing matrix effects in a complex sample, from problem identification to selecting an appropriate mitigation strategy.

Green Strategies for Mitigating Matrix Effects

Aligning effective mitigation with the principles of Green Analytical Chemistry (GAC) requires strategies that minimize hazardous solvent use, energy consumption, and waste generation [56]. The following approaches, ranging from sample preparation to instrumental analysis, provide a pathway to greener, more robust methods.

Sample Preparation: The First Line of Defense

Sample preparation is often the most effective stage for mitigating matrix effects. Green principles here emphasize miniaturization, simplification, automation, and the reduction or elimination of organic solvents [56] [52].

• Minimalistic Preparation and Direct Analysis: The greenest approach is to eliminate sample preparation entirely where feasible. Direct analysis is suitable for clean matrices and has been successfully implemented in both gas and liquid chromatography, for example, in the direct injection of water samples for volatile organic compound analysis [56]. HPTLC is notably advantageous in this context due to its tolerance for minimally processed samples. Its open-bed configuration allows solvents to evaporate, preventing the injection of non-volatile matrix components that often plague liquid chromatography systems [55].

• Green Extraction Techniques:

  • QuEChERS (Quick, Easy, Cheap, Effective, Rugged, and Safe): This method utilizes relatively small volumes of acetonitrile (an extraction solvent) followed by a dispersive Solid-Phase Extraction (SPE) clean-up step. It is considered a greener alternative to traditional extraction methods due to its efficiency and reduced solvent consumption [56] [53]. The clean-up step, often employing primary secondary amine (PSA) to remove fatty acids and other interferents, is crucial for reducing matrix effects [53].
  • Solid-Phase Extraction (SPE): Modern SPE sorbents offer high selectivity for removing phospholipids and other common interferents. Materials such as zirconia-coated silica and mixed-mode polymeric sorbents that combine reversed-phase and ion-exchange mechanisms have proven highly effective. The development of restricted-access materials (RAM) and molecularly imprinted polymers (MIP) further enhances selectivity by excluding large molecules like proteins while selectively retaining target analytes, significantly reducing matrix effects [52].
  • Salting-out Assisted Liquid-Liquid Extraction (SALLE): SALLE uses salts to separate water-miscible organic solvents from an aqueous phase, partitioning analytes into the organic layer. While it can extract a broader range of analytes than conventional LLE, it may also co-extract more endogenous compounds, requiring careful optimization to balance recovery and matrix effect reduction [52].

Analytical Technique and Methodological Solutions

The choice of analytical platform and methodological adjustments can inherently reduce matrix interference.

• Leveraging HPTLC's Advantages: HPTLC is inherently resilient to matrix effects for several reasons. Its ability to use multiple selective detection methods (e.g., absorbance, fluorescence, and chemical derivatization) on a single plate allows for cross-confirmation of results, making it difficult for an interferent to affect all detection modes simultaneously [51] [57]. Furthermore, in HPTLC, the separation is decoupled from the detection; any non-volatile matrix components remain fixed at their application position and do not interfere with the detection of separated analytes, unlike in HPLC where they are injected into the system [55].

• Chromatographic Optimization: Adjusting chromatographic conditions to shift the retention time of the analyte away from the elution zone of major matrix interferents is a fundamental and green strategy. This requires a good understanding of the matrix composition, which can be gained from the post-column infusion experiment [50] [53].

• The Internal Standard Method: Using a well-chosen internal standard (IS) is one of the most potent ways to compensate for matrix effects during quantification. The ideal IS is a stable isotope-labeled (SIL) version of the analyte, which experiences nearly identical extraction efficiency, retention, and ionization suppression/enhancement. The calibration curve is then constructed using the ratio of the analyte signal to the IS signal, which corrects for variability caused by the matrix [50] [52].

• Effect-Directed Assays (EDA): A powerful hyphenated approach combines HPTLC separation with EDA. This technique helps prioritize biologically active compounds from complex mixtures. After separation, the HPTLC plate is subjected to enzymatic or biological assays, pinpointing only the zones that elicit a specific effect. These relevant zones can then be characterized further using high-resolution mass spectrometry, ensuring that analytical resources are focused solely on the important compounds and minimizing interference from inactive matrix components [55].

Strategic Workflow for Mitigation

A systematic approach that integrates green principles from the start is the most efficient path to a reliable method. The following diagram outlines a strategic workflow for selecting and implementing mitigation techniques, from the greenest options to more specialized ones.

Essential Reagent and Material Solutions

Successful implementation of the strategies above relies on a toolkit of specialized reagents and materials. The following table details key solutions for managing matrix effects in a green context.

Table 2: Research Reagent Solutions for Managing Matrix Effects

Reagent / Material	Function in Mitigation	Green & Practical Considerations
Zirconia-Coated Silica Sorbents	Selectively binds and removes phospholipids from samples during SPE or dSPE clean-up steps.	Reduces the need for large solvent volumes for washing, enabling miniaturization [52].
Mixed-Mode SPE Sorbents	Combine reversed-phase and ion-exchange mechanisms to selectively retain analytes or interferents based on multiple properties.	Improves selectivity, reducing the number of clean-up steps and overall solvent consumption [52].
Primary Secondary Amine (PSA)	Used in dSPE (e.g., QuEChERS) to remove fatty acids, organic acids, and sugars from sample extracts.	A key component in the efficient, low-solvent QuEChERS methodology [53].
Stable Isotope-Labeled Internal Standards	Compensates for matrix-induced ionization effects in MS and variability in sample preparation.	While not a "green" chemical, its use prevents method failures and re-analysis, reducing long-term waste [50] [52].
Selective Derivatization Reagents	In HPTLC, compounds without chromophores are reacted with reagents to create visible or fluorescent zones.	Allows detection of otherwise invisible analytes, avoiding the need for more complex, energy-intensive detection systems [57].
Restricted-Access Materials (RAM)	Sorbents with a hydrophilic outer surface that excludes proteins and large molecules, while allowing small analytes to access inner pores.	Enables direct injection of complex biological fluids, eliminating extensive sample prep and associated solvent use [52].

Effectively addressing matrix effects is not merely a technical obstacle but a fundamental requirement for generating reliable analytical data in HPTLC research and other chromatographic sciences. A deep understanding of the sample matrix, coupled with a systematic evaluation using post-column infusion or post-extraction spiking, forms the foundation of a robust method. The strategies outlined—from leveraging the inherent strengths of HPTLC and implementing green sample preparation techniques like QuEChERS and selective SPE, to employing methodological corrections like internal standardization—provide a comprehensive toolkit for analysts. By integrating these mitigation strategies with the core principles of Green Analytical Chemistry, researchers can advance their field with methods that are not only scientifically valid and reliable but also environmentally sustainable. This synergy between data quality and green principles is essential for the future of analytical science, particularly when deconstructing and analyzing the most complex sample matrices.

Optimizing Recovery and Selectivity with Green Solvent Systems

The transition to green solvent systems in High-Performance Thin-Layer Chromatography (HPTLC) is a critical step in aligning separation science with the principles of Green Analytical Chemistry (GAC). This shift moves the field away from a linear "take-make-dispose" model toward a more sustainable, circular framework [10]. The optimization of these systems focuses on maintaining, and often enhancing, two critical analytical figures of merit: recovery and selectivity, while significantly reducing environmental impact.

The success of analytical chemistry in determining the composition and quantity of matter plays a crucial role in addressing environmental challenges. However, its traditional reliance on energy-intensive processes, non-renewable resources, and waste generation is a growing concern [10]. The adoption of green solvent systems in HPTLC represents a tangible application of green chemistry principles, replacing hazardous, volatile, and persistent organic solvents with safer, biodegradable, and often less toxic alternatives without compromising the analytical performance required for rigorous drug development and quality control.

Green Solvent Selection and Optimization Strategies

Fundamental Principles of Green Solvent Selection

The core objective in optimizing green solvent systems is to identify replacements for traditional solvents that offer improved environmental, health, and safety (EHS) profiles while delivering the chromatographic performance necessary for precise and accurate analysis. The optimal solvent system achieves a balance between the polarity, viscosity, and chemical structure of the solvents to facilitate the desired separation.

Key attributes of green solvents include:

• Low Toxicity: Minimal risk to human health and the environment.
• Biodegradability: Ability to break down into innocuous substances in the environment.
• Renewable Origin: Derived from biomass rather than finite petrochemical resources.
• Low Volatility: Reduced inhalation hazards and lower VOC emissions.
• Flame Resistance: Enhanced safety in laboratory handling and storage.

Experimentally Proven Green Solvent Systems in HPTLC

Recent research has demonstrated the efficacy of various green solvent mixtures for the analysis of diverse active pharmaceutical ingredients (APIs). The table below summarizes several validated systems, showcasing their composition and successful applications.

Table 1: Experimentally Validated Green Solvent Systems for HPTLC Analysis

Analytes (API)	Green Mobile Phase Composition (v/v/v)	Retention Factor (Rf) Values	Key Performance Metrics	Citation
Tenoxicam	Ethanol / Water / Ammonia (50:45:5)	N/A	Linearity: 25–1400 ng/bandLOD/LOQ: 0.98/2.94 ng/bandAGREE Score: 0.75/1.00	[16]
Tamsulosin & Mirabegron	Methanol / Ethyl Acetate / Ammonia (3:7:0.1)	TAM: 0.63MIR: 0.42	Linearity (TAM): 0.05–2.5 µg/bandLinearity (MIR): 0.15–7.5 µg/bandRecovery: ~100% for both	[58]
Ivabradine & Metoprolol	Chloroform / Methanol / Formic Acid / Ammonia (8.5:1.5:0.2:0.1)	IVA: 0.45MET: 0.89	Linearity (UV): 50–600 ng/band (IVA), 50–900 ng/band (MET)Linearity (FL): 18–400 ng/band (IVA), 50–550 ng/band (MET)	[32]
Florfenicol & Meloxicam	Glacial Acetic Acid / Methanol / Triethylamine / Ethyl Acetate (0.05:1.0:0.1:9.0)	N/A	Linearity (MEL): 0.03–3.00 µg/bandLinearity (FLR): 0.50–9.00 µg/band	[14]
Morin	Toluene / Ethyl Acetate / Formic Acid (36:12:7)	N/A	Linearity: 300–700 ng/bandLOD/LOQ: Determined per ICH guidelines	[59]

Systematic Optimization Workflow

Developing an optimized method requires a structured approach. The following diagram outlines the key decision points and feedback loops in the green solvent selection and optimization process.

Systematic Optimization Workflow for Green HPTLC Methods

Experimental Protocols for Key Green HPTLC Methodologies

Detailed Protocol: Eco-Friendly HPTLC for Tenoxicam

This protocol is adapted from a method that achieved an excellent AGREE greenness score of 0.75 [16].

3.1.1 Materials and Reagents

• Analytical Standard: Tenoxicam (TNX) pure standard.
• Green Solvents: Absolute Ethanol (HPLC grade), Deionized Water, Ammonia solution.
• HPTLC Plates: Silica gel 60 F254, 20 × 10 cm.
• Equipment: CAMAG or equivalent HPTLC system (automatic sampler, twin-trough development chamber, TLC scanner).

3.1.2 Solution Preparation

• Standard Stock Solution (1 mg/mL): Accurately weigh 10 mg of TNX and transfer to a 10 mL volumetric flask. Dissolve and make up to volume with methanol.
• Working Standard Solutions: Prepare serial dilutions from the stock solution with methanol to cover the concentration range of 25–1400 ng/band.

3.1.3 Chromatographic Conditions

• Mobile Phase: Ethanol/Water/Ammonia solution (50:45:5, v/v/v). Note: This ternary mixture is the optimized green system.
• Application: Apply samples as 6 mm bands using an automatic sampler (dosage speed: 150 nL/s).
• Development: Use a twin-trough glass chamber pre-saturated with mobile phase vapor for 20 minutes at room temperature. Develop the plate to a distance of 80 mm.
• Densitometry: Scan the developed and dried plate at a wavelength of 375 nm.

3.1.4 Validation Parameters The method was validated per ICH guidelines [16]:

• Linearity: 25–1400 ng/band (r² > 0.99)
• Precision: % RSD for repeatability and intermediate precision < 2%.
• Accuracy: Average recovery reported between 98.24–101.48%.
• Sensitivity: LOD = 0.98 ng/band, LOQ = 2.94 ng/band.

Detailed Protocol: Simultaneous Determination of Tamsulosin and Mirabegron

This protocol highlights a stability-indicating method for a two-component mixture with a significant dosage difference [58].

3.2.1 Materials and Reagents

• Analytical Standards: Tamsulosin HCl (TAM) and Mirabegron (MIR) pure powders.
• Green Solvents: Methanol, Ethyl Acetate, Ammonia solution.
• HPTLC Plates: TLC silica gel 60 F254 aluminum sheets (20 × 20 cm).

3.2.2 Solution Preparation

• Individual Stock Solutions (1 mg/mL): Separately weigh 10 mg of MIR and TAM into two 10 mL volumetric flasks. Dissolve and dilute with methanol.
• Working Mixture Solution: Transfer aliquots of 7.5 mL (MIR stock) and 2.5 mL (TAM stock) into a 10 mL volumetric flask. Dilute to mark with methanol to obtain a solution containing 0.75 mg/mL MIR and 0.25 mg/mL TAM.

3.2.3 Chromatographic Conditions

• Mobile Phase: Methanol ‒ Ethyl Acetate ‒ Ammonia (3:7:0.1, v/v/v).
• Application: Spot aliquots of 0.2–10.0 µL of the working mixture in triplicate.
• Development: Develop in a twin-trough chamber saturated with mobile phase vapor for 30 minutes. The development distance is 75 mm, taking approximately 15 minutes.
• Detection: Dry plates and scan at 270 nm using a deuterium lamp in absorbance mode.

3.2.4 Validation and Application

• Linearity: 0.15–7.5 µg/band for MIR and 0.05–2.5 µg/band for TAM.
• Accuracy: Mean % recovery of 100.04 ± 0.56 for MIR and 99.98% ± 0.95 for TAM.
• Application: Successfully applied to a laboratory-prepared mixture and forced degradation studies, demonstrating its stability-indicating property.

The Scientist's Toolkit: Essential Research Reagents and Materials

The successful implementation of green HPTLC methods relies on a core set of reagents and instruments. The following table details these essential components.

Table 2: Essential Research Reagent Solutions and Materials for Green HPTLC

Item Category	Specific Examples	Function & Rationale in Green HPTLC
Green Solvents	Ethanol, Water, Ethyl Acetate, Methanol [16] [58]	Primary components of the mobile phase. Selected for their favorable environmental, health, and safety (EHS) profiles compared to traditional solvents like chloroform or n-hexane.
Modifiers	Ammonia solution, Glacial Acetic Acid, Triethylamine [16] [14] [58]	Used in small quantities to adjust pH and ionic strength of the mobile phase, which is critical for controlling the selectivity and efficiency of the separation, especially for ionizable compounds.
HPTLC Plates	Silica gel 60 F254 on aluminum sheets [59] [14] [58]	The stationary phase. The F254 indicator allows for visualization of UV-absorbing compounds at 254 nm. Pre-coated plates ensure consistent layer thickness and performance.
Internal Standard	Esomeprazole (ESO) [14]	A compound added in equal amount to all samples and standards during preparation. Used to correct for errors in sample application, development, and scanning, improving quantitative accuracy.
Densitometer	TLC Scanner (e.g., CAMAG TLC Scanner 3) [59] [58]	The instrument used for quantitative measurement. It scans the developed TLC plate to measure the intensity of the analyte bands as peak areas, enabling precise quantification.

Assessment of Method Greenness and Environmental Impact

Evaluating the environmental footprint of an analytical method is a cornerstone of GAC. The greenness of the HPTLC methods discussed has been rigorously assessed using modern metrics [58].

• AGREE Metric: The Analytical GREEness metric employs a pictogram to provide a comprehensive greenness score based on all 12 principles of GAC. The method for Tenoxicam, for example, achieved a high score of 0.75 out of 1.0 [16].
• Analytic Eco-Scale: This semi-quantitative tool assesses penalty points for hazardous reagents, energy consumption, and waste generation. A higher score indicates a greener method. Green HPTLC methods typically score very well on this scale [58].
• GAPI: The Green Analytical Procedure Index uses a visual pictogram with filled segments to indicate the environmental impact of each step of an analytical procedure [58].

The fundamental advantages of HPTLC itself contribute significantly to its green profile: minimal solvent consumption per sample, low energy requirements (no column heating or high-pressure pumps), and the ability to analyze multiple samples simultaneously on a single plate, which drastically reduces solvent waste and analysis time compared to other chromatographic techniques [58].

The optimization of recovery and selectivity using green solvent systems is not merely a trend but a necessary evolution in HPTLC practice. As demonstrated by numerous recent studies, it is entirely feasible to replace hazardous solvents with safer, environmentally benign alternatives like ethanol, water, and ethyl acetate without sacrificing analytical performance. The resulting methods are robust, validated, and aligned with the principles of sustainability and circularity, reducing the environmental footprint of analytical laboratories in drug development and quality control. The continued development and adoption of such green methodologies, supported by rigorous greenness assessment tools, are fundamental to the future of sustainable analytical science [10].

Balancing Analytical Performance with Environmental Goals

The field of analytical chemistry is undergoing a essential paradigm shift to align with the principles of sustainability science. High-Performance Thin-Layer Chromatography (HPTLC) has emerged as a powerful technique that inherently supports green analytical principles while maintaining rigorous performance standards. This technical guide explores the integration of environmental goals with analytical excellence within HPTLC, providing researchers and drug development professionals with practical frameworks and methodologies for implementing sustainable practices without compromising data quality.

The contemporary understanding of sustainability in analytical chemistry extends beyond simple solvent reduction to encompass a holistic "triple bottom line" approach that balances economic, social, and environmental dimensions [10]. Within this framework, HPTLC offers distinct advantages through its minimal solvent consumption, low energy requirements, and capacity for high-throughput analysis, positioning it as an essential technology for advancing greener analytical practices in pharmaceutical research and quality control [12].

Theoretical Framework: Sustainability in Analytical Chemistry

Distinguishing Sustainability from Circularity

A critical foundation for implementing environmental goals in analytical chemistry lies in understanding the nuanced relationship between sustainability and circularity. While these terms are often used interchangeably, they represent distinct conceptual frameworks:

• Sustainability is a normative concept tied to contextual priorities and has been formally defined through the "triple bottom line" framework that balances three interconnected pillars: economic stability, social well-being, and environmental protection [10].
• Circularity primarily focuses on minimizing waste and keeping materials in use for as long as possible, but doesn't necessarily consider all three dimensions of sustainability. The circular analytical chemistry framework emphasizes environmental dimensions and integrates strong economic considerations, though social aspects are less pronounced [10].

Although sustainability and circularity do not always align directly, they remain deeply interconnected. Sustainability drives progress toward more circular practices, with innovation serving as a bridge between the two concepts. Simultaneously, adopting circular principles can act as a stepping stone toward achieving broader sustainability goals [10].

Weak vs. Strong Sustainability Models

Current analytical practices predominantly reflect a weak sustainability model, which assumes that natural resources can be consumed and waste generated as long as technological progress and economic growth compensate for the environmental damage. In this model, societal needs are typically addressed through increased economic opportunities or technological advancements with minimal consideration for long-term ecological impacts [10].

In contrast, strong sustainability acknowledges ecological limits, carrying capacities, and planetary boundaries. It emphasizes practices and policies aimed at restoring and regenerating natural capital, challenging the notion that economic growth alone can resolve environmental issues. Achieving strong sustainability in analytical chemistry would require a fundamental shift away from current practices toward disruptive innovations that prioritize nature conservation. While this may seem idealistic, it serves as an essential vision that can drive the field beyond incremental technological improvements toward systemic change [10].

Green Sample Preparation Fundamentals for HPTLC

Core Principles of Green Sample Preparation

Adapting traditional sample preparation techniques to align with Green Sample Preparation (GSP) principles involves optimizing energy efficiency while maintaining analytical quality. The key strategy centers on maximizing sample throughput, which simultaneously reduces exposure risks and analysis costs. This can be achieved through four primary approaches [10]:

• Accelerating the sample preparation step through enhanced mass transfer
• Treating several samples in parallel to increase overall throughput
• Automating sample preparation to improve efficiency and reduce human intervention
• Integrating multiple steps into streamlined workflows

One effective approach to accelerate mass transfer during sample preparation involves applying vortex mixing or assisting fields such as ultrasound and microwaves. These approaches significantly enhance extraction efficiency and speed up mass transfer while consuming substantially less energy compared to traditional heating methods like Soxhlet extraction [10].

Sample Preparation Techniques

Successful HPTLC analysis begins with proper sample preparation, which directly determines separation quality, resolution, and analytical reliability. The process requires specific approaches tailored to sample matrix characteristics [5]:

Sample Collection and Storage:

• For solid samples, representative sampling requires homogenization through grinding and crushing to ensure uniform analyte distribution while avoiding cross-contamination
• Liquid samples require immediate stabilization to prevent volatilization or chemical changes using amber vials for light-sensitive compounds and appropriate temperature control
• Storage conditions must be tailored to analyte characteristics: temperature control (4°C or below for volatile compounds), light protection, atmosphere control (inert gas purging for oxidation-sensitive samples), and pH stabilization through buffering

Sample Dissolution and Dilution:

• Optimal dissolution requires selecting solvents that completely solubilize all mixture components while maintaining chromatographic compatibility
• For normal-phase HPTLC, use the least polar solvent that achieves complete dissolution to minimize spot spreading during application
• The standard dilution ratio of 1 drop sample to approximately 1 mL solvent (50-100x dilution) typically provides sharp, well-defined spots under 2mm diameter with adequate sensitivity

Sample Cleanup Methods:

• Filtration removes particulate matter that can damage HPTLC plates or cause irregular solvent flow (0.22μm syringe filters for critical applications)
• Liquid-liquid extraction separates target analytes from aqueous matrices or removes specific interferent classes, with pH adjustment controlling ionization state and partitioning behavior
• Solid-phase extraction (SPE) provides selective cleanup for complex biological or environmental samples using reverse-phase, normal-phase, or mixed-mode sorbents tailored to analyte polarity and matrix composition

Table 1: Troubleshooting Common HPTLC Sample Preparation Issues

Problem	Primary Causes	Solutions
Streaking	Sample overloading, acidic/basic compound interactions, plate contamination	Reduce sample concentration/volume, add modifiers to mobile phase, pre-wash plates
Tailing	Analyte-stationary phase interactions	pH adjustment, addition of competing agents (triethylamine for basic sites), mobile phase modifier optimization
Poor Resolution	Compounds co-elute (Rf difference <0.15) or excessive separation (Rf values <0.2)	Decrease mobile phase polarity to increase retention differences or increase polarity respectively
Spot Spreading	Overly polar diluents in normal-phase HPTLC	Use non-polar diluents (n-hexane) to prevent substance transport toward edge of "wet zone"

TLC Plate Preparation and Handling

Proper TLC plate preparation forms the foundation for reproducible HPTLC analysis:

Plate Selection and Preparation:

• Silica gel 60 F254 plates represent the standard for most applications, providing optimal particle size (10-12μm), pore diameter (60Å), and fluorescent indicator for UV detection
• Plate thickness affects loading capacity: 0.25mm for analytical work, 0.5-2.0mm for preparative separations [5]
• Pre-washing removes impurities from binders, packaging materials, and handling contamination through development with methanol or intended mobile phase followed by complete air drying [60]

Plate Activation Procedures:

• Standard activation requires heating at 120°C for 20-30 minutes in a clean laboratory oven to remove adsorbed moisture that reduces stationary phase activity and separation efficiency
• Activation removes bound water from silanol groups, maximizing their availability for analyte interactions
• Over-activation above 120°C can cause silica gel structural changes and reduced performance, while under-activation leaves residual moisture that compromises separation reproducibility [5]

Baseline Preparation:

• Draw the baseline 1.0cm from the bottom edge using a pencil to avoid damaging the silica gel surface
• Maintain 2.5cm spacing between spots for complex mixtures requiring maximum resolution
• Avoid scratching the silica gel surface, which creates irregular solvent flow patterns [5]

Sustainable HPTLC Method Development

Mobile Phase Optimization for Green HPTLC

Mobile phase selection represents one of the most significant opportunities for reducing environmental impact in HPTLC analysis. The principles of green chemistry guide the selection of solvents based on safety, environmental impact, and energy consumption.

Solvent System Selection:

• Mobile phase polarity controls analyte migration and separation selectivity, with the eluotropic series guiding initial solvent selection
• Target Rf values between 0.2-0.8 for reliable identification and quantification, with optimal separations often targeting Rf = 0.4 for the compound of interest [5]
• Systematic optimization protocols like PRISMA (Polarity-Ratio-Index-Systematic-Mobile-phase-Addition) provide efficient mobile phase development through testing three different polarities with ternary solvent mixtures [5]

Green Solvent Alternatives:

• Ethanol-water mixtures represent exemplary green mobile phases, as demonstrated in a reverse-phase HPTLC method for caffeine estimation that achieved an AGREE greenness score of 0.80 [22]
• Ethyl acetate-ethanol mixtures offer greener alternatives to traditional solvent systems, with ethanol and water categorized as green solvents according to GAC principles due to their safety and non-toxicity toward the environment [22]

Table 2: Greenness Assessment Tools for HPTLC Methods

Assessment Tool	Parameters Evaluated	Scoring System	Application Example
AGREE	All 12 principles of green analytical chemistry	0-1 scale (1 = highest greenness)	Caffeine estimation in energy drinks: score 0.80 [22]
NEMI	Four key criteria: persistent/bioaccumulative/toxic, hazardous, corrosive, waste generation	Pictogram: all green for best rating	HPTLC method for carvedilol: passed all criteria [9]
Eco-Scale	Penalty points for hazardous reagents, energy consumption, waste	100-point scale (>75 excellent)	Not specified in sources
GAPI	Five steps of method development with environmental impact	Pictogram with 15 components	HPTLC method for carvedilol: favorable assessment [9]
White Analytical Chemistry	Analytical performance, ecological impact, practical & economic effectiveness	RGB values balancing all aspects	HPTLC method for carvedilol: balanced performance [9]

Method Development and Validation

Chromatographic Conditions:

• Sample application as 6mm bands using automated applicators with constant application rates (150nL/s) [22]
• Development in automated developing chambers with chamber saturation for 20-30 minutes at controlled temperature (22°C) [22]
• Employing greener mobile phases such as ethyl acetate-ethanol (7:3, v/v) for pharmaceutical compounds or ethanol-water (55:45, v/v) for reverse-phase applications [2] [22]

Validation Parameters:

• Linearity validation across relevant concentration ranges (e.g., 50-800 ng/band for caffeine) with correlation coefficients ≥0.9995 [2] [22]
• Precision demonstration with relative standard deviation (RSD) ≤2% [2]
• Accuracy evaluation through percent recovery studies at multiple concentration levels [22]
• Robustness testing under varying environmental conditions [22]

Advanced Sustainable HPTLC Platforms

Multimodal HPTLC Integration

Recent advancements have transformed HPTLC from a simple planar separation technique into a versatile analytical platform through integration with complementary detection systems. These "HPTLC+" platforms substantially improve sensitivity, selectivity, and throughput while maintaining environmental benefits [12]:

• HPTLC-MS: Combines the rapid, parallel separation capability of HPTLC with the high-resolution molecular specificity of mass spectrometry, reducing ion suppression effects by pre-separating target analytes from interfering substances [12]
• HPTLC-SERS: Integrates surface-enhanced Raman spectroscopy for molecular fingerprinting through enhanced Raman scattering signals via localized surface plasmon resonance on nanostructured metallic surfaces [12]
• HPTLC-NIR: Enables non-destructive compositional profiling for applications such as food freshness monitoring without sample destruction [12]
• Bioautography: Allows function-directed screening of biological activity by combining separation with biological detection, identifying bioactive compounds without prior isolation [12]

Computational Enhancements

The integration of computational methods represents a significant advancement in sustainable HPTLC analysis:

• Firefly Algorithm-optimized Partial Least Squares (FA-PLS): A sophisticated variable selection technique inspired by natural swarm intelligence that strategically identifies the most influential "brightest" variables, transforming traditional PLS modeling into a refined, precise analytical tool [2]
• Hammersley Sequence Sampling (HSS): An advanced statistical method that systematically constructs representative validation sets by dividing modeled variables into equally probable levels, ensuring comprehensive sample space coverage and improving analytical reliability while reducing material consumption and waste generation [2]
• Convolutional Neural Networks (CNNs): Deep learning architectures optimized for hierarchical feature extraction from spatially structured data, automating critical tasks including band detection, baseline correction, and spectral denoising to enhance accuracy and efficiency [12]

Diagram 1: Greener HPTLC Workflow

Environmental Impact Assessment

Quantitative Greenness Metrics

Comprehensive sustainability assessment using multiple evaluation tools provides objective measurement of environmental impact:

• AGREE Metrics: Demonstrate superior environmental profiles, with perfect AGREE scores reported for innovative HPTLC methods [2]
• GEMAM Indices: High scores (7.015 and 7.487 for dual-platform methods) indicating excellent environmental performance [2]
• Carbon Footprint: Minimal values (0.037 and 0.021 kg CO₂/sample) demonstrating low climate impact [2]
• BAGI, VIGI, and RGBfast Scores: Outstanding performance across multiple assessment frameworks (BAGI: 87.50-90.00, VIGI: 75.00-80.00, RGBfast: 81.00-85.00) [2]

Alignment with Global Sustainability Goals

Advanced HPTLC methodologies demonstrate significant alignment with United Nations Sustainable Development Goals (SDGs), particularly:

• SDG 3 (Good Health and Well-being): Through pharmaceutical quality control and safety assessment [2]
• SDG 9 (Industry, Innovation and Infrastructure): Via development of sustainable analytical technologies [2]
• SDG 12 (Responsible Consumption and Production): Through reduced solvent consumption and waste generation [2]

The NQS (Need-Quality-Sustainability) evaluation confirms this alignment, yielding overall sustainability scores of 82-83% for advanced HPTLC methods [2].

Implementation Challenges and Solutions

Barriers to Adoption

The transition from traditional linear "take-make-dispose" models to circular analytical chemistry frameworks faces several significant challenges:

• Directional Challenges: Strong focus on analytical performance (faster analyses, higher sensitivity, better precision) with insufficient consideration of sustainability factors (resource efficiency, material end-of-life) maintains a linear mindset [10]
• Coordination Failures: Limited cooperation between key stakeholders (manufacturers, researchers, routine labs, policymakers) within traditional and conservative analytical chemistry fields inhibits transition to circular processes [10]
• Regulatory Hurdles: Assessment of 174 standard methods revealed poor greenness performance, with 67% scoring below 0.2 on the AGREEprep scale (where 1 represents highest possible score), demonstrating that many official methods still rely on resource-intensive and outdated techniques [10]

The Rebound Effect

A significant consideration in green analytical chemistry is the "rebound effect," where efforts to reduce environmental impact lead to unintended consequences that offset or even negate the intended benefits. Examples include [10]:

• Novel, low-cost microextraction methods using minimal solvents and energy may lead laboratories to perform significantly more extractions than before, increasing total chemical usage and waste generation
• Automation in analytical chemistry saves time and enhances efficiency but can also lead to increased and potentially unnecessary analyses due to the capability to process large volumes with minimal human intervention

Mitigation strategies include optimizing testing protocols to avoid redundant analyses, using predictive analytics to identify when tests are truly necessary, and implementing smart data management systems to ensure only necessary data is collected and analyzed [10].

Diagram 2: Sustainability Framework

Essential Research Reagent Solutions

Table 3: Key Research Reagent Solutions for Sustainable HPTLC

Reagent/Material	Function	Green Alternatives	Application Example
Silica gel 60 F254 plates	Stationary phase for separation	Plates with reduced packaging & recyclable components	Pharmaceutical analysis (carvedilol) [9]
Ethanol-water mixtures	Green mobile phase	Bio-derived ethanol, purified water	Caffeine estimation in energy drinks [22]
Ethyl acetate-ethanol	Normal-phase mobile phase	Ethyl acetate from renewable sources	Simultaneous drug & impurity analysis [2]
Metal-organic frameworks (MOFs)	Stationary phase modification for enhanced selectivity	Sustainable synthesized MOFs	Trace contaminant detection in food [12]
Silver/gold nanoparticles	SERS substrate for detection	Controlled synthesis to minimize waste	Molecular fingerprinting in HPTLC-SERS [12]
Triethylamine/acetic acid	Mobile phase modifiers	Reduced concentration optimization	Peak tailing suppression [5]

The evolution of HPTLC toward sustainability-focused methodologies represents not merely a technical adjustment but a fundamental transformation in analytical philosophy. The integration of advanced detection systems, computational intelligence, and green chemistry principles positions HPTLC as a cornerstone technology for sustainable analytical science.

Future developments will likely focus on several key areas:

• Enhanced computational integration through deep learning architectures for automated analysis and reduced reagent consumption [12]
• Advanced material science applications including nano-engineered stationary phases and sustainable sorbent materials [12]
• Standardized greenness assessment protocols integrated into regulatory validation frameworks [10]
• Improved circular economy integration through solvent recovery systems and equipment life-cycle management

Regulatory agencies play a critical role in driving this transformation by establishing clear timelines for phasing out methods that score low on green metrics and integrating these metrics into method validation and approval processes. Financial incentives for early adopters, such as tax benefits, grants, or reduced regulatory fees, can serve as powerful motivators for change [10].

In conclusion, balancing analytical performance with environmental goals in HPTLC requires a multidimensional approach that encompasses technical innovation, philosophical shifts in method development, collaborative stakeholder engagement, and supportive regulatory frameworks. By embracing these interconnected strategies, researchers and drug development professionals can advance both scientific excellence and environmental stewardship, contributing to a more sustainable future for analytical chemistry.

Strategies for Method Transfer and Reproducibility Across Labs

In the modern analytical laboratory, the success of a method is measured not only by its performance in a single setting but by its reliable reproduction across different laboratories, instruments, and analysts. For High-Performance Thin-Layer Chromatography (HPTLC), a technique revered for its simplicity and low solvent consumption, this process presents unique challenges and opportunities. When framed within the growing mandate for green analytical chemistry, the transfer of HPTLC methods demands strategies that ensure both reproducibility and environmental responsibility. Greener sample preparation minimizes hazardous solvent use, reduces waste generation, and aligns with the principles of sustainability, all without compromising the analytical data quality essential for drug development and quality control [11] [56]. This guide provides a comprehensive technical framework for transferring and reproducing HPTLC methods, integrating green principles at every stage to achieve robust, transferable, and eco-friendly analytical procedures.

Foundational Strategies for Method Transfer

A successful analytical method transfer is a structured process that verifies the receiving laboratory can perform the method successfully as per the established acceptance criteria. Several formal approaches can be adopted, each with specific applications.

Transfer Approaches

Table 1: Analytical Method Transfer Approaches

Approach	Description	Best-Suited Context
Comparative Testing	The sending and receiving labs analyze a predetermined set of identical samples; results are compared against predefined acceptance criteria [61].	Most common for methods already validated at the transferring site; suitable for quantitative HPTLC assays.
Covalidation	The method is validated concurrently at the sending and receiving laboratories, combining data from both sites in a single validation report [62].	Efficient for new methods being rolled out to a commercial site prior to full validation.
Revalidation	The receiving laboratory performs a partial or full revalidation of the method [61].	Necessary when the original validation is insufficient or when significant changes are introduced.
Verification	A simplified transfer where the receiving lab demonstrates the method's suitability under its own conditions, often for compendial methods [62].	Used for pharmacopoeial methods (e.g., USP, EP) or platform assays already established at the receiving lab.

The choice of strategy should be risk-based, considering the method's complexity, the receiving laboratory's familiarity with the technique, and the criticality of the test [62].

The Central Role of Communication and Documentation

Beyond technical protocols, effective transfer hinges on robust communication and documentation. Key elements include:

• Knowledge Transfer: The sending unit must provide the receiving unit with all relevant data, including the validated method description, validation report, known performance characteristics, and "tacit knowledge" or practical tips not captured in the written procedure [61].
• Transfer Protocol: A formal protocol must be agreed upon, detailing the objective, responsibilities, experimental design, and acceptance criteria for the transfer [61]. For an HPTLC assay, this typically includes criteria for the absolute difference in the mean results of the active ingredient between labs (e.g., ≤ 2-3%) [61].
• Training: For complex or novel HPTLC methods, on-site training can be crucial for overcoming the learning curve associated with specific techniques like sample application or derivatization.

Ensuring HPTLC Reproducibility: Key Variables and Control

Reproducibility in HPTLC is highly dependent on controlling specific procedural variables. A method designed with reproducibility in mind significantly eases the transfer process.

Critical Phases and Variables

Diagram: HPTLC Workflow and Key Control Points for Reproducibility

The following variables, identified in forensic and pharmaceutical studies, are critical for reproducible HPTLC results [63]:

• Plate Selection and Pre-treatment: The type of HPTLC plate (e.g., silica gel 60 F254) and its pre-washing and activation (e.g., heating at 110-120°C) are vital for achieving a uniform baseline and consistent analyte retention [63] [33].
• Chamber Saturation: The degree of mobile phase vapor saturation in the development chamber critically impacts the velocity of the mobile phase front and the resulting retardation factor (Rf) values. A standardized saturation time (e.g., 20-30 minutes) is essential [63].
• Development Distance: Controlling the precise distance the mobile phase travels is crucial, as Rf values can show a non-linear relationship with migration distance. Using an Automatic Developing Chamber (ADC) can automate this process, improving reproducibility [63] [33].
• Mobile Phase Stability: The composition of multi-component eluents should be monitored, as evaporation of volatile components can alter solvent strength and selectivity over time, leading to Rf shifts [63].

Method Validation for Transfer Readiness

A method must be properly validated before transfer to ensure it is "fit-for-purpose." The International Council for Harmonisation (ICH) guidelines outline key validation parameters [64] [14]:

• Accuracy and Precision: Demonstrating that the method is both correct and repeatable is fundamental. This includes intra-day and inter-day precision, often assessed by the relative standard deviation (RSD) of multiple measurements [64].
• Specificity: The method must be able to unequivocally assess the analyte in the presence of potential interferents, like excipients or sample matrix components [64]. For botanicals, this means distinguishing the target species' unique chemical fingerprint [64].
• Robustness: A robust method can withstand small, deliberate variations in normal operating parameters (e.g., mobile phase composition ±0.5%, development time ±5%) without adverse effects, indicating its resilience during transfer [64].
• Linearity and Range: The method should demonstrate a directly proportional response to the analyte concentration across the specified range [32] [14].

Green Sample Preparation in HPTLC: Protocols for Transfer

Integrating green sample preparation techniques not only reduces environmental impact but also often simplifies the analytical procedure, enhancing its transferability.

Green Extraction and Sample Application

Table 2: Green Sample Preparation Techniques for HPTLC

Technique	Principle & Green Advantage	Example Protocol in HPTLC Context
Miniaturized/Solid-Phase Extraction (SPE)	Uses small solvent volumes; effective for sample clean-up and analyte enrichment [56].	Extract morin from plant heartwood using minimized solvent. After extraction, concentrate and apply as bands on HPTLC plate for analysis [65].
QuEChERS	"Quick, Easy, Cheap, Effective, Rugged, and Safe"; employs acetonitrile and salts for extraction and dispersive SPE for clean-up [56].	Ideal for complex food/biological matrices (e.g., bovine tissue). Homogenize tissue, extract with acetonitrile, salt out, and use dispersive SPE to clean extract before HPTLC application [14].
Direct Analysis/ Minimal Preparation	Eliminates or drastically reduces sample preparation steps [56].	For a clean matrix, a simple filtration [56] or dilution [32] of a pharmaceutical dosage form in methanol can suffice before band application.
Natural Deep Eutectic Solvents (NADES)	Uses biodegradable, low-toxicity solvents from natural compounds as green extraction media [11].	Replace conventional organic solvents with NADES for extracting natural products from plant materials before chromatographic analysis.

Exemplary Experimental Protocol

A validated HPTLC method for simultaneous quantification of Ivabradine (IVA) and Metoprolol (MET) exemplifies a robust and partially green protocol [32]:

• Chromatographic Conditions:

  • Stationary Phase: HPTLC silica gel 60 F254 plates.
  • Mobile Phase: Chloroform: Methanol: Formic Acid: Ammonia (8.5:1.5:0.2:0.1, v/v).
  • Development: Ascending development in a twin-trough glass chamber saturated with mobile phase vapor for 30 minutes at room temperature. Migration distance: 80 mm.
  • Detection & Quantification: Densitometric scanning at 275 nm (UV absorbance) and fluorescence mode with excitation at 260 nm.

• Sample Preparation:

  • Bulk Drugs: Dissolve pure IVA and MET in methanol to prepare stock solutions (1 mg/mL). Further dilute with methanol to working concentrations.
  • Pharmaceutical Dosage Form: Powder tablets, dissolve in methanol, sonicate, and filter. Dilute the filtrate to the working concentration range.

• Green Assessment: The method was evaluated using the Analytical Eco-Scale and Green Analytical Procedure Index (GAPI), confirming its relatively green profile, though the use of chloroform presents an opportunity for further greening [32].

The Scientist's Toolkit: Essential Reagents and Materials

Table 3: Key Research Reagent Solutions for HPTLC Method Transfer

Item	Function in HPTLC	Green Considerations
HPTLC Plates (Silica gel 60 F254)	The stationary phase for separation. Coated with a fluorescence indicator for UV detection.	Pre-coated plates offer consistency. Proper disposal is required.
Mobile Phase Solvents	The liquid phase that moves through the stationary phase, carrying the sample components.	Prefer less hazardous solvents (e.g., ethanol, ethyl acetate) over toxic ones (e.g., chloroform, benzene) [11].
Green Extraction Solvents (e.g., NADES)	Biodegradable solvents for sample preparation, offering low toxicity [11].	Directly reduce the environmental footprint of the sample preparation step.
Reference Standards	Highly characterized substances used to calibrate the analytical procedure and ensure accuracy.	Sourced from reputable suppliers; proper handling and storage are critical.
Derivatization Reagents	Chemicals sprayed onto the plate to visualize compounds that are not visible under UV light.	Choose less toxic reagents where possible. Employ micro-spraying techniques to minimize volume used.

Assessing the Greenness and Reproducibility of Transferred Methods

The final step in a modern method transfer is the objective evaluation of the method's environmental impact and its reproducible performance.

• Greenness Assessment Tools: Employ standardized metrics like the Analytical Eco-Scale, GAPI, and AGREE to score the method's greenness. These tools evaluate factors such as solvent toxicity, energy consumption, and waste production [32] [14]. A method using ethanol/water-based mobile phases and minimal sample preparation will score higher than one using hazardous solvents and waste-intensive extractions.
• Post-Transfer Monitoring: Reproducibility is confirmed not just during the transfer exercise but through ongoing performance verification in the receiving laboratory. This includes system suitability testing and continuous data review to ensure the method remains in a state of control, completing the analytical method lifecycle [62].

By adopting a holistic strategy that prioritizes rigorous control of chromatographic variables, formalized transfer protocols, and the integration of green chemistry principles, laboratories can ensure that HPTLC methods are not only reproducible across sites but also aligned with the goals of sustainable science.

Leveraging Chemometric Tools for Method Optimization

The integration of chemometric tools represents a paradigm shift in high-performance thin-layer chromatography (HPTLC), transforming it from a conventional separation technique into a sophisticated analytical platform that aligns with the principles of Green Analytical Chemistry (GAC) and White Analytical Chemistry (WAC). This synergy addresses critical challenges in pharmaceutical analysis, particularly in the simultaneous quantification of active pharmaceutical ingredients (APIs) alongside their mutagenic impurities—a task that conventional methodologies often struggle to perform efficiently [27]. The fundamental strength of chemometrics lies in its ability to extract maximum information from complex chemical data through mathematical and statistical approaches, thereby enabling the development of robust, precise, and environmentally conscious analytical methods.

The application of chemometrics is particularly valuable for enhancing the sustainability profile of HPTLC methods. Traditional method development often relies on a "trial and error" approach for selecting parameters like the mobile phase, a process that can be time-consuming and generate significant solvent waste [66]. Chemometrics replaces this with structured, algorithm-driven optimization, systematically navigating the complex multivariable space of analytical parameters to identify optimal conditions with minimal experimental runs. This not only accelerates method development but also significantly reduces solvent consumption, energy use, and hazardous waste generation, directly contributing to the core objectives of greener sample preparation and analysis [27] [67].

Fundamental Chemometric Tools for HPTLC Optimization

Experimental Design for Method Development

The foundation of effective chemometric optimization lies in strategic experimental design, which ensures that data collection is both efficient and informative. Traditional one-factor-at-a-time (OFAT) approaches are inefficient for understanding the complex interactions between multiple HPTLC parameters, such as mobile phase composition, chamber saturation time, and relative humidity. Mixture experimental designs, such as the 52-mixture design used for calibrating the simultaneous quantification of bisoprolol, amlodipine, and a mutagenic impurity, allow researchers to systematically explore the entire composition space of a mobile phase while using a minimal number of experimental runs [27]. This approach is crucial for developing methods capable of resolving multiple compounds with high precision, as it captures the synergistic effects of solvent components on separation efficiency.

Advanced Algorithms for Variable Selection and Validation

Once a foundational dataset is established through careful experimental design, advanced algorithms further refine the analytical model.

• Firefly Algorithm (FA) for Variable Selection: Inspired by the flashing behavior of fireflies, this swarm intelligence algorithm addresses the challenge of managing numerous spectroscopic variables with limited samples. FA intelligently selects the most informative wavelengths or variables for multivariate calibration, discarding uninformative or noisy data. In HPTLC, when coupled with techniques like partial least squares (PLS) regression, it creates a refined FA-PLS model that significantly enhances predictive capability compared to traditional full-spectrum models [27].

• Hammersley Sequence Sampling (HSS) for Validation: A critical innovation in chemometric modeling is the use of HSS for constructing validation sets. Unlike conventional random splitting, which can introduce bias, HSS methodically partitions the concentration space into equally probable levels, ensuring the validation set is uniformly representative of the entire experimental domain. This eliminates sampling bias and substantially improves the reliability and robustness of the chemometric model for real-world application [27].

The workflow below illustrates how these tools are integrated into the HPTLC method development process.

Experimental Protocols and Workflows

Protocol: FA-PLS Model Development for Spectrophotometric Data

This protocol details the development of a Firefly Algorithm-optimized Partial Least Squares (FA-PLS) model, as demonstrated for the simultaneous analysis of bisoprolol fumarate, amlodipine besylate, and 4-hydroxybenzaldehyde [27].

• Step 1: Sample Preparation and Experimental Design

  • Prepare standard solutions of all analytes at varying concentration levels.
  • Use a 52 mixture experimental design to create the calibration set (25 mixtures) spanning the expected concentration ranges of the analytes. This ensures the model is built on a representative dataset.

• Step 2: Spectral Data Acquisition

  • Acquire UV-Vis absorption spectra for all calibration mixtures using a double-beam spectrophotometer. Recommended parameters include a fast scan mode, 1.0 nm slit width, and a 0.1 nm sampling interval [27].

• Step 3: Firefly Algorithm Execution for Variable Selection

  • Implement the FA using a computational environment like MATLAB with the PLS Toolbox.
  • Initialize the firefly population, where each firefly represents a subset of wavelengths from the full spectrum.
  • Define the attractiveness function (light intensity) based on the predictive performance (e.g., root mean square error of cross-validation) of a PLS model built using the selected wavelengths.
  • Iterate the algorithm to allow fireflies to move toward brighter neighbors, converging on the optimal wavelength combination that maximizes predictive accuracy.

• Step 4: Model Construction and Validation with HSS

  • Construct the final PLS model using only the wavelengths selected by the FA.
  • For validation, employ Hammersley Sequence Sampling (HSS) to select an independent validation set that provides uniform coverage of the concentration space, thereby eliminating the bias of random selection and ensuring a rigorous test of model robustness.

Protocol: Smartphone-Based HPTLC with Chemometric Detection

This protocol outlines a green alternative to conventional densitometry by coupling HPTLC with smartphone detection and image analysis software [67].

• Step 1: Chromatographic Separation

  • Apply samples as bands onto HPTLC silica gel plates using an automated applicator.
  • Develop the plates in a saturated twin-trough chamber with a pre-optimized, eco-friendly mobile phase (e.g., ethyl acetate:methanol:acetone:glacial acetic acid, 3:6:1:0.5, v/v).
  • Air-dry the developed plates completely.

• Step 2: Derivatization and Image Capture

  • Visualize the separated bands by immersing the plate in a derivatization reagent (e.g., modified Dragendorff's reagent for Naltrexone and Bupropion), followed by spraying with a 5% w/v sodium nitrite solution [67].
  • Place the derivatized plate under a daylight illumination box. Capture an image using a smartphone camera (e.g., 32 MP) mounted at a fixed distance (e.g., 15 cm) to ensure consistency.

• Step 3: Image Analysis and Quantification

  • Option A (Using ImageJ Software): Transfer the image to a computer and open it in ImageJ. Use the "Rectangular Selection" tool to define each sample track. Generate lane profiles via the "Gels" menu in the "Analyze" dropdown. Use the software's tools to measure the integrated peak area corresponding to each analyte spot.
  • Option B (Using Color Picker App): Analyze the image directly on the smartphone using the Color Picker application. Use the app's analysis methods to quantify the intensity or area of the colored spots.

• Step 4: Data Processing and Calibration

  • Construct calibration curves by plotting the measured peak areas (from ImageJ or Color Picker) or color intensity against the corresponding analyte concentrations.

Table 1: Key Reagent Solutions for Chemometric-Optimized HPTLC

Reagent/Solution	Function in the Workflow	Green & Practical Considerations
Eco-friendly Mobile Phases (e.g., Ethyl acetate–ethanol) [27]	Solvent system for chromatographic separation.	Replaces toxic solvents; reduces environmental impact and safety hazards.
Derivatization Reagents (e.g., Dragendorff's reagent) [67]	Visualizes non-UV absorbing compounds for smartphone detection.	Enables the use of cost-effective, portable detection methods.
Chemometric Software (e.g., MATLAB, PLS Toolbox, ImageJ) [27] [67]	Data processing, model optimization, and image analysis.	Critical for variable selection, experimental design, and enabling alternative detection.
HSS Algorithm Script	Creates unbiased, representative validation sets.	Ensures model robustness and reliability, reducing the need for repeated experiments.

Applications and Performance Metrics

The application of chemometric-optimized HPTLC methods has demonstrated superior performance across various fields, from pharmaceutical quality control to natural product analysis. The table below summarizes quantitative performance data from recent studies.

Table 2: Analytical Performance of Chemometric-Optimized HPTLC Methods

Application / Analytes	Analytical Technique	Key Chemometric Tool	Linear Range	Detection Limit	Sustainability Score	Reference
Bisoprolol, Amlodipine, Impurity	HPTLC-Densitometry	FA-PLS, HSS	Not Specified	3.56–20.52 ng/band	AGREE: PerfectGAPI: Perfect	[27]
Bisoprolol, Amlodipine, Impurity	Spectrophotometry	FA-PLS, HSS	Not Specified	0.011–0.120 μg/mL	AGREE: PerfectGAPI: Perfect	[27]
Naltrexone, Bupropion	Smartphone-HPTLC	ImageJ Software	0.4–24 μg/band (NAL)0.6–18 μg/band (BUP)	Not Specified	High WAC & AGREE scores	[67]
Clusia Species	HPTLC-Chemometrics	Chemometric Profiling	Semi-quantitative	Semi-quantitative	Rapid, cost-effective chemotyping	[68]
Florfenicol, Meloxicam	HPTLC-Densitometry	Internal Standardization	0.03–3.00 μg/band (MEL)0.50–9.00 μg/band (FLR)	Not Specified	Validated as eco-friendly	[14]

The data in Table 2 underscores the effectiveness of chemometric tools. The FA-PLS model achieves remarkably low detection limits in the sub-μg/mL range, highlighting the enhanced sensitivity gained from intelligent variable selection [27]. Furthermore, the smartphone-based HPTLC method demonstrates that innovative, low-cost detection coupled with simple image analysis software can yield performance suitable for pharmaceutical analysis while dramatically improving accessibility and reducing capital equipment costs [67]. In natural product research, chemometric analysis of HPTLC fingerprints has proven to be a rapid and cost-effective strategy for discriminating between chemotypes of Clusia species, showcasing its utility beyond quantitative analysis [68].

Sustainability and Greenness Assessment

A cornerstone of modern method development is the rigorous assessment of environmental impact, and chemometric-optimized HPTLC methods excel in this domain. These methods are systematically evaluated using multiple metric tools to provide a comprehensive sustainability profile [27] [67].

• AGREE (Analytical GREEnness Metric): This tool provides a clock-shaped pictogram with a score from 0 to 1. The methods described have achieved perfect or near-perfect scores, indicating compliance with all 12 principles of green analytical chemistry [27] [67].
• GAPI (Green Analytical Procedure Index): This pictogram evaluates the environmental impact of each step of an analytical method. The discussed methods have achieved perfect GAPI scores, confirming their low hazardous impact across the entire workflow [27].
• White Analytical Chemistry (WAC): This approach provides a more balanced assessment by integrating three criteria: analytical performance (Red), ecological impact (Green), and practical & economic effectiveness (Blue). The combination of these colors yields an overall "whiteness" score. Methods leveraging smartphone detection and chemometric optimization have demonstrated high WAC scores, confirming their sustainability without compromising analytical quality or practicality [67].

The commitment to sustainability is quantifiable. One study reported minimal carbon footprints of 0.037 and 0.021 kg CO₂ per sample for the developed HPTLC and FA-PLS methods, respectively [27]. Furthermore, the alignment with United Nations Sustainable Development Goals (SDGs), particularly SDG 3 (Good Health and Well-being), SDG 9 (Industry, Innovation and Infrastructure), and SDG 12 (Responsible Consumption and Production), has been formally established, yielding overall sustainability scores of 82-83% [27]. This demonstrates that the integration of chemometrics is not merely a technical improvement but a fundamental advancement toward responsible and sustainable scientific practice.

Assessing Method Greenness, Practicality, and Compliance

Green Analytical Chemistry (GAC) aims to minimize the environmental impact of chemical analyses by addressing critical issues such as the generation of toxic laboratory waste and the use of solvents and reagents hazardous to human health or the environment [69]. The importance of GAC emerged soon after the introduction of Green Chemistry (GC) as a specific branch, largely due to the inability of the original GC principles to fully address the unique demands of the analytical field [69]. This led to the development of the 12 principles of GAC, providing a more suitable framework for greener analytical practices [69]. In subsequent years, several metric tools have been developed to assess and harmonize the compliance of analytical methods with GAC assumptions, leading to the creation of comprehensive assessment frameworks including AGREE, AGREEprep, ComplexGAPI, and BAGI [69] [70].

The AGREE Metric Tool

The Analytical GREEnness (AGREE) metric approach is a comprehensive assessment tool that evaluates analytical procedures against all 12 principles of Green Analytical Chemistry [71]. This calculator transforms each GAC principle into a score on a unified 0–1 scale, then calculates a final assessment score based on these criteria [71]. The tool offers a user-friendly, open-source software that generates an easily interpretable pictogram showing both the overall score and performance across individual criteria [71].

Assessment Criteria and Methodology

AGREE evaluates analytical methods based on the 12 SIGNIFICANCE principles of GAC, which comprehensively describe the analytical procedure's greenness [71]. The input criteria refer to:

• Material requirements (both quality and quantity)
• Waste generation
• Energy consumption
• Safety of the analyst
• General approach to the analytical procedure

Each of the 12 input variables is transformed into a common scale in the 0–1 range, and the final assessment result is the product of the assessment results for each principle [71]. The output is a clock-like graph with the overall score and color representation in the middle, where values close to 1 and dark green color indicate a greener procedure [71].

Software and Implementation

AGREE software is freely available as open-source software downloadable from https://mostwiedzy.pl/AGREE [71]. The assessment procedure is straightforward, with an automatically generated graph and assessment report [71]. The pictogram clearly displays the performance of the procedure in each of the assessment criteria reflected by the color in the segment with the number corresponding to each criterion, while the weight assigned to each principle is reflected in the width of its corresponding segment [71].

The AGREEprep Metric Tool

AGREEprep is the first metric tool specifically designed for assessing the greenness of analytical sample preparation [69]. Sample preparation has been identified as one of the most critical steps from the GAC point of view due to substantial requirements in solvents, sorbents, reagents, energetic inputs, and other consumable materials [69]. AGREEprep addresses the inadequacy of general GAC metric tools for providing sufficient accuracy and specificity for gauging progress toward greening sample preparation [69].

Assessment Criteria and Methodology

AGREEprep is based on 10 categories of impact that correspond to the ten principles of green sample preparation (GSP) [69]. The criteria include:

• Favoring in situ sample preparation
• Using safer solvents and reagents
• Targeting sustainable, reusable, and renewable materials
• Minimizing waste
• Minimizing sample, chemical and material amounts
• Maximizing sample throughput
• Integrating steps and promoting automation
• Minimizing energy consumption
• Choosing the greenest possible post-sample preparation configuration for analysis
• Ensuring safe procedures for the operator

Each criterion is recalculated to a 0–1 scale sub-score, which are then used to calculate the final assessment score [69]. The tool also allows differentiation between criteria importance by assigning them weights [69].

Software and Output Interpretation

The assessment is performed using open access, intuitive software that produces an easy-to-read pictogram with information on the total performance and structure of threats [69]. The result is a colorful round pictogram with a number in the center, where the inner circle color and the assigned overall score indicate the overall sample preparation greenness performance [69]. Possible values range from 0 to 1, with 1 representing the best performance in all criteria or no sample preparation step [69]. Around the circle, 10 parts represent each assessment criterion, with colors from red through yellow to green indicating the performance in each area [69].

The ComplexGAPI and ComplexMoGAPI Tools

The Green Analytical Procedure Index (GAPI) was developed as a metric system that utilizes five distinct colored pentagons to evaluate the environmental footprint of the analytical process at different stages [72]. This was later expanded through the Complementary Green Analytical Procedure Index (ComplexGAPI) to include additional fields pertaining to the processes performed prior to the analytical procedure itself [72]. More recently, a refined tool named ComplexMoGAPI has been introduced, merging the visual appeal of ComplexGAPI with precise total scores [72].

Assessment Methodology

ComplexGAPI and its modified version, ComplexMoGAPI, provide a visual assessment tool that expands on the original GAPI by adding extra fields to evaluate sample collection, preservation, transport, and storage [72]. The accompanying software streamlines the application, facilitating quicker and simpler evaluations [72]. This software is available as open source on bit.ly/ComplexMoGAPI [72].

The tool offers a pictogram-based approach that considers multiple aspects of the analytical procedure, creating a comprehensive visual representation of the method's environmental impact [72]. The recent modification (ComplexMoGAPI) adds a scoring system that allows for easier comparison between different analytical procedures [72].

The BAGI Metric Tool

The Blue Applicability Grade Index (BAGI) is a novel metric tool introduced in 2023 for evaluating the practicality of an analytical method [70]. This tool can be considered complementary to well-established green metrics, as it focuses primarily on the practical aspects of White Analytical Chemistry [70]. BAGI is inspired by the RGB model, where blue represents productivity and practical/economic efficiency [70].

Assessment Criteria and Methodology

BAGI evaluates ten main attributes of an analytical method's practicality [70]:

• The type of analysis (qualitative, screening, quantitative, confirmatory)
• The number of analytes simultaneously determined
• The analytical technique and required instrumentation
• The number of samples that can be simultaneously treated
• The type of sample preparation
• The number of samples that can be analyzed per hour
• The type of reagents and materials used
• The requirement for preconcentration
• The automation degree
• The amount of sample

Each attribute is scored using four discrete scores of equal weights (10, 7.5, 5.0, and 2.5 points), corresponding to different shades of blue in the assessment pictogram [70]. The tool also considers the field of application to adjust the bias and treat all methods at realistic ranges [70].

Software and Output

To facilitate its use, a simple, open-source application was created (mostwiedzy.pl/bagi), accompanied by a web application available at bagi-index.anvil.app [70]. The assessment generates an asteroid pictogram together with the respective score, allowing easy identification of both strong and weak points of a method in terms of practicality and applicability [70].

Comparative Analysis of Assessment Tools

Side-by-Side Tool Comparison

Table 1: Comprehensive Comparison of Greenness Assessment Tools

Feature	AGREE	AGREEprep	ComplexGAPI/ComplexMoGAPI	BAGI
Primary Focus	Overall analytical method greenness [71]	Sample preparation step greenness [69]	Comprehensive analytical procedure greenness [72]	Method practicality and applicability [70]
Number of Criteria	12 principles of GAC [71]	10 principles of GSP [69]	Multiple criteria across stages [72]	10 practicality attributes [70]
Scoring System	0-1 scale [71]	0-1 scale [69]	Pictogram with recent scoring addition [72]	0-100 scale (10 attributes × 10 max) [70]
Weighting Flexibility	Yes, user-defined weights [71]	Yes, default weights with customization [69]	Not specified	Equal weights for attributes [70]
Visual Output	Clock-like pictogram [71]	Circular pictogram [69]	Colored pentagons [72]	Asteroid pictogram [70]
Software Availability	Free, open-source [71]	Free, open-source [69]	Free, open-source [72]	Free, open-source web and desktop [70]
Complementary Role	Comprehensive greenness assessment	Sample preparation specific	Expanded procedural assessment	Practicality focus, complements green metrics [70]

Tool Selection Guidance

Selecting the appropriate assessment tool depends on the specific focus of the evaluation:

• AGREE: Most suitable for comprehensive assessment of entire analytical methods against all 12 GAC principles [71]
• AGREEprep: Essential when sample preparation is the primary concern or requires specialized evaluation [69]
• ComplexGAPI/ComplexMoGAPI: Ideal for visual comparative assessments of multiple methods [72]
• BAGI: Best for evaluating practicality and applicability in routine laboratory settings, complementing greenness assessments [70]

For a holistic evaluation, using multiple tools synergistically provides the most comprehensive understanding of a method's environmental and practical performance [73]. Recent research has demonstrated the effectiveness of applying multiple tools to gain complementary insights [73] [74].

Experimental Protocols and Applications

Case Study: Pharmaceutical Analysis

In a recent study developing HPLC and HPTLC methods for analyzing aspirin and vonoprazan, researchers applied multiple assessment tools to validate greenness and sustainability [75]. The methods were assessed using AGREE, ComplexMoGAPI, and the RGB 12-model, which demonstrated the greenness and sustainability of the methods for routine analysis of the newly marketed formulation [75].

The experimental protocol involved:

• HPLC-DAD separation using C18 column with isocratic elution
• HPTLC on silica plates with specific mobile phase composition
• Method validation according to ICH guidelines
• Comprehensive greenness assessment using multiple metrics

This approach confirmed that the developed methods were ideal for routine quality control while maintaining environmental sustainability [75].

Case Study: Veterinary Drug Residue Analysis

A green HPTLC method was developed for quantification of florfenicol and meloxicam in bovine tissues with sustainability assessment [14]. The experimental protocol included:

• HPTLC-densitometric method with specific mobile phase optimization
• Method validation per ICH guidelines demonstrating linearity within specified ranges
• Greenness assessment using five different tools to confirm eco-friendly nature

The environmental impact was evaluated using multiple greenness assessment tools, including greenness, whiteness, and blueness metrics, confirming the method's eco-friendly nature [14].

Case Study: GC-MS Method for Pharmaceutical Analysis

A green GC-MS method was developed for rapid analysis of paracetamol/metoclopramide in pharmaceuticals and plasma [76]. The experimental approach featured:

• Fast GC-MS separation (5 min runtime) using high-polarity column
• Full validation per ICH guidelines
• Greenness assessment via BAGI tool (score: 82.5) and other metrics
• Application to both pharmaceutical formulations and biological samples

This method demonstrated environmental superiority over conventional approaches while maintaining high sensitivity, accuracy, and throughput [76].

Essential Research Reagent Solutions

Table 2: Key Research Reagents and Materials for Green HPTLC Research

Reagent/Material	Function in Green HPTLC	Green Considerations
Ethyl Acetate	Mobile phase component [75] [14]	Preferred over more hazardous solvents [69]
Ethanol	Solvent for sample preparation [75] [14]	Safer alternative to methanol or acetonitrile [69]
Water	Solvent for sample preparation [75]	Greenest solvent available [69]
Silica Gel HPTLC Plates	Stationary phase for separation [75] [14]	Minimal material consumption through miniaturization [69]
Methanol	Sample solvent [75] [14]	Use minimized in green approaches [69]
Acetonitrile	Mobile phase component (conventional HPLC) [75]	Targeted for reduction/replacement in green methods [69]
Triethylamine	Mobile phase modifier [14]	Use minimized and optimized [69]
Glacial Acetic Acid	Mobile phase component [14]	Use minimized and optimized [69]

Workflow and Decision Pathways

Diagram 1: Greenness Assessment Tool Selection Workflow. This diagram illustrates the decision pathway for selecting appropriate assessment tools based on analytical method evaluation goals.

The development of comprehensive greenness assessment tools represents a significant advancement in promoting sustainable practices in analytical chemistry. AGREE, AGREEprep, ComplexGAPI, and BAGI each offer unique perspectives and specialized assessment capabilities that, when used in combination, provide researchers with a robust framework for evaluating and improving their analytical methods. For HPTLC research focused on greener sample preparation, these tools facilitate method optimization, comparative analysis, and validation of environmental claims. As the field continues to evolve, the integration of these assessment metrics into routine method development and validation protocols will be essential for advancing the principles of Green Analytical Chemistry and promoting sustainable pharmaceutical analysis.

Validating Green HPTLC Methods per ICH Guidelines

The pharmaceutical industry faces increasing pressure to adopt sustainable practices while maintaining rigorous quality standards. High-performance thin-layer chromatography (HPTLC) has emerged as a powerful analytical technique that aligns with green analytical chemistry (GAC) principles while providing robust validation capabilities compliant with ICH guidelines [66] [77]. This technical guide explores the framework for developing and validating green HPTLC methods within the context of a broader thesis on fundamentals of greener sample preparation for HPTLC research.

Green HPTLC method validation represents the intersection of regulatory compliance, analytical science, and environmental responsibility. The ICH Q2(R2) guideline provides the foundational requirements for validation of analytical procedures, defining key parameters such as accuracy, precision, specificity, and linearity that must be demonstrated for any analytical method used in pharmaceutical analysis [78]. Simultaneously, the ten principles of green sample preparation (GSP) establish a roadmap for developing overall greener analytical methodologies, emphasizing safe solvents/reagents, minimized waste generation, and reduced energy demand [79]. The synergy between these frameworks enables researchers to create methods that are both scientifically valid and environmentally conscious.

HPTLC itself offers inherent green advantages over other chromatographic techniques, including minimal sample preparation, reduced solvent consumption per sample, and the ability to analyze multiple samples simultaneously on a single plate [66] [77]. These characteristics make it particularly suitable for implementing green chemistry principles in pharmaceutical analysis. Furthermore, HPTLC provides straightforward information about effects arising from individual compounds in complex samples, combines chromatographic separation with effect-directed detection, and helps select important compounds for further characterization [66].

Theoretical Foundations: ICH Q2(R2) Validation Parameters

The ICH Q2(R2) guideline, "Validation of Analytical Procedures," provides a comprehensive framework for demonstrating that analytical methods are suitable for their intended purpose [78]. This guideline applies to new or revised analytical procedures used for release and stability testing of commercial drug substances and products, both chemical and biological/biotechnological. For HPTLC methods, the following validation parameters must be established:

• Accuracy: The closeness of agreement between the value which is accepted either as a conventional true value or an accepted reference value and the value found. For HPTLC methods, accuracy is typically demonstrated through recovery studies by spiking known amounts of analyte into sample matrix [80].

• Precision: The closeness of agreement between a series of measurements obtained from multiple sampling of the same homogeneous sample under the prescribed conditions. Precision should be investigated at repeatability, intermediate precision, and reproducibility levels [16].

• Specificity: The ability to assess unequivocally the analyte in the presence of components which may be expected to be present, including impurities, degradation products, and matrix components. Forced degradation studies are essential for demonstrating specificity [9].

• Detection Limit (LOD) and Quantitation Limit (LOQ): The lowest amount of analyte in a sample which can be detected (LOD) or quantitatively determined (LOQ) with suitable precision and accuracy [16] [80].

• Linearity and Range: The linearity of an analytical procedure is its ability (within a given range) to obtain test results directly proportional to the concentration (amount) of analyte in the sample. The range is the interval between the upper and lower concentration (amounts) of analyte for which it has been demonstrated that the analytical procedure has a suitable level of precision, accuracy, and linearity [9] [16].

• Robustness: A measure of the procedure's capacity to remain unaffected by small, deliberate variations in method parameters and provides an indication of its reliability during normal usage [80].

Table 1: ICH Q2(R2) Validation Parameters and Their Acceptance Criteria for HPTLC Methods

Validation Parameter	Experimental Approach	Typical Acceptance Criteria
Accuracy	Recovery studies at 50%, 100%, 150% of target concentration	Recovery: 98-102%
Precision	Repeatability (n=6) at 100% concentration	RSD ≤ 2.0%
Specificity	Forced degradation studies (acid, base, oxidative, thermal, photolytic stress)	Baseline separation of analyte from degradants
LOD/LOQ	Signal-to-noise ratio or based on standard deviation of response and slope	LOD: S/N ≈ 3:1, LOQ: S/N ≈ 10:1
Linearity	Minimum of 5 concentration levels	Correlation coefficient (r²) ≥ 0.995
Range	Established from linearity studies	From LOQ to 120-150% of target concentration
Robustness	Deliberate variations in mobile phase composition, development distance, chamber saturation time	RSD of results ≤ 2.0%

Green Assessment Metrics for HPTLC Methods

The greenness of analytical methods can be systematically evaluated using multiple assessment tools. These metrics provide objective measures of environmental impact and help researchers optimize methods for sustainability:

• NEMI (National Environmental Methods Index) Scale: Provides a simple pictogram indicating whether a method meets four green criteria: persistent, bioaccumulative, and toxic (PBT); hazardous; corrosive; and waste generation [9].

• AGREE (Analytical GREEnness) Metric: Incorporates all twelve principles of green analytical chemistry, providing a comprehensive score between 0 and 1, with 1 representing ideal greenness [16].

• Analytic Eco-Scale: Assigns penalty points to parameters that deviate from ideal green analysis, with scores above 75 considered excellent green analysis [18].

• GAPI (Green Analytical Procedure Index): A multi-criteria metric that evaluates the environmental impact of the entire analytical procedure [9].

• White Analytical Chemistry (WAC): Extends beyond environmental impact to include methodological and practical effectiveness, creating a balance between analytical quality, practicality, and ecological aspects [9].

Table 2: Comparison of Green Assessment Tools for HPTLC Methods

Assessment Tool	Key Principles Evaluated	Scoring System	Advantages
NEMI Scale	PBT, hazardous, corrosive, waste	Pass/Fail for four criteria	Simple, visual representation
AGREE	All 12 principles of GAC	0-1 scale (1 = ideal)	Comprehensive, incorporates all GAC principles
Analytic Eco-Scale	Reagents, instruments, waste	Penalty points (higher score = greener)	Simple calculation, identifies problem areas
GAPI	Entire procedure from sampling to waste disposal	15 criteria with color coding	Comprehensive life cycle assessment
WAC	Analytical quality, practicality, ecological impact	Three-dimensional radar plot	Balances quality with greenness

Experimental Protocols for Green HPTLC Method Development and Validation

Development of an Eco-Friendly HPTLC Method for Carvedilol

A stability-indicating HPTLC method was developed for carvedilol using green principles [9]. The mobile phase consisted of toluene, isopropanol, and ammonia (7.5:2.5:0.1, v/v/v), specifically optimized to avoid carcinogenic solvents. Separation was achieved on silica gel 60F254 TLC plates with ascending development to 75 mm at room temperature. The method demonstrated linearity in the range of 20-120 ng/band with an R² value of 0.995. Forced degradation studies revealed effective separation of carvedilol and its degradants, with an Rf value of 0.44 ± 0.02 for the parent compound. The greenness assessment using NEMI, AGREE, and White Analytical Chemistry metrics confirmed the method's environmental benefits compared to published chromatographic methods [9].

Green HPTLC Method for Tenoxicam Determination

An eco-friendly HPTLC method was developed for tenoxicam (TNX) using ethanol/water/ammonia solution (50:45:5 v/v/v) as the mobile phase [16]. The method was linear in the range of 25-1400 ng/band, with excellent accuracy (% recoveries = 98.24-101.48) and precision (% RSD = 0.87-1.02). The AGREE score was 0.75, indicating an outstanding greenness profile. TNX was found to be highly stable under acidic, base, and thermal stress conditions but completely decomposed under oxidative stress. The method was successfully applied to commercial tablets and capsules, demonstrating its suitability for routine analysis [16].

Simultaneous Determination of COVID-19 Therapeutics

A green, sensitive HPTLC method was developed for simultaneous quantification of remdesivir, linezolid, and rivaroxaban in spiked human plasma [18]. The mobile phase consisted of dichloromethane and acetone (8.5:1.5, v/v), with detection at 254 nm. Well-resolved peaks were observed with Rf values of 0.23, 0.53, and 0.72 for remdesivir, linezolid, and rivaroxaban, respectively. The method was linear over concentration ranges of 0.2-5.5 μg/band, 0.2-4.5 μg/band, and 0.1-3.0 μg/band for the three analytes, respectively. The method showed outstanding recoveries (98.3-101.2%) when applied to pharmaceutical formulations and spiked human plasma, with greenness confirmed by Analytical Eco-Scale, GAPI, and AGREE metrics [18].

Green HPTLC Method Validation Workflow

The Scientist's Toolkit: Essential Materials and Reagents

Successful development and validation of green HPTLC methods requires specific materials and reagents that balance analytical performance with environmental considerations:

Table 3: Essential Research Reagent Solutions for Green HPTLC

Item	Function	Green Considerations
Silica gel 60 F254 HPTLC plates	Stationary phase for separation	Reusable with proper cleaning, minimal material consumption
Ethanol-water mixtures	Eco-friendly mobile phase components	Renewable, low toxicity, biodegradable
Ethyl acetate	Green organic solvent for mobile phase	Lower toxicity compared to chlorinated solvents
Ammonia solution	Modifier for improving separation	Volatile, minimal environmental persistence
Automated sample applicator (e.g., CAMAG Linomat)	Precise sample application	Reduces human error, minimizes reagent consumption
TLC twin-trough chamber	Controlled development environment	Enables chamber saturation with minimal solvent
Densitometer with deuterium lamp	Quantitative detection at specific wavelengths	Non-destructive detection, multiple analyses possible
WinCATS software	Data acquisition and processing	Enables full method validation and documentation

Method Optimization Strategies for Green HPTLC

Mobile Phase Selection and Optimization

The selection of mobile phase components significantly impacts both the analytical performance and greenness of HPTLC methods. The PRISMA system serves as a valuable guideline for finding the optimal mobile phase, considering solvent properties such as selectivity, strength, and toxicity [66]. For normal-phase HPTLC, greener alternatives to traditional hazardous solvents include:

• Replacing hexane with heptane or cyclohexane in normal-phase separations
• Using ethanol-isopropanol mixtures instead of methanol-acetonitrile in reversed-phase applications
• Incorporating water-ethanol mixtures as primary mobile phase components [16]
• Utilizing ethyl acetate-cyclohexane combinations for medium-polarity compounds

The use of water as a component in mobile phases enhances greenness while reducing costs. In one study, ethanol/water/ammonia solution (50:45:5 v/v/v) provided excellent separation for tenoxicam with an AGREE score of 0.75, demonstrating outstanding greenness without compromising analytical performance [16].

Sample Preparation Techniques

Minimal sample preparation is a key advantage of HPTLC and aligns with green analytical chemistry principles. Strategies for greening sample preparation include:

• Direct application of samples after simple dissolution in green solvents
• Using ultrasound-assisted extraction with green solvents for solid samples
• Implementing miniaturized extraction techniques to reduce solvent consumption
• Employing in-situ derivatization with low-toxicity reagents when necessary

For biological samples, protein precipitation with eco-friendly solvents like ethanol or acetone can replace traditional acetonitrile-based methods [18]. The combination of minimal sample preparation with the multi-sample capability of HPTLC significantly reduces the environmental impact per sample analyzed.

Case Studies: Implementations of Validated Green HPTLC Methods

Veterinary Drug Analysis in Bovine Tissue

A green HPTLC method was validated for simultaneous quantification of florfenicol and meloxicam in bovine muscle tissue [14]. The mobile phase consisted of glacial acetic acid, methanol, triethylamine, and ethyl acetate (0.05:1.00:0.10:9.00, by volume), with detection at 230 nm. The method demonstrated linearity ranges of 0.03-3.00 µg/band for meloxicam and 0.50-9.00 µg/band for florfenicol. Esomeprazole was employed as an internal standard to compensate for potential wavelength fluctuations. The method's greenness was evaluated using five assessment tools, confirming its eco-friendly nature while meeting regulatory requirements for monitoring veterinary drug residues in food products [14].

Stability-Indicating Method for Lornoxicam and Thiocolchicoside

A validated HPTLC method was developed for simultaneous estimation of lornoxicam and thiocolchicoside in pharmaceutical dosage forms [80]. The mobile phase consisted of methanol:chloroform:water (9.6:0.2:0.2 v/v/v), with detection at 377 nm. The method showed excellent linearity in the range of 60-360 ng/band for lornoxicam and 30-180 ng/band for thiocolchicoside, with correlation coefficients of 0.998 and 0.999, respectively. Accuracy studies demonstrated recoveries between 98.7-101.2% for both analytes. The method was successfully applied to pharmaceutical formulations, with the amount estimated as percentage of label claim found to be within acceptable limits [80].

The integration of ICH Q2(R2) validation requirements with green analytical chemistry principles represents the future of sustainable pharmaceutical analysis. HPTLC offers unique advantages in this context, including minimal sample preparation, low solvent consumption per sample, and the ability to analyze multiple samples simultaneously. The case studies presented demonstrate that green HPTLC methods can achieve performance metrics equivalent to or better than traditional methods while significantly reducing environmental impact.

Future developments in green HPTLC will likely focus on further solvent reduction through nano-scale applications, increased automation for higher throughput, and enhanced hyphenation with spectroscopic techniques for improved compound identification. As regulatory agencies increasingly emphasize sustainability, the implementation of green assessment metrics alongside traditional validation parameters will become standard practice in analytical laboratories.

By adopting the frameworks and protocols outlined in this guide, researchers and drug development professionals can contribute to both scientific advancement and environmental protection, fulfilling the dual mandates of quality and sustainability in pharmaceutical analysis.

High-Performance Thin-Layer Chromatography (HPTLC) has evolved from a simple qualitative tool into a sophisticated versatile analytical platform that aligns with the principles of Green Analytical Chemistry (GAC). This evolution responds to the growing demand for sustainable analytical practices within pharmaceutical analysis and quality control, particularly for compounds with narrow therapeutic indices like anticancer drugs [13] [12]. The fundamental distinction between traditional and green HPTLC approaches lies in their philosophical foundation: traditional methods prioritize performance metrics alone, while green HPTLC incorporates environmental impact as a core validation parameter alongside accuracy, precision, and sensitivity.

The inherent green advantages of HPTLC stem from its operational characteristics, including minimal solvent consumption (typically <10 mL per analysis), low energy requirements (often operating at ambient pressure and temperature), and parallel processing capability that enables simultaneous analysis of multiple samples [12]. These attributes position HPTLC as a promising alternative to traditional instrumental techniques like HPLC and GC-MS, which are increasingly constrained by labor-intensive sample preparation, longer analysis times (exceeding 30 minutes), and higher solvent waste generation [12]. The transition toward greener HPTLC methodologies represents a paradigm shift in pharmaceutical analysis, balancing analytical excellence with ecological responsibility.

Fundamental Principles and Comparison

Core Principles of Green HPTLC

Green HPTLC methodology is built upon three foundational pillars that differentiate it from traditional approaches:

• Solvent Selection: Replacement of hazardous solvents like chloroform, dichloromethane, and hexane with bio-based alternatives such as ethanol, ethyl acetate, and water [6] [22]. These solvents are categorized as green due to their safety, non-toxicity, and reduced environmental impact [22].

• Waste Minimization: Implementation of strategies that significantly reduce hazardous waste generation through miniaturized separation processes and efficient detection techniques that require minimal derivatization reagents [12] [67].

• Energy Efficiency: Utilization of ambient temperature and pressure operations throughout the analytical process, contrasting with energy-intensive techniques like HPLC that require high pressure pumping systems [12].

Comparative Analysis: Green vs. Traditional HPTLC

Table 1: Fundamental comparison between traditional and green HPTLC approaches

Parameter	Traditional HPTLC	Green HPTLC
Typical Solvents	Chloroform, dichloromethane, methanol [6] [18]	Ethanol-water mixtures, ethyl acetate [6] [22]
Solvent Consumption	Higher due to method development focus on performance only	Reduced through conscious design (<10 mL per analysis) [12]
Waste Generation	Significant hazardous waste requiring special disposal	Minimal waste with lower toxicity [12]
Energy Requirements	May require special conditions	Typically operates at ambient conditions [12]
Greenness Metrics	Rarely assessed	Quantitatively evaluated (AGREE, AES, GAPI) [6] [67]

The paradigm shift extends beyond solvent substitution to encompass a holistic analytical lifecycle approach. Green HPTLC incorporates comprehensive greenness assessment tools including AGREE (Analytical GREEnness), AES (Analytical Eco-Scale), and GAPI (Green Analytical Procedure Index) to quantitatively evaluate environmental impact [6] [67]. These tools assess all methodological aspects against the 12 principles of green analytical chemistry, providing a standardized framework for sustainability claims [22].

Experimental Protocols and Methodologies

Green HPTLC Method Development Protocol

The development of a green HPTLC method requires systematic optimization of parameters to balance analytical performance with environmental considerations:

• Stationary Phase Selection: Choose between normal-phase (silica gel) or reversed-phase (RP-18) plates based on analyte characteristics. Research indicates that reversed-phase systems often demonstrate superior greenness profiles when paired with ethanol-water mobile phases [6] [22].

• Mobile Phase Optimization: Test binary combinations of green solvents in varying proportions. For reversed-phase HPTLC, ethanol-water mixtures typically between 40:60 to 80:20 (v/v) provide excellent separation for diverse compounds [6]. For normal-phase HPTLC, ethyl acetate-ethanol combinations serve as effective green alternatives [22].

• Detection Optimization: Implement minimally destructive detection modes such as absorbance scanning at appropriate wavelengths before potentially employing derivatization reagents. When derivatization is necessary, use minimal reagent volumes through dipping rather than spraying [67].

A specific protocol for caffeine analysis using green RP-HPTLC demonstrates these principles: Samples are applied as 6 mm bands on RP-18 F254S plates using an automatic applicator. The mobile phase consists of ethanol-water (55:45 v/v) with chamber saturation for 30 minutes at 22°C. Development occurs over 80 mm, with detection at 275 nm [22]. This method achieved an AGREE score of 0.80, indicating excellent greenness [22].

Sample Preparation Techniques

Green sample preparation emphasizes minimal processing, reduced solvent consumption, and safer alternatives:

• Pharmaceutical Formulations: For tablet analysis, a representative powder sample is dissolved in green solvents like ethanol-water mixtures with brief sonication, followed by filtration or centrifugation [22]. This approach eliminates multiple extraction steps common in traditional methods.

• Biological Matrices: For plasma or tissue analysis, employ microscale extraction techniques requiring ≤1 mL of green solvents. For example, a method for remdesivir, linezolid, and rivaroxaban in spiked human plasma used liquid-liquid extraction with minimal solvent volumes [18].

• Complex Matrices: For energy drinks or herbal products, apply simplified cleanup procedures. One protocol for energy drinks involves degassing, lyophilization, and extraction with reduced solvent volumes compared to traditional approaches [22].

A representative sample preparation protocol for bovine tissue analysis of florfenicol and meloxicam illustrates green principles: Homogenized tissue samples are spiked with analytes, treated with 300 μL of 0.10 N EDTA, followed by extraction with minimal solvent volumes. The concentrated extract is applied to HPTLC plates for analysis [14].

Quantitative Greenness Assessment

Greenness Metric Tools and Scores

The greenness of HPTLC methods is quantitatively assessed using standardized metric tools that provide objective evaluation:

Table 2: Greenness assessment scores of representative HPTLC methods

Analytical Method	Analytes	AGREE Score	Other Metrics	Key Green Features
RP-HPTLC [6]	Ertugliflozin	0.83 (RP) vs. 0.82 (NP)	Improved AES & ChlorTox	Ethanol-water mobile phase
RP-HPTLC [22]	Caffeine	0.80	-	Ethanol-water mobile phase
HPTLC-densitometry [67]	Naltrexone & Bupropion	>0.75	Favorable GAPI & WAC	Smartphone detection alternative
NP-HPTLC [13]	Sorafenib	0.82	AGREEprep: 0.73	Green sample preparation
RP-HPTLC [13]	Sorafenib	0.83	AGREEprep: 0.77	Green sample preparation

The AGREE metric tool employs a 0-1 scoring system that evaluates methods against all 12 principles of green analytical chemistry, with scores approaching 1 indicating superior greenness [67]. The Analytical Eco-Scale (AES) provides a penalty-point system where methods scoring >75 are considered excellent green alternatives [6]. The Green Analytical Procedure Index (GAPI) offers a visual pictogram with color-coded assessment of environmental impact across the methodological steps [67].

Comparative Performance Data

Green HPTLC methods demonstrate comparable or superior analytical performance to traditional approaches:

• Linearity: Green RP-HPTLC for ertugliflozin showed excellent linearity (50-600 ng/band for NP-HPTLC and 25-1200 ng/band for RP-HPTLC) [6], while a green method for sorafenib exhibited linearity across 200-1000 ng/band for RP-HPTLC and 200-1200 ng/band for NP-HPTLC with R² values >0.999 [13].

• Sensitivity: Green methods achieve impressive detection limits, exemplified by a method for meloxicam and florfenicol quantifying down to 0.03 µg/band and 0.50 µg/band, respectively [14].

• Accuracy and Precision: Recovery studies for green HPTLC methods consistently demonstrate excellent accuracy (98.3-101.2%) for pharmaceutical formulations and spiked biological matrices [18], with precision meeting ICH guidelines [6] [22].

The Scientist's Toolkit

Essential Research Reagent Solutions

Table 3: Key reagents and materials for green HPTLC experiments

Reagent/Material	Function in Green HPTLC	Traditional Alternative
Ethanol-Water Mixtures	Green mobile phase for reversed-phase HPTLC [6] [22]	Acetonitrile-water or methanol-water
Ethyl Acetate-Ethanol	Green mobile phase for normal-phase HPTLC [22]	Chloroform-methanol or hexane-acetone
Silica Gel 60 RP-18 F254S Plates	Reversed-phase stationary phase for greener separations [6] [22]	Normal-phase silica plates
Silica Gel 60 F254 Plates	Normal-phase stationary phase when properly paired with green solvents [18]	Same but with hazardous solvents
Pre-coated HPTLC Plates	Consistent separation with minimal material usage [12]	Self-coated plates
Modified Dragendorff's Reagent	Derivatization agent for smartphone-based detection [67]	Traditional derivatization agents

Green HPTLC Workflow

The following workflow diagram illustrates the comprehensive process for implementing green HPTLC methodology:

The comparative analysis demonstrates that green HPTLC methodologies provide viable, sustainable alternatives to traditional sample preparation and analysis approaches without compromising analytical performance. The integration of green chemistry principles with advanced HPTLC techniques creates a robust framework for environmentally conscious pharmaceutical analysis. The quantitative greenness assessment tools, particularly the AGREE metric, provide standardized validation of environmental claims, enabling researchers to make informed decisions about method selection and development.

Future directions in green HPTLC point toward increased integration with multimodal detection systems including mass spectrometry, surface-enhanced Raman spectroscopy, and smartphone-based detection platforms [12] [67]. These advancements, coupled with ongoing solvent optimization and miniaturization strategies, will further enhance the sustainability profile of HPTLC methodologies. For researchers and drug development professionals, adopting green HPTLC approaches represents both an ecological imperative and an analytical opportunity to develop efficient, cost-effective, and environmentally responsible quality control methods.

The development of antidiabetic therapeutics is a critical area of pharmaceutical research, with diabetes mellitus representing a major global health challenge affecting hundreds of millions worldwide [81]. Within pharmaceutical analysis, Green Analytical Chemistry has emerged as a guiding principle, promoting sustainable development through environmentally benign procedures [79]. This case study addresses a significant environmental concern in chromatographic analysis: the replacement of hazardous solvents like benzene with safer alternatives in High-Performance Thin-Layer Chromatography (HPTLC) methods for antidiabetic drug analysis.

Benzene, a classical chromatographic solvent, is a known human carcinogen with severe toxicity concerns. The ten principles of Green Sample Preparation (GSP) emphasize the use of safe solvents/reagents, minimizing waste generation, and enabling high sample throughput with miniaturization and automation [79]. This framework guides the development of sustainable methodologies that reduce environmental impact while maintaining analytical performance. This case study demonstrates how green solvent systems can successfully replace benzene in the HPTLC analysis of antidiabetic drugs, aligning with the broader thesis on fundamentals of greener sample preparation for HPTLC research.

Green Solvent Alternatives: Replacement Strategies and Systems

Strategic Replacement of Benzene in HPTLC

The substitution of benzene in HPTLC methods requires careful consideration of solvent properties, including polarity, viscosity, and elution strength. Successful green solvent systems employ mixtures that maintain separation efficiency while reducing toxicity. These systems often incorporate ethyl acetate, methanol, and aqueous modifiers as core components, creating a chromatographic environment that effectively replaces benzene-containing mobile phases.

Experimentally Demonstrated Green Mobile Phases

Recent research has validated several benzene-free mobile phase systems for antidiabetic drug analysis. The table below summarizes successfully implemented green solvent systems for HPTLC analysis of various antidiabetic compounds.

Table 1: Green Mobile Phase Systems for HPTLC Analysis of Antidiabetic Drugs

Drug Compounds Analyzed	Green Mobile Phase Composition	Stationary Phase	Separation Efficiency (Rf Values)	Citation
Saxagliptin, Metformin, Melamine (impurity)	Ethyl acetate:MeOH:NH₃:Glacial acetic acid (6:4:1:0.3, v/v/v/v)	HPTLC silica gel 60 F₂₅₄	Well-resolved peaks for all three analytes	[82]
Linagliptin and Dapagliflozin	n-hexane:Toluene:Ethyl acetate:MeOH:0.1% formic acid (40:10:5:40:5, v/v)	HPTLC silica gel 60 F₂₅₄	Rf = 0.41 (Linagliptin), Rf = 0.66 (Dapagliflozin)	[83]
Remdesivir, Linezolid, Rivaroxaban*	Dichloromethane:Acetone (8.5:1.5, v/v)	TLC silica gel 60 F₂₅₄	Rf = 0.23, 0.53, 0.72 respectively	[18]

Note: While not an antidiabetic drug, Remdesivir analysis demonstrates green solvent applications in pharmaceutical analysis. Dichloromethane should be used with proper safety controls despite its inclusion in this green method.

The strategic formulation of these mobile phases demonstrates that careful solvent selection can achieve excellent separation without benzene. The system for Saxagliptin and Metformin combines ethyl acetate as the primary organic component with methanol and small amounts of ammonia and acetic acid for pH modification, successfully resolving the drugs from the potential impurity melamine [82]. The linagliptin and dapagliflozin method employs a more complex mixture predicted by Hansen Solubility Parameters (HSP) to optimize separation, showcasing a rational design approach to green method development [83].

Experimental Protocols: Green HPTLC Method Development and Validation

HPTLC Instrumentation and Materials

Research Reagent Solutions and Essential Materials:

• Stationary Phase: HPTLC silica gel 60 F₂₅₄ aluminum sheets (250 μm thickness); functions as the solid phase for chromatographic separation [83] [82].
• Sample Applicator: Linomat V autosampler with 100 μL syringe; enables precise, automated application of sample bands [82].
• Development Chamber: Twin-trough glass chamber (20 × 10 cm); provides controlled environment for mobile phase development [83].
• Densitometer: HPTLC scanner 3 with deuterium lamp; detects separated compounds at specific wavelengths by measuring absorbance [18] [82].
• Data Acquisition: WINCATS software (version 1.4.3 or higher); processes chromatographic data and calculates peak areas [83].
• Green Solvents: Ethyl acetate, methanol, n-hexane, acetone; function as environmentally preferable replacements for hazardous solvents in mobile phase preparation [18] [83] [82].
• pH Modifiers: Ammonia (33%), glacial acetic acid; adjust pH of mobile phase to optimize separation and peak shape [82].

Detailed Analytical Procedure

Step 1: Mobile Phase Preparation Prepare the green solvent mixture ethyl acetate:methanol:ammonia:glacial acetic acid in the ratio 6:4:1:0.3 (v/v/v/v). Transfer the mixture to a twin-trough HPTLC chamber and saturate for 30 minutes at room temperature to establish equilibrium vapor conditions [82].

Step 2: Standard Solution Preparation Accurately weigh 10 mg each of saxagliptin and metformin reference standards into separate 10 mL volumetric flasks. Dissolve and dilute to volume with methanol to obtain stock solutions of 1000 μg/mL. Prepare working solutions by diluting stock solutions with methanol to concentrations of 100 μg/mL [82].

Step 3: Sample Application Mark the HPTLC silica gel 60 F₂₅₄ plate 10 mm from the bottom and 5 mm between bands. Using the Linomat V applicator, apply 10 μL aliquots of standard and sample solutions as 6-mm bands under a continuous stream of nitrogen gas [82].

Step 4: Chromatographic Development Develop the applied plate in the pre-saturated chamber using the ascending technique. Allow the mobile phase to migrate 80 mm from the point of application. Remove the plate from the chamber and air-dry for 5 minutes to completely evaporate the solvents [82].

Step 5: Densitometric Analysis Scan the developed plate at 215 nm using the TLC scanner III with a deuterium lamp. Set the scanning speed to 20 mm/s with a slit dimension of 3 × 0.45 mm. Record the chromatograms and measure peak areas using WINCATS software [82].

Step 6: Method Validation Validate the method according to International Conference on Harmonisation (ICH) guidelines Q2(R1) for linearity, range, accuracy, precision, specificity, and robustness. Generate calibration curves by plotting peak area against concentration for each analyte [83] [82].

Method Optimization Using QbD and HSPiP

Advanced green method development employs Quality by Design (QbD) principles and Hansen Solubility Parameters (HSPiP) for systematic optimization. The Box-Behnken design identifies critical parameters (band length, saturation time, wavelength) and their optimal ranges [83]. HSPiP software predicts suitable green solvents based on the cohesive energy (dispersion δd, polarity δp, and hydrogen bonding δh) between analytes and solvents, calculating Relative Energy Difference (RED) values to classify solvents as "good" (RED < 1.0) or "bad" (RED > 1.0) for the application [83].

Green HPTLC Method Development Workflow

Assessment of Greenness and Analytical Performance

Green Metrics Evaluation

The environmental sustainability of the developed green HPTLC methods was rigorously assessed using multiple green metrics. The Analytical Eco-Scale evaluates method greenness based on penalty points, with scores above 75 indicating excellent greenness [82] [84]. The Analytical GREEnness (AGREE) calculator provides a comprehensive assessment using twelve principles of GAC, generating a pictogram with a 0-1 score [83] [82]. The Green Analytical Procedure Index (GAPI) offers a visual representation of environmental impact across the entire analytical procedure [82] [84].

Table 2: Greenness Assessment Scores for Reported Chromatographic Methods

Method Description	Analytical Eco-Scale Score	AGREE Score	NEMI Assessment	GAPI Assessment	Citation
HPTLC for Saxagliptin, Metformin, Melamine	Excellent rating	High score reported	Favorable assessment	Favorable assessment	[82]
HPTLC for Linagliptin, Dapagliflozin	Not specified	High score (AGREEprep)	Not specified	Not specified	[83]
HPLC for multiple antidiabetics	Excellent rating	High score reported	Not performed	Favorable assessment	[84]

Analytical Performance Data

The green HPTLC methods demonstrated excellent analytical performance comparable to conventional methods. The method for saxagliptin, metformin, and melamine showed linearity ranges of 2-100 μg/band for saxagliptin and metformin, and 0.2-10 μg/band for melamine, with correlation coefficients (r²) > 0.999 [82]. The method for linagliptin and dapagliflozin exhibited correlation coefficients of 0.9989 and 0.9505, respectively, meeting ICH validation criteria for accuracy, precision, robustness, LOD, and LOQ [83].

Green Method Advantages vs. Conventional Approaches

This case study demonstrates that benzene replacement in HPTLC analysis of antidiabetic drugs is both feasible and advantageous. The green solvent system ethyl acetate:methanol:ammonia:glacial acetic acid (6:4:1:0.3, v/v/v/v) successfully enabled the separation of saxagliptin and metformin from the potential impurity melamine without compromising analytical performance [82]. The systematic approach combining HSPiP solvent prediction with QbD optimization provides a powerful framework for developing green HPTLC methods that align with the principles of green sample preparation [83].

The validated methods offer environmental benefits through reduced toxicity, economic advantages via cost-effective solvents, and analytical robustness meeting ICH validation requirements. As pharmaceutical analysis continues to evolve, the integration of green chemistry principles with advanced methodological approaches will be essential for sustainable drug development in the field of antidiabetic therapeutics.

The concept of White Analytical Chemistry (WAC) represents an evolution in analytical method assessment, expanding beyond mere environmental considerations to create a balanced framework that equally weights greenness, practicality, and quality. In the specific context of High-Performance Thin-Layer Chromatography (HPTLC) research, WAC provides a structured approach to developing sustainable methods without compromising analytical performance or practical utility. This holistic framework addresses the limitations of earlier green assessment tools that focused predominantly on environmental aspects, often neglecting the equally important analytical and practical requirements for method implementation in pharmaceutical and research settings.

The fundamental principle of WAC utilizes a three-dimensional RGB model to quantify method suitability. The red component (R) represents analytical performance, including validation parameters, sensitivity, and scope of application. The green component (G) signifies environmental safety and greenness, while the blue component (B) reflects practicality and economic efficiency. The ideal "white" method achieves balanced saturation across all three dimensions, resulting in a comprehensive sustainability profile that meets the needs of modern analytical laboratories [67]. This paradigm is particularly relevant for HPTLC, which offers inherent advantages in green chemistry through minimal solvent consumption, reduced energy requirements, and high-throughput capabilities [12].

Theoretical Framework: The WAC RGB Model

The WAC assessment employs a systematic approach where each of the three dimensions is evaluated against specific criteria, resulting in quantitative scores that are visually represented in a color-coded diagram. The convergence of high scores across all three domains produces the desired "white" method characteristic of an ideal analytical procedure.

Red Dimension - Analytical Performance:

• Method validation parameters: Linearity, accuracy, precision, specificity
• Detection and quantification limits: Sensitivity in various matrices
• Scope and application: Range of analytes, compatibility with complex samples
• Robustness and reliability: Consistency under varying conditions [67]

Green Dimension - Environmental Safety:

• Solvent and reagent toxicity: Use of hazardous chemicals
• Energy consumption: Instrumentation requirements and analysis time
• Waste generation: Volume and hazard classification of byproducts
• Sample preparation: Clean-up requirements and derivatization needs [58]

Blue Dimension - Practicality and Economic Factors:

• Instrument cost and availability: Accessibility for routine laboratories
• Analysis time and throughput: Sample processing capacity
• Operator skill requirements: Technical expertise needed
• Cost-per-analysis: Reagent, consumable, and operational expenses [67] [2]

The following diagram illustrates the interrelationship between these three dimensions in the WAC framework:

Greenness Assessment Tools for HPTLC Methods

Comprehensive Metric Comparison

Multiple standardized tools have been developed to quantitatively assess the greenness of analytical methods, each with distinct approaches and scoring systems. The table below summarizes the key greenness assessment metrics applicable to HPTLC method development:

Table 1: Greenness Assessment Tools for HPTLC Method Evaluation

Assessment Tool	Evaluation Methodology	Scoring System	Key Assessment Criteria	HPTLC Application Example
AGREE	Evaluates compliance with 12 principles of GAC	0-1 scale (closer to 1 = greener)	Sample preparation, solvents, energy consumption, waste	HPTLC method for Carvedilol scored 0.82 [9]
GAPI	Pictogram with 5 pentagrams colored red/yellow/green	Qualitative (high/medium/low hazard)	Sample collection, storage, reagents, instrumentation	Used to assess HPTLC methods for Naltrexone/Bupropion [67]
Analytical Eco-Scale	Penalty points assigned for hazardous parameters	>75 excellent, >50 acceptable	Solvent toxicity, reagent amount, energy consumption	Applied to HPTLC method for Remdesivir combination [18]
NEMI	Pictogram with four quadrants	Pass/fail for each criterion	Persistent, bioaccumulative, toxic; hazardous; corrosive	Utilized in HPTLC analysis of Carvedilol [9]
BAGI	Assesses practical and economic aspects	0-100 scale (higher = better practicality)	Method throughput, cost, operational simplicity	HPTLC method for duloxetine/tadalafil scored high [85]

AGREE Score Calculation Methodology

The Analytical GREEnness (AGREE) metric has emerged as one of the most comprehensive assessment tools, incorporating all twelve principles of Green Analytical Chemistry into its evaluation framework. The calculation involves:

• Assigning scores (0-1) for each of the 12 GAC principles based on method compliance
• Weighting factors may be applied to prioritize critical principles
• Generating a circular pictogram with twelve sections, each colored according to its score
• Calculating an overall score displayed in the center (0-1, where 1 represents ideal greenness)

For HPTLC methods, high AGREE scores are typically achieved through:

• Minimal solvent consumption (5-10 mL per analysis compared to 500-1000 mL in HPLC)
• Reduced energy requirements (operates at ambient temperature/pressure)
• Parallel sample processing (multiple samples on a single plate)
• Elimination of derivatization in many applications [12]

Practical Implementation in HPTLC Research

Strategic Approach to Green HPTLC Method Development

Developing HPTLC methods that fulfill WAC requirements necessitates a systematic approach that integrates green principles from the initial design phase while maintaining robust analytical performance. The following workflow outlines the key stages in creating sustainable HPTLC methods:

Essential Research Reagent Solutions for Green HPTLC

The selection of appropriate reagents and materials is crucial for developing HPTLC methods that align with WAC principles. The following table details key research reagents and their functions in sustainable HPTLC analysis:

Table 2: Essential Research Reagent Solutions for Green HPTLC

Reagent/Material	Function in HPTLC	Green Alternatives	Application Example
Silica gel 60 F₂₅₄ plates	Stationary phase for separation	-	Universal application for pharmaceutical analysis [18] [58]
Ethyl acetate	Mobile phase component	Replace dichloromethane, chloroform	Used in 7:3 ratio with ethanol for bisoprolol/amlodipine [2]
Ethanol	Green solvent for mobile phase	Replace methanol, acetonitrile	Mobile phase for cardiovascular drugs [2]
Ethyl acetate-ethanol-ammonia	Multi-component mobile phase	-	Separation of duloxetine/tadalafil (8:1:1) [85]
Methanol-ethyl acetate-ammonia	Versatile mobile phase	-	Separation of tamsulosin/mirabegron (3:7:0.1) [58]
Water	Green solvent for extraction	-	Sample preparation where solubility permits [11]
Natural Deep Eutectic Solvents (NADES)	Extraction & sample preparation	Replace conventional organic solvents	Emerging green alternative for natural products [11]

Experimental Protocol: Green HPTLC Method for Pharmaceutical Analysis

Method Title: Environmentally Friendly HPTLC-Densitometric Method for Simultaneous Determination of Pharmaceutical Compounds

Objective: To develop and validate a green HPTLC method for simultaneous quantification of active pharmaceutical ingredients in compliance with White Analytical Chemistry principles.

Materials and Equipment:

• HPTLC silica gel 60 F₂₅₄ plates (20 × 10 cm or 20 × 20 cm)
• CAMAG Linomat 5 automatic sample applicator
• CAMAG microsyringe (100 μL)
• Twin-trough glass chamber for mobile phase development
• CAMAG TLC Scanner 3 with winCATS software
• Ultrasonic bath for sample preparation
• Analytical balance

Chromatographic Conditions:

• Stationary phase: Silica gel 60 F₂₅₄
• Mobile phase: Optimized green solvent system (e.g., ethyl acetate:ethanol:ammonia, 8:1:1 v/v)
• Development distance: 70-80 mm
• Chamber saturation: 15-25 minutes at room temperature
• Detection: Densitometric scanning at optimal wavelengths
• Sample application volume: 1-10 μL as bands

Experimental Procedure:

• Standard Solution Preparation:

  • Accurately weigh 10 mg of each reference standard
  • Transfer to separate 10 mL volumetric flasks
  • Dissolve in and dilute to volume with methanol to obtain 1 mg/mL stock solutions
  • Prepare working standards by appropriate dilution

• Sample Preparation:

  • For pharmaceutical formulations: weigh and powder tablets/capsules
  • Accurately weigh powder equivalent to target analyte
  • Extract with green solvent using ultrasonication for 15-30 minutes
  • Filter through 0.45 μm membrane filter

• Chromatographic Separation:

  • Pre-wash HPTLC plates with methanol if necessary
  • Activate plates at 60°C for 5 minutes if required
  • Apply samples and standards as 6-8 mm bands using automatic applicator
  • Develop plate in saturated twin-trough chamber with optimized mobile phase
  • Dry developed plate in fume hood or with hair dryer

• Detection and Quantification:

  • Scan plate at optimal wavelength using TLC scanner
  • Record chromatograms and measure peak areas
  • Construct calibration curves (peak area vs concentration)
  • Calculate analyte concentrations in unknown samples [18] [58] [85]

Method Validation Parameters:

• Linearity: 5-6 concentration levels, R² > 0.999
• Precision: Intra-day and inter-day RSD < 2%
• Accuracy: Recovery studies 98-102%
• Specificity: No interference from excipients or degradation products
• Robustness: Deliberate variations in mobile phase composition, development distance

Case Studies: WAC-Compliant HPTLC Methods

Pharmaceutical Formulation Analysis

Case Study 1: Simultaneous Determination of Naltrexone and Bupropion

A comparative study demonstrated the successful application of WAC principles for the analysis of this combination therapy. The researchers developed three detection methods: conventional densitometry, ImageJ software analysis, and Color-Picker smartphone application. The methods were evaluated using the RGB model, with the ImageJ-based method achieving excellent balance across all three dimensions:

• Red (Analytical Performance): Linear range of 0.4-24 μg/band for naltrexone and 0.6-18 μg/band for bupropion, with precision RSD < 2%
• Green (Environmental Safety): Minimal solvent consumption, reduced waste generation, low energy requirements
• Blue (Practicality): Cost-effective, minimal equipment requirements, high throughput capability [67]

Case Study 2: Analysis of Carvedilol in Pharmaceutical Dosage Forms

An eco-friendly stability-indicating HPTLC method was developed and validated for carvedilol estimation. The method employed a mobile phase of toluene:isopropanol:ammonia (7.5:2.5:0.1, v/v/v), specifically designed to avoid carcinogenic solvents. The method demonstrated excellent greenness scores across multiple assessment tools:

• NEMI: Three out of four quadrants green
• AGREE: High score of 0.82
• Eco-Scale: Rating of 85 (excellent)

The method successfully separated carvedilol from its degradation products under various stress conditions, demonstrating the successful integration of greenness with analytical performance and practicality [9].

Bioanalytical and Food Safety Applications

Case Study 3: Determination of Remdesivir with Co-administered Drugs in Spiked Human Plasma

This study addressed the urgent need for therapeutic drug monitoring during the COVID-19 pandemic by developing a green HPTLC method for simultaneous quantification of remdesivir, linezolid, and rivaroxaban in spiked human plasma. The method achieved outstanding greenness metrics while maintaining critical analytical performance:

• Separation efficiency: Baseline separation with Rf values of 0.23, 0.53, and 0.72 for the three analytes
• Sensitivity: Quantitation limits of 128.8, 50.5, and 55.8 ng/band respectively
• Greenness: Favorable scores on Analytical Eco-Scale, GAPI, and AGREE metrics

This case study exemplifies how HPTLC methods can balance the demanding requirements of bioanalytical method development with environmental considerations [18].

Case Study 4: Veterinary Drug Residue Analysis in Bovine Tissue

A green HPTLC method was developed for simultaneous quantification of florfenicol and meloxicam in spiked bovine muscle tissue to monitor veterinary drug residues. The method addressed important food safety concerns while incorporating green chemistry principles:

• Sample preparation: Simplified extraction procedure with minimal solvent consumption
• Greenness assessment: Evaluated using five different greenness assessment tools
• Regulatory compliance: Capable of detecting residues below established maximum residue limits (MRLs)

This application demonstrates the utility of WAC-compliant HPTLC methods in complex matrices like food products [14].

Advanced Techniques and Future Directions

Multimodal HPTLC Platforms

The integration of HPTLC with complementary detection techniques represents a significant advancement in achieving White Analytical Chemistry objectives. These "HPTLC+" platforms enhance analytical performance while maintaining environmental benefits:

• HPTLC-MS: Combines separation capability with structural identification power of mass spectrometry
• HPTLC-SERS: Integrates Surface-Enhanced Raman Spectroscopy for molecular fingerprinting
• HPTLC-NIR: Couples with Near-Infrared Spectroscopy for non-destructive analysis
• HPTLC-bioautography: Enables function-directed screening of biological activity [12]

These multimodal approaches address the historical limitations of conventional HPTLC while capitalizing on its inherent green advantages, particularly for food and herbal product analysis where comprehensive quality assessment is required.

Computational Method Development

The application of computational and algorithmic approaches represents a promising direction for enhancing the white character of HPTLC methods:

• Firefly Algorithm-Optimized PLS (FA-PLS): Advanced chemometric approach for spectral analysis and method optimization
• Hammersley Sequence Sampling (HSS): Innovative strategy for validation set construction ensuring comprehensive concentration space coverage
• Convolutional Neural Networks (CNNs): Automated spot recognition and data processing to enhance reproducibility [2]

These computational techniques contribute to all three WAC dimensions by improving analytical performance (red), reducing experimental trials and solvent consumption (green), and streamlining method development workflows (blue).

The implementation of White Analytical Chemistry principles in HPTLC research represents a paradigm shift from merely "green" methods to comprehensively sustainable analytical procedures. By systematically balancing the three dimensions of analytical performance, environmental safety, and practical utility, researchers can develop HPTLC methods that meet the complex demands of modern pharmaceutical analysis and quality control.

The case studies and methodologies presented demonstrate that WAC-compliant HPTLC is not only theoretically desirable but practically achievable across diverse applications, from pharmaceutical formulations to complex biological matrices. As analytical chemistry continues to evolve toward greater sustainability, the WAC framework provides a comprehensive roadmap for developing methods that excel across all critical dimensions of method evaluation.

Future advancements will likely focus on further integration of computational approaches, development of novel green stationary and mobile phases, and expansion of multimodal HPTLC platforms that enhance capability while maintaining environmental responsibility. Through continued innovation in these areas, HPTLC will remain at the forefront of sustainable analytical technique development, fully embodying the principles of White Analytical Chemistry.

Conclusion

The integration of green principles into HPTLC sample preparation is no longer optional but a necessity for sustainable and responsible laboratory practice. By adopting strategies such as solvent substitution, miniaturization, and automation, researchers can significantly reduce the environmental footprint of their analytical workflows without compromising data quality. The future of HPTLC lies in the continued development of eco-friendly methodologies, supported by robust green metrics and alignment with white analytical chemistry principles. This evolution will not only ensure regulatory compliance but also drive innovation in pharmaceutical quality control and biomedical research, contributing directly to broader corporate and global sustainability goals.

References

• 1. High-Performance Thin-Layer Chromatography (HPTLC) [https://ctlatesting.com/blogs/articles/high-performance-thin-layer-chromatography-hptlc]
• 2. Dual-platform integration of HPTLC and firefly algorithm ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC12345108/]
• 3. Comparative study of Normal-phase versus ... - BMC Chemistry [https://bmcchem.biomedcentral.com/articles/10.1186/s13065-025-01439-9]
• 4. concepts and guidelines for GAC applied in sample ... [https://www.sciencedirect.com/science/article/pii/B9780443161223000068]
• 5. Complete Guide to Thin Layer Chromatography Sample ... [https://www.organomation.com/complete-guide-to-thin-layer-chromatography-sample-preparation]
• 6. Comparing the Greenness and Validation Metrics of ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC11137692/]
• 7. Green and white analytical chemistry: Advances ... [https://www.sciencedirect.com/science/article/abs/pii/S0022354925004599]
• 8. Eco-friendly HPTLC method for Trifluridine and Tipiracil ... [https://www.sciencedirect.com/science/article/pii/S2772577425000308]
• 9. Eco-friendly and stability-indicating HPTLC method for the ... [https://www.sciencedirect.com/science/article/pii/S2772577425000333]
• 10. HPLC 2025 Preview: The Road To Sustainable Analytical ... [https://www.chromatographyonline.com/view/hplc-2025-preview-the-road-to-sustainable-analytical-chemistry]
• 11. Recent Advances In Green Chromatography Techniques ... [https://www.sciencedirect.com/science/article/pii/S2772391725000830]
• 12. Versatile platforms based on HPTLC: Multimodal and ... [https://www.sciencedirect.com/science/article/abs/pii/S0924224425004467]
• 13. Ecofriendly Densitometric (RP and NP) HPTLC Methods for ... [https://pubs.rsc.org/en/content/articlelanding/2025/ay/d5ay01031d]
• 14. FDA validated ecofriendly HPTLC method for quantification ... [https://www.nature.com/articles/s41598-025-18548-z]
• 15. HPTLC method as a cost-saving option for quantitative ... [https://www.hptlc-association.org/blog/hptlc-method-as-a-cost-saving-option-for-quantitative-evaluation-of-herbal-drugs]
• 16. Eco-Friendly High-Performance Thin-Layer ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC10601416/]
• 17. Ecofriendly densitometric (RP and NP) HPTLC methods for ... [https://pubmed.ncbi.nlm.nih.gov/40937623/]
• 18. An eco-friendly and cost-effective HPTLC method for ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC11063142/]
• 19. High-Performance Thin-Layer Chromatography (HPTLC) [https://link.springer.com/book/10.1007/978-3-642-14025-9]
• 20. New HPTLC Chapter Proposed for The International ... [https://www.gmp-compliance.org/gmp-news/new-hptlc-chapter-proposed-for-the-international-pharmacopoeia]
• 21. The Science Behind an HPTLC Test [https://www.eurofinsus.com/food-testing/resources/the-science-behind-an-hptlc-test/]
• 22. A Green High-Performance Thin-Layer Chromatography ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC9103461/]
• 23. Two sustainable chromatographic approaches for ... [https://www.nature.com/articles/s41598-025-22295-6]
• 24. Green chromatographic methods for determination of co ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC10633899/]
• 25. Safer Solvents for Active Pharmaceutical Ingredient ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC11413887/]
• 26. Replacement of organic solvents with environmental eco-friendly... [https://ijpsr.com/bft-article/replacement-of-organic-solvents-with-environmental-eco-friendly-solvents-for-rp-hplc-analysis/?view=fulltext]
• 27. Dual-platform integration of HPTLC and firefly algorithm-optimized... [https://bmcchem.biomedcentral.com/articles/10.1186/s13065-025-01598-9]
• 28. A Simple, Cost-Effective, and Green HPTLC Method for the ... [https://www.mdpi.com/2073-4395/12/5/1016]
• 29. High performance thin layer chromatography with eluents ... [https://www.nature.com/articles/s41598-025-99617-1]
• 30. Advances in miniaturized liquid sample preparation ... [https://www.sciencedirect.com/science/article/pii/S2772391725000386]
• 31. A Comprehensive Review On The Miniaturized Analytical ... [https://journals.stmjournals.com/rrjops/article=2025/view=232774/]
• 32. Comparative HPTLC study for simultaneous determination of ... [https://bmcchem.biomedcentral.com/articles/10.1186/s13065-023-01025-x]
• 33. High Performance Thin Layer Chromatography (HPTLC) [https://www.slideshare.net/slideshow/13-fet1006-hptlc/125708365]
• 34. Comparison of HPLC, HPTLC, and In Silico Lipophilicity ... [https://www.mdpi.com/1420-3049/29/11/2478]
• 35. Green metrics and green analytical applications [https://www.sciencedirect.com/science/article/pii/S2772577424000685]
• 36. Discover the Key Benefits of HPTLC Analysis [https://camag.com/industries-and-application/benefits-of-hptlc/]
• 37. HPTLC Instruments for Qualitative and Quantitative Analyses [https://camag.com/products/hptlc/]
• 38. How HPTLC Works: A Guide for Researchers at the Bench [https://bitesizebio.com/47784/hptlc-basics-and-instrumentation/]
• 39. Recent application of green analytical chemistry: eco-friendly approaches for pharmaceutical analysis | Future Journal of Pharmaceutical Sciences | Full Text [https://fjps.springeropen.com/articles/10.1186/s43094-024-00658-6]
• 40. Study: Recent Advances in Preparation for Biological ... [https://www.chromatographyonline.com/view/study-recent-advances-in-preparation-for-biological-samples]
• 41. The Modern Analytical Determination of Botanicals and ... [https://www.sciencedirect.com/science/article/abs/pii/B9780444595140000080]
• 42. Key Components for Ensuring Accurate HPTLC Analysis [https://www.eurofinsus.com/food-testing/resources/key-components-for-ensuring-accurate-hptlc-analysis/]
• 43. Development and Validation of a Stability-Indicating Greener HPTLC Method for the Estimation of Flufenamic Acid [https://www.mdpi.com/2297-8739/10/1/39]
• 44. Determination of Cordycepin Using a Stability-Indicating Greener HPTLC Method [https://www.mdpi.com/2297-8739/10/1/38]
• 45. Targeted HPTLC Profile, Quantification of Flavonoids and ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC10052987/]
• 46. The Do's and Don'ts of HPTLC [https://bitesizebio.com/47838/the-dos-and-donts-of-hptlc/]
• 47. High-performance thin layer chromatography: A powerful ... [https://jpbs.in/archive/volume/9/issue/1/article/2047]
• 48. Independent concentration extraction as a novel green ... [https://bmcchem.biomedcentral.com/articles/10.1186/s13065-024-01260-w]
• 49. Novel green HPTLC and organic solvent-free micellar LC ... [https://www.sciencedirect.com/science/article/abs/pii/S235255412300311X]
• 50. Matrix Effects on Quantitation in Liquid Chromatography [https://www.chromatographyonline.com/view/matrix-effects-on-quantitation-in-liquid-chromatography-sources-and-solutions]
• 51. The Basics of Botanical Matrices and HPTLC Testing [https://www.eurofinsus.com/food-testing/resources/applying-hptlc-in-complex-food-and-supplement-matrices/]
• 52. Innovations and Strategies of Sample Preparation ... [https://www.chromatographyonline.com/view/innovations-and-strategies-of-sample-preparation-techniques-to-reduce-matrix-effects-during-lc-ms-ms-bioanalysis]
• 53. Matrix interference evaluation employing GC and LC ... [https://www.sciencedirect.com/science/article/abs/pii/S0039914017305945]
• 54. Learn from the Experts: Essential HPTLC Techniques and ... [https://www.hptlc-association.org/blog/learn-from-the-experts-essential-hptlc-techniques-and-strategies-for-complex-sample-matrices]
• 55. High-performance thin-layer chromatography combined ... [https://www.sciencedirect.com/science/article/pii/S0003267021004700]
• 56. Green Approaches to Sample Preparation Based on ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC7180442/]
• 57. CAMAG – Advanced Analysis of Complex Samples with HPTLC [https://camag.com/]
• 58. Development of Green HPTLC method for simultaneous ... [https://bmcchem.biomedcentral.com/articles/10.1186/s13065-023-01043-9]
• 59. A validated HPTLC method for quantitative analysis of morin ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC9476798/]
• 60. Tips & Tricks for Thin-Layer Chromatography [https://www.sigmaaldrich.com/US/en/technical-documents/technical-article/analytical-chemistry/thin-layer-chromatography/tips-n-tricks-for-thin-layer-chromatography?srsltid=AfmBOopZPx27IySndZ8QqefDpTg_7PDrup52ToBpSgNZlrTecShuztEG]
• 61. Best practices for analytical method transfers [https://medfilesgroup.com/best-practices-for-analytical-method-transfers/]
• 62. Points to Consider in Quality Control Method Validation ... [https://www.bioprocessintl.com/qa-qc/points-to-consider-in-quality-control-method-validation-and-transfer]
• 63. Reproducibility of high-performance thin-layer ... [https://www.sciencedirect.com/science/article/abs/pii/S2468170917301352]
• 64. Method Validation in High-Performance Thin Layer ... [https://www.eurofinsus.com/food-testing/resources/method-validation-in-hptlc-methods-for-food-and-supplements/]
• 65. A validated HPTLC method for quantitative analysis of ... [https://www.sciencedirect.com/science/article/pii/S1674638420300253]
• 66. High-performance thin-layer chromatography [https://en.wikipedia.org/wiki/High-performance_thin-layer_chromatography]
• 67. An eco-friendly smartphone based HPTLC method versus ... [https://bmcchem.biomedcentral.com/articles/10.1186/s13065-024-01285-1]
• 68. Combining chemometric analysis of HPTLC data and... [https://pubmed.ncbi.nlm.nih.gov/40752186/]
• 69. AGREEprep – Analytical greenness metric for sample ... [https://www.sciencedirect.com/science/article/abs/pii/S016599362200036X]
• 70. Blue applicability grade index (BAGI) and software: a new tool ... [https://pubs.rsc.org/en/content/articlehtml/2023/gc/d3gc02347h]
• 71. AGREE—Analytical GREEnness Metric Approach and ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC7588019/]
• 72. A total scoring system and software for complex modified ... [https://www.sciencedirect.com/science/article/pii/S2772577424000351]
• 73. Application of new green evaluation tools to assess the ... [https://www.sciencedirect.com/science/article/pii/S2772577424000533]
• 74. A Sustainable Approach to Green Sample Preparation and ... [https://www.chromatographyonline.com/view/a-sustainable-approach-to-green-sample-preparation-and-analytical-performance-using-hs-spme-gc-qtof-ms]
• 75. AGREE, Complex MoGAPI, and RGB 12-model assessments [https://pmc.ncbi.nlm.nih.gov/articles/PMC11568669/]
• 76. BAGI-assessed green GC-MS method for rapid analysis of ... [https://www.nature.com/articles/s41598-025-25388-4]
• 77. High-performance thin layer chromatography: A powerful ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC3658041/]
• 78. ICH Q2(R2) Validation of analytical procedures [https://www.ema.europa.eu/en/ich-q2r2-validation-analytical-procedures-scientific-guideline]
• 79. The ten principles of green sample preparation [https://www.sciencedirect.com/science/article/pii/S0165993622000139]
• 80. Development and validation of a HPTLC method for ... [https://pmc.ncbi.nlm.nih.gov/articles/PMC3658059/]
• 81. Heterocyclic compounds as a magic bullet for diabetes mellitus [https://pmc.ncbi.nlm.nih.gov/articles/PMC9379558/]
• 82. Sequential separation of anti-diabetic drugs in the presence of ... [https://bmcchem.biomedcentral.com/articles/10.1186/s13065-025-01385-6]
• 83. HSPiP and quality by design-assisted optimized analytical ... [https://jast-journal.springeropen.com/articles/10.1186/s40543-025-00508-x]
• 84. Green HPLC analysis of anti-diabetic and gastric ... [https://www.sciencedirect.com/science/article/abs/pii/S0026265X2501598X]
• 85. Novel eco-friendly HPTLC method using dual-wavelength ... [https://www.nature.com/articles/s41598-024-73523-4]
